JSX For Angular Developers

I share one trick a day until the end of the COVID-19 quarantine in Switzerland, April 19th 2020. Sixteen days left until hopefully better days.


At first I wasn’t that much a fan of the JSX syntax when I discovered it while developing my first Web Components with Stencil. I was missing the Angular HTML templates.

Nowadays? I might change my mind in the future again, but after having developed such an eco-system as DeckDeckGo and having even learned React, I can definitely say that I actually feels all the contrary, I love JSX ❤️. Even probably more these days as I am developing Angular clients’ projects on a weekly basis.

That’s why I had this idea to write a really brief and I hope beginner friendly introduction to JSX as used in Stencil or React for Angular developers.


JSX vs HTML Templates

If you write an Angular application, commonly you are going to separate your components in layers and even probably three separate files: the code (TypeScript), the style (CSS) and the template (HTML, the GUI).

import {Component} from '@angular/core';

@Component({
  selector: 'app-my-component',
  templateUrl: './my-component.component.html',
  styleUrls: ['./my-component.component.scss']
})
export class MyComponentComponent {

}
Enter fullscreen mode Exit fullscreen mode

And the related template:

<div>Hello, World!</div>
Enter fullscreen mode Exit fullscreen mode

With JSX, regardless if Stencil or React, you have this separation of concern too but you are not going to separate your template and code in two separate files. Everything is commonly packed in on file, even in a same class or function .

The separation of concern occurs on the code side. If you have a class , you will have to expose a method render() which returns what suppose to be, guess what, rendered. In short: “a method which renders your HTML code”.

import {Component, h} from '@stencil/core';

@Component({
  tag: 'my-component',
  styleUrl: 'my-component.css'
})
export class MyComponent {

  render() {
    return <div>Hello, World!</div>;
  }

}
Enter fullscreen mode Exit fullscreen mode

If you have a function , then instead of render you will have a return method which follows the same behavior.

import React from 'react';

const MyComponent: React.FC = () => {

    return (
        <div>Hello, World!</div>
    );
};

export default MyComponent;
Enter fullscreen mode Exit fullscreen mode

Both Stencil and React do support class or function . These last type became or are becoming, I think, really popular in React thanks to the use and introduction of Hooks , which I am not going to cover in this article. If you are interested in a separate post about it, ping me! I still have many posts to write to fulfill my challenge 😆.

Note also that for the rest of this article, I will display the Stencil examples using class and the React one using functions .


Root Element

One important difference is the notion of root element. In Angular, you don’t really care about if. If your template contains a single root element or multiple ones, it compiles in any case.

<div>Hello, World!</div>

<div>
  <p>Salut</p>
  <p>Hallo</p>
</div>
Enter fullscreen mode Exit fullscreen mode

In JSX, to the contrary, it does matter. Your component should be developed to handle such cases.

Therefore, our first solution might be to group our children under a single HTML node.

import {Component, h} from '@stencil/core';

@Component({
  tag: 'my-component',
  styleUrl: 'my-component.css'
})
export class MyComponent {

  render() {
    return <div>
      <div>Hello, World!</div>

      <div>
        <p>Salut</p>
        <p>Hallo</p>
      </div>
    </div>;
  }

}
Enter fullscreen mode Exit fullscreen mode

That would work out but this would result on adding a not needed div tag, the parent one, to our DOM. That’s why both Stencil and React have their respective similar solution to this problem.

In Stencil you can use a Host element.

import {Component, h, Host} from '@stencil/core';

@Component({
  tag: 'my-component',
  styleUrl: 'my-component.css'
})
export class MyComponent {

  render() {
    return <Host>
      <div>Hello, World!</div>

      <div>
        <p>Salut</p>
        <p>Hallo</p>
      </div>
    </Host>;
  }

}
Enter fullscreen mode Exit fullscreen mode

And in React you can use what is called a Fragment.

import React from 'react';

const MyComponent: React.FC = () => {

    return (
        <>
            <div>Hello, World!</div>

            <div>
                <p>Salut</p>
                <p>Hallo</p>
            </div>
        </>
    );
};

export default MyComponent;
Enter fullscreen mode Exit fullscreen mode

Finally, in Stencil, if you rather like not to use such container, you can return an array of elements. But I feel like, mostly for styling reason, that I used the above solution more often so far.

import {Component, h} from '@stencil/core';

@Component({
  tag: 'my-component',
  styleUrl: 'my-component.css'
})
export class MyComponent {

  render() {
    return [
      <div>Hello, World!</div>,
      <div>
        <p>Salut</p>
        <p>Hallo</p>
      </div>
    ];
  }

}
Enter fullscreen mode Exit fullscreen mode

States And Properties

In Angular public variables are these used in the templates and for which any changes are triggering a new rendering (“the changes are applied to the GUI”).

Variables made private are these which are used internally in the component and for which, no new rendering is needed.

Moreover there is also the Input decorator which is used to expose a variable as property of the component.

import {Component, Input} from '@angular/core';

@Component({
  selector: 'app-my-component',
  templateUrl: './my-component.component.html',
  styleUrls: ['./my-component.component.scss']
})
export class MyComponentComponent {

  @Input()
  count = 0;

  odd = false;

  private even = false;

  inc() {
    // Render again
    this.count++;
    this.odd = this.count % 2 === 1;

    // Do not trigger a new render
    this.even = this.count % 2 === 0;

}
Enter fullscreen mode Exit fullscreen mode

And corresponding template:

<div>Hello, World!</div>
<div>{{odd}} {{count}}</div>
Enter fullscreen mode Exit fullscreen mode

In JSX, you find the same approach but kind of split in two categories, state and properties , for which, any changes will trigger a new render of the component. On the other side, if you have a variable which is neither one of these, then no render will be triggered again.

properties are kind of the corresponding idea to the @Input() fields, these are the exposed properties of the components.

states are kind of Angular public variables which have not been marked as inputs.

Concretely in Stencil you use decorator for such purpose.

import {Component, h, Host, Prop, State} from '@stencil/core';

@Component({
  tag: 'my-component',
  styleUrl: 'my-component.css'
})
export class MyComponent {

  @Prop()
  count = 0;

  @State()
  private odd = false;

  even = false;

  inc() {
    // Render again
    this.count++;
    this.odd = this.count % 2 === 1;

    // Do not trigger a new render
    this.even = this.count % 2 === 0;
  }

  render() {
    return <Host>
        <div>{this.odd} {this.count}</div>
      </Host>
    ;
  }

}
Enter fullscreen mode Exit fullscreen mode

While in React functions you are going to use hooks to handle states and interfaces to declare your properties.

import React, {useEffect, useState} from 'react';

interface MyProps {
    count: number;
}

const MyComponent: React.FC<MyProps> = (props: MyProps) => {

    const [odd, setOdd] = useState<boolean>(false);
    let even = false;

    useEffect(() => {
        // Render again
        props.count++;
        setOdd(props.count % 2 === 1);

        // Do not trigger a new render
        even = props.count % 2 === 0;
    }, [props.count]);

    return (
        <>
            <div>{odd} {props.count}</div>
        </>
    );
};

export default MyComponent;
Enter fullscreen mode Exit fullscreen mode

I now, I said I won’t cover hooks in this article, therefore let just summarize these as asynchronous functions, which observe or apply a change to a variable and in case of the hook dedicated to states, useState , trigger a new rendering if a change is applied to the observed variable.


Conditional Rendering

Angular exposes is own tags which have to be use in the templates to perform any logical operations, notably *ngIf for conditional rendering.

<div>Hello, World!</div>

<div *ngIf="odd">{{count}}</div>
Enter fullscreen mode Exit fullscreen mode

One beauty of JSX is that you are not developing in a template, therefore you are using statements as you would do writing code.

In brief, a if is a if 😉.

Only important thing to remember about conditional rendering: always return something! That’s why, if you do not want to render anything, I suggest to return undefined which will have for effect to add nothing to the DOM.

With Stencil:

render() {
  return <Host>
    {
      this.odd ? <div>{this.odd} {this.count}</div> : undefined
    }
  </Host>;
}
Enter fullscreen mode Exit fullscreen mode

Or with React:

return (
    <>
        {
            odd ? <div>{odd} {props.count}</div> : undefined
        }
    </>
);
Enter fullscreen mode Exit fullscreen mode

Moreover, you can either inline your condition as above or use it wisely in split render methods.

As in this Stencil example:

render() {
  return <Host>
    {this.renderLabel()}
  </Host>;
}

private renderLabel() {
  return this.odd ? <div>{this.odd} {this.count}</div> : undefined;
}
Enter fullscreen mode Exit fullscreen mode

Or again in this React one:

return (
    <>
        {renderLabel()}
    </>
);

function renderLabel() {
    return odd ? <div>{odd} {props.count}</div> : undefined;
}
Enter fullscreen mode Exit fullscreen mode

Summary

There is so much left to say and to describe, but unfortunately I have to rush to make steps forwards in a useful, particularly in these special days, mobile application I am developing for a client.

If this appetizer made you eager to know more about JSX from an Angular point of view, let me know. I would be really happy to develop it further in several blog posts. And Like I said, I still got some more in order to accomplish my challenge 😃.

Stay home, stay safe!

David
