Part 13: Linked Lists (๐Ÿ˜ฑ ๐Ÿ”ฅ โžก๏ธ)

Alt Text

A linked list is a data structure in which each node (or element) points to another node. Unlike arrays, which have a fixed size, a linked list is a dynamic data structure. By the end of this part 13, you will understand how to implement and work with linked lists. And oh! (๐Ÿ˜ฎ) There are two types of linked lists: singly (โžก๏ธ) and doubly (โ†”๏ธ). Letโ€™s examine the singly linked list first.(๐Ÿ˜ƒ) Let's go! (๐Ÿ”ฅ๐Ÿ”ฅ๐Ÿ”ฅ)

Singly Linked Lists (โžก๏ธโžก๏ธ)

Alt text

The Singly Linked List is data structure where each node has reference to the next node. Let's look to our sample below:
Alt Text

Figure 13-1. Singly linked list

A node in a singly linked list has the following properties: data and next. data is the value and next is a pointer to another. Let's look to our code below to start to write our Singly Linked Lists:

Example:

// Singly Linked List Node
function SinglyLinkedListNode(data) {
    this.data = data;
    this.next = null;
}

The following code below is the base for the singly linked list. That is, the code block that check whether the singly linked list is empty:

Example:

// Singly Linked List Node
function SinglyLinkedListNode(data) {
    this.data = data;
    this.next = null;
}


// Singly Linked List
function SinglyLinkedList() {
    this.head = null;
    this.size = 0;
}

// Base
SinglyLinkedList.prototype.isEmpty = function () {
    return this.size == 0;
}

Note (๐Ÿ“):The start of the linked list is the head. This property defaults to null before inserting any element.

Insertion (โžก๏ธโœ…โžก๏ธ)

The following code block below shows how to insert into a singly linked list. If the head is empty, the head is set to the new node (or must be added an element). Or if the head is not empty, the old heap (collection or quantity) is saved in temp, and the new head becomes the newly added node. Finally, the new headโ€™s next points to the temp (the old temp).

Note (๐Ÿ“): If you are confuse, you can look at the code and study them

Example:

// Singly Linked List Node
function SinglyLinkedListNode(data) {
    this.data = data;
    this.next = null;
}


// Singly Linked List
function SinglyLinkedList() {
    this.head = null;
    this.size = 0;
}

// Base: Empty
SinglyLinkedList.prototype.isEmpty = function () {
    return this.size == 0;
}

// Insert
SinglyLinkedList.prototype.insert = function (value) {
    if (this.head === null) {
        this.head = new SinglyLinkedListNode(value);
    } else {
        var temp = this.head;
        this.head = new SinglyLinkedListNode(value);
        this.head.next = temp;
    }
    this.size++;
}

// Log
SinglyLinkedList.prototype.log = function () {
    var head = this.head.data;
    var next1 = this.head.next.data;
    var next2 = this.head.next.next.data;
    var next3 = this.head.next.next.next;
    return {
        Tree: this.head,
        Result: head + " -> " + next1 + " -> " + next2 + " -> " + next3
    };
}

// Instance(example) of the SinglyLinkedList class
var sll = new SinglyLinkedList();

// Add
sll.insert(1); // 1 -> null
sll.insert(2); // 2 -> 1 -> null
sll.insert(3); // 3 -> 2 -> 1 -> null

// Result
sll.log(); // Prints "3 -> 2 -> 1 -> null"

Execution:

// Singly Linked List Node function SinglyLinkedListNode(data) { this.data = data; this.next = null; } // Singly Linked List function SinglyLinkedList() { this.head = null; this.size = 0; } // Base: Empty SinglyLinkedList.prototype.isEmpty = function () { return this.size == 0; } // Insert SinglyLinkedList.prototype.insert = function (value) { if (this.head === null) { this.head = new SinglyLinkedListNode(value); } else { var temp = this.head; this.head = new SinglyLinkedListNode(value); this.head.next = temp; } this.size++; } // Log SinglyLinkedList.prototype.log = function () { var head = this.head.data; var next1 = this.head.next.data; var next2 = this.head.next.next.data; var next3 = this.head.next.next.next; return { Tree: this.head, Result: head + " -> " + next1 + " -> " + next2 + " -> " + next3 }; } // Instance(example) of the SinglyLinkedList class var sll = new SinglyLinkedList(); // Add sll.insert(1); // 1 -> null sll.insert(2); // 2 -> 1 -> null sll.insert(3); // 3 -> 2 -> 1 -> null // Result sll.log(); // Prints "3 -> 2 -> 1 -> null"

Time Complexity: O(1)O(1)

Deletion By Value (โžก๏ธโžก๏ธโŒ)

The deletion of node in a singly linked list is by removing the reference(the link or the path) of that node. Let's look below how that it works as shown in Figure 13-2:

Alt Text

Figure 13-2. Interior node removal from a singly linked list

If the node is at the end of the linked list, then the second-to-last element can dereference the node by setting its next to null. Let's look at some example code below:

Example:

// Singly Linked List Node
function SinglyLinkedListNode(data) {
    this.data = data;
    this.next = null;
}


// Singly Linked List
function SinglyLinkedList() {
    this.head = null;
    this.size = 0;
}

// Base: Empty
SinglyLinkedList.prototype.isEmpty = function () {
    return this.size == 0;
}

// Insert
SinglyLinkedList.prototype.insert = function (value) {
    if (this.head === null) {
        this.head = new SinglyLinkedListNode(value);
    } else {
        var temp = this.head;
        this.head = new SinglyLinkedListNode(value);
        this.head.next = temp;
    }
    this.size++;
}

// Remove
SinglyLinkedList.prototype.remove = function (value) {
    var currentHead = this.head; // this.head is equal to 3 -> 2 -> 1 -> null
    // currentHead.data is equal to "3"
    if (currentHead.data == value) {
        // x = means deleted reference as an example
        // Remove the reference: 3 x 2 -> 1 -> null
        this.head = currentHead.next;
        // Reduce the size by "one"
        this.size--;
    } else {
        var prev = currentHead;  // prev is equal to 3 -> 2 -> 1 -> null
        // currentHead.next is equal to 2 -> 1 -> null
        while (currentHead.next) {
            // currentHead.data is equal to "3"
            if (currentHead.data == value) {
                // prev.next is equal to 2 -> 1 -> null
                // currentHead.next is equal to 2 -> 1 -> null
                prev.next = currentHead.next;
                // prev is equal to 3 -> 2 -> 1 -> null
                prev = currentHead;
                // x = means deleted reference as an example
                // Remove the reference: 3 x 2 -> 1 -> null
                currentHead = currentHead.next;
                // currentHead is now equal to 2 -> 1 -> null
                break; // break out of the loop
            }

            // prev is now equal to 2 -> 1 -> null since currentHead is equal to 2 -> 1 -> null
            // if "currentHead.data == value" matched, but if not,
            // they ignore it and return to the original: "3 -> 2 -> 1 -> null"
            prev = currentHead;
            // "currentHead = currentHead.next" means move to the next
            // if the first value doesn't match linked list value
            // And then, the while loop starts again...
            currentHead = currentHead.next;
        }

        // If wasn't found in the head or middle, it must be on tail
        if (currentHead.data == value) {
            prev.next = null;
        }
        this.size--;
    }
}

// Log 1: Not Deleted Singly Linked List
SinglyLinkedList.prototype.log1 = function () {
    var head = this.head.data;
    var next1 = this.head.next.data;
    var next2 = this.head.next.next.data;
    var next3 = this.head.next.next.next;
    return {
        Tree: this.head,
        Result: head + " -> " + next1 + " -> " + next2 + " -> " + next3
    };
}

// Log 2: Deleted Singly Linked List
SinglyLinkedList.prototype.log2 = function () {
    var head = this.head.data;
    var next1 = this.head.next

    return {
        Tree: this.head,
        Result: head + " -> " + next1
    };;
}

// Instance(example) of the SinglyLinkedList class
var sll = new SinglyLinkedList();

// Add
sll.insert(1); // 1 -> null
sll.insert(2); // 2 -> 1 -> null
sll.insert(3); // 3 -> 2 -> 1 -> null


// Result
console.log(sll.log1()); // Prints " 3 -> 2 -> 1 -> null"

// Remove
sll.remove(3); // 2 -> 1 -> null
sll.remove(2); // 1 -> null

// Result
sll.log2(); // Prints "1 -> null"

Execution:

// Singly Linked List Node function SinglyLinkedListNode(data) { this.data = data; this.next = null; } // Singly Linked List function SinglyLinkedList() { this.head = null; this.size = 0; } // Base: Empty SinglyLinkedList.prototype.isEmpty = function () { return this.size == 0; } // Insert SinglyLinkedList.prototype.insert = function (value) { if (this.head === null) { this.head = new SinglyLinkedListNode(value); } else { var temp = this.head; this.head = new SinglyLinkedListNode(value); this.head.next = temp; } this.size++; } // Remove SinglyLinkedList.prototype.remove = function (value) { var currentHead = this.head; // this.head is equal to 3 -> 2 -> 1 -> null // currentHead.data is equal to "3" if (currentHead.data == value) { // x = means deleted reference as an example // Remove the reference: 3 x 2 -> 1 -> null this.head = currentHead.next; // Reduce the size by "one" this.size--; } else { var prev = currentHead; // prev is equal to 3 -> 2 -> 1 -> null // currentHead.next is equal to 2 -> 1 -> null while (currentHead.next) { // currentHead.data is equal to "3" if (currentHead.data == value) { // prev.next is equal to 2 -> 1 -> null // currentHead.next is equal to 2 -> 1 -> null prev.next = currentHead.next; // prev is equal to 3 -> 2 -> 1 -> null prev = currentHead; // x = means deleted reference as an example // Remove the reference: 3 x 2 -> 1 -> null currentHead = currentHead.next; // currentHead is now equal to 2 -> 1 -> null break; // break out of the loop } // prev is now equal to 2 -> 1 -> null since currentHead is equal to 2 -> 1 -> null // if "currentHead.data == value" matched, but if not, // they ignore it and return to the original: "3 -> 2 -> 1 -> null" prev = currentHead; // "currentHead = currentHead.next" means move to the next // if the first value doesn't match linked list value // And then, the while loop starts again... currentHead = currentHead.next; } // If wasn't found in the head or middle, it must be on tail if (currentHead.data == value) { prev.next = null; } this.size--; } } // Log 1: Not Deleted Singly Linked List SinglyLinkedList.prototype.log1 = function () { var head = this.head.data; var next1 = this.head.next.data; var next2 = this.head.next.next.data; var next3 = this.head.next.next.next; return { Tree: this.head, Result: head + " -> " + next1 + " -> " + next2 + " -> " + next3 }; } // Log 2: Deleted Singly Linked List SinglyLinkedList.prototype.log2 = function () { var head = this.head.data; var next1 = this.head.next return { Tree: this.head, Result: head + " -> " + next1 };; } // Instance(example) of the SinglyLinkedList class var sll = new SinglyLinkedList(); // Add sll.insert(1); // 1 -> null sll.insert(2); // 2 -> 1 -> null sll.insert(3); // 3 -> 2 -> 1 -> null // Result console.log(sll.log1()); // Prints " 3 -> 2 -> 1 -> null" // Remove sll.remove(3); // 2 -> 1 -> null sll.remove(2); // 1 -> null // Result sll.log2(); // Prints "1 -> null"

Time Complexity: O(n)O(n)

Note (๐Ÿ“): In the worst case, the entire linked list must be traversed.

Deletion at the Head (โŒโžก๏ธโžก๏ธ)

Deleting an element at the head of the linked list is possible in O(1)O(1) . No traversal is required. The implementation of this deletion is shown in the following code block below. This allows the linked list to implement a stack (remember the stack in Part 12). The last-added item can be removed in O(1)O(1) . Let's look at some example code below:

Example:

// Singly Linked List Node
function SinglyLinkedListNode(data) {
    this.data = data;
    this.next = null;
}


// Singly Linked List
function SinglyLinkedList() {
    this.head = null;
    this.size = 0;
}

// Base: Empty
SinglyLinkedList.prototype.isEmpty = function () {
    return this.size == 0;
}

// Insert
SinglyLinkedList.prototype.insert = function (value) {
    if (this.head === null) {
        this.head = new SinglyLinkedListNode(value);
    } else {
        var temp = this.head;
        this.head = new SinglyLinkedListNode(value);
        this.head.next = temp;
    }
    this.size++;
}

// Delete
SinglyLinkedList.prototype.deleteAtHead = function () {
    var toReturn = null;

    if (this.head !== null) {
        toReturn = this.head.data;
        this.data = this.head.next;
        this.size--;
    }
    return toReturn;
}

// Log 1: Not Deleted Singly Linked List
SinglyLinkedList.prototype.log1 = function () {
    var head = this.head.data;
    var next1 = this.head.next.data;
    var next2 = this.head.next.next.data;
    var next3 = this.head.next.next.next;
    return {
        Tree: this.head,
        Result: head + " -> " + next1 + " -> " + next2 + " -> " + next3
    };
}

// Log 2: Deleted Singly Linked List
SinglyLinkedList.prototype.log2 = function () {
    var next1 = this.head.next.data;
    var next2 = this.head.next.next.data;
    var next3 = this.head.next.next.next;

    return {
        Tree: this.head,
        Result: next1 + " -> " + next2 + " -> " + next3
    };;
}

// Instance(example) of the SinglyLinkedList class
var sll = new SinglyLinkedList();

// Add
sll.insert(1); // 1 -> null
sll.insert(2); // 2 -> 1 -> null
sll.insert(3); // 3 -> 2 -> 1 -> null


// Result
console.log(sll.log1()); // Prints " 3 -> 2 -> 1 -> null"

// Remove
sll.deleteAtHead(); // 2 -> 1 -> null

// Result
sll.log2(); // Prints "1 -> null"

Execution:

// Singly Linked List Node function SinglyLinkedListNode(data) { this.data = data; this.next = null; } // Singly Linked List function SinglyLinkedList() { this.head = null; this.size = 0; } // Base: Empty SinglyLinkedList.prototype.isEmpty = function () { return this.size == 0; } // Insert SinglyLinkedList.prototype.insert = function (value) { if (this.head === null) { this.head = new SinglyLinkedListNode(value); } else { var temp = this.head; this.head = new SinglyLinkedListNode(value); this.head.next = temp; } this.size++; } // Delete SinglyLinkedList.prototype.deleteAtHead = function () { var toReturn = null; if (this.head !== null) { toReturn = this.head.data; this.data = this.head.next; this.size--; } return toReturn; } // Log 1: Not Deleted Singly Linked List SinglyLinkedList.prototype.log1 = function () { var head = this.head.data; var next1 = this.head.next.data; var next2 = this.head.next.next.data; var next3 = this.head.next.next.next; return { Tree: this.head, Result: head + " -> " + next1 + " -> " + next2 + " -> " + next3 }; } // Log 2: Deleted Singly Linked List SinglyLinkedList.prototype.log2 = function () { var next1 = this.head.next.data; var next2 = this.head.next.next.data; var next3 = this.head.next.next.next; return { Tree: this.head, Result: next1 + " -> " + next2 + " -> " + next3 };; } // Instance(example) of the SinglyLinkedList class var sll = new SinglyLinkedList(); // Add sll.insert(1); // 1 -> null sll.insert(2); // 2 -> 1 -> null sll.insert(3); // 3 -> 2 -> 1 -> null // Result console.log(sll.log1()); // Prints " 3 -> 2 -> 1 -> null" // Remove sll.deleteAtHead(); // 2 -> 1 -> null // Result sll.log2(); // Prints "1 -> null"

Search (โžก๏ธโžก๏ธ๐Ÿ”Ž)

To find out whether a value exists in a singly linked list, simple iteration through all its next pointers is needed. Let's look at some example code below:

Example:

// Singly Linked List Node
function SinglyLinkedListNode(data) {
    this.data = data;
    this.next = null;
}

// Singly Linked List
function SinglyLinkedList() {
    this.head = null;
    this.size = 0;
}

// Base: Empty
SinglyLinkedList.prototype.isEmpty = function () {
    return this.size == 0;
}

// Insert
SinglyLinkedList.prototype.insert = function (value) {
    if (this.head === null) {
        this.head = new SinglyLinkedListNode(value);
    } else {
        var temp = this.head;
        this.head = new SinglyLinkedListNode(value);
        this.head.next = temp;
    }
    this.size++;
}

// Search
SinglyLinkedList.prototype.find = function (value) {
    var currentHead = this.head;

    while (currentHead.next) {
        if (currentHead.data == value) {
            return true;
        }
        currentHead = currentHead.next;
    }
    return false;
}

// Instance(example) of the SinglyLinkedList class
var sll = new SinglyLinkedList();

// Add
sll.insert(1); // 1 -> null
sll.insert(2); // 2 -> 1 -> null
sll.insert(3); // 3 -> 2 -> 1 -> null

// Search
sll.find(3); // Prints "true"

Execution:

// Singly Linked List Node function SinglyLinkedListNode(data) { this.data = data; this.next = null; } // Singly Linked List function SinglyLinkedList() { this.head = null; this.size = 0; } // Base: Empty SinglyLinkedList.prototype.isEmpty = function () { return this.size == 0; } // Insert SinglyLinkedList.prototype.insert = function (value) { if (this.head === null) { this.head = new SinglyLinkedListNode(value); } else { var temp = this.head; this.head = new SinglyLinkedListNode(value); this.head.next = temp; } this.size++; } // Search SinglyLinkedList.prototype.find = function (value) { var currentHead = this.head; while (currentHead.next) { if (currentHead.data == value) { return true; } currentHead = currentHead.next; } return false; } // Instance(example) of the SinglyLinkedList class var sll = new SinglyLinkedList(); // Add sll.insert(1); // 1 -> null sll.insert(2); // 2 -> 1 -> null sll.insert(3); // 3 -> 2 -> 1 -> null // Search sll.find(3); // Prints "true"

Time Complexity: O(n)O(n)

Note (๐Ÿ“): In the worst case, the entire linked list must be traversed.

Doubly Linked Lists (โ†”๏ธโ†”๏ธ)

Alt text

A doubly linked list can be thought of as a bidirectional(two-way) singly linked list. Each node in the doubly linked list has both a next pointer and a prev pointer. The following code block below implements the doubly linked list node:

Example:

// Doubly Linked List Node
function DoublyLinkedListNode(data) {
    this.data = data;
    this.next = null;
    this.prev = null;
}

In addition, a doubly linked list has a head pointer as well as a tail pointer. The head refers to the beginning, and the tail refers to the end. This is implemented in the following code below along with a helper function to check whether the doubly linked list is empty:

Example:

// Doubly Linked List
function DoublyLinkedList() {
    this.head = null;
    this.tail = null;
    this.size = 0;
}

// Empty
DoublyLinkedList.prototype.isEmpty = function () {
    return this.size == 0;
}

Each node in a doubly linked list has next and prev properties. Figure 13-3 shows an example of a doubly linked list:

Alt Text

Figure 13-3. Doubly linked list example with five nodes

Insertion at the Head (โœ…โ†”๏ธโ†”๏ธ)

Inserting into the head of the doubly linked list is the same as the insertion for the singly linked list except that it has to update the prev pointer as well. The following code block below shows how to insert into the doubly linked list. If the head of the linked list is empty, the head and the tail are set to the new node.

This is because when there is only one element, that element is both the head and the tail. Otherwise, the temp variable is used to store the new node. The new nodeโ€™s next points to the current head, and then the current headโ€™s prev points to the new node. Finally, the head is updated to the new node. Let's look at it below:

Example:

// Doubly Linked List Node
function DoublyLinkedListNode(data) {
    this.data = data;
    this.next = null;
    this.prev = null;
}

// Doubly Linked List
function DoublyLinkedList() {
    this.head = null;
    this.tail = null;
    this.size = 0;
}

//  Add
DoublyLinkedList.prototype.addAtFront = function (value) {
    // At first, the head is null
    if (this.head === null) {
        // So this is the first code block to be executed
        // "this.head = new DoublyLinkedListNode(value);" means
        //  Add "1" to data at current head
        this.head = new DoublyLinkedListNode(value);
        // "this.tail = this.head;" means
        // Add "1" to data at current tail
        this.tail = this.head;
        // This means both head and tail have the
        // same value of "1" at first.
        // After "1", it will go to "else statement"
        // Because "this.head" is now not null
    } else {
        // This is the code block to be executed next after "1"
        // if "this.head" is not null
        // "temp = new DoublyLinkedListNode(value);" means add new node to "this.data"
        // And that is "2". Because that's next
        var temp = new DoublyLinkedListNode(value);
        // "temp.next = this.head;" means add the current head
        // which is "1" and make
        // the last head we did earlier to become the tail
        // And now our head is "2" and the tail is "1"
        // But the "temp.next" said "make 1 as the head"
        // Because that's the last node we add in "temp.next"
        temp.next = this.head; // Working for "tail"
        // "this.head.prev = temp;" means just add the new head
        // "this.head.prev = temp;" means "add 3 after 2"
        // Because the earlier head was "2"
        // And now, our current head is "3"
        this.head.prev = temp; // Working for "head"
        // "this.head = temp;" means "add 2 after 1" and "add 3 after 2"
        // And now, our head is "3" and our tail is "1"
        // "this.head = temp;" makes the navigation
        // to next and prev pointer easier
        this.head = temp;
        // "add 3 after 2" and "add 2 after 1" equate to:
        // "3 <-> 2" as our head to middle and "2 <-> 1" as middle to tail
        // And now we have head and tail
    }
    this.size++;
}

// Log
DoublyLinkedList.prototype.log = function () {
    return {
        head: this.head.data,
        tail: this.tail.data
    };
    // You can try "this.head" and "this.tail" to see
    // the tree structure and study them
}

// Instance(example) of the Doubly Linked List class
var dll = new DoublyLinkedList();

// Add
dll.addAtFront(1);
dll.addAtFront(2);
dll.addAtFront(3);

// Result
dll.log() // Prints "{ head: 3, tail: 1 }"

Execution:

// Doubly Linked List Node function DoublyLinkedListNode(data) { this.data = data; this.next = null; this.prev = null; } // Doubly Linked List function DoublyLinkedList() { this.head = null; this.tail = null; this.size = 0; } // Add DoublyLinkedList.prototype.addAtFront = function (value) { // At first, the head is null if (this.head === null) { // So this is the first code block to be executed // "this.head = new DoublyLinkedListNode(value);" means // Add "1" to data at current head this.head = new DoublyLinkedListNode(value); // "this.tail = this.head;" means // Add "1" to data at current tail this.tail = this.head; // This means both head and tail have the // same value of "1" at first. // After "1", it will go to "else statement" // Because "this.head" is now not null } else { // This is the code block to be executed next after "1" // if "this.head" is not null // "temp = new DoublyLinkedListNode(value);" means add new node to "this.data" // And that is "2". Because that's next var temp = new DoublyLinkedListNode(value); // "temp.next = this.head;" means add the current head // which is "1" and make // the last head we did earlier to become the tail // And now our head is "2" and the tail is "1" // But the "temp.next" said "make 1 as the head" // Because that's the last node we add in "temp.next" temp.next = this.head; // Working for "tail" // "this.head.prev = temp;" means just add the new head // "this.head.prev = temp;" means "add 3 after 2" // Because the earlier head was "2" // And now, our current head is "3" this.head.prev = temp; // Working for "head" // "this.head = temp;" means "add 2 after 1" and "add 3 after 2" // And now, our head is "3" and our tail is "1" // "this.head = temp;" makes the navigation // to next and prev pointer easier this.head = temp; // "add 3 after 2" and "add 2 after 1" equate to: // "3 <-> 2" as our head to middle and "2 <-> 1" as middle to tail // And now we have head and tail } this.size++; } // Log DoublyLinkedList.prototype.log = function () { return { head: this.head.data, tail: this.tail.data }; // You can try "this.head" and "this.tail" to see // the tree structure and study them } // Instance(example) of the Doubly Linked List class var dll = new DoublyLinkedList(); // Add dll.addAtFront(1); dll.addAtFront(2); dll.addAtFront(3); // Result dll.log() // Prints "{ head: 3, tail: 1 }"

Time Complexity: O(1)O(1)

Insertion at the Tail (โ†”๏ธโ†”๏ธโœ…)

Similarly, a new node can be added to the tail of a doubly linked list, as implemented in the following code block:

Example:

// Doubly Linked List Node
function DoublyLinkedListNode(data) {
    this.data = data;
    this.next = null;
    this.prev = null;
}

// Doubly Linked List
function DoublyLinkedList() {
    this.head = null;
    this.tail = null;
    this.size = 0;
}

//  Add
DoublyLinkedList.prototype.addAtTail = function (value) {
    // At first, the tail is null
    if (this.tail === null) {
        // So this is the first code block to be executed
        // "this.tail = new DoublyLinkedListNode(value);" means
        //  Add "1" to data at current tail
        this.tail = new DoublyLinkedListNode(value);
        // "this.head = this.tail;" means
        // Add "1" to data at current head
        this.head = this.tail;
        // This means both head and tail have the
        // same value of "1" at first.
        // After "1", it will go to "else statement"
        // Because "this.tail" is now not null
    } else {
        // This is the code block to be executed next after "1"
        // if "this.tail" is not null
        // "temp = new DoublyLinkedListNode(value);" means add new node to "this.data"
        // And that is "2". Because that's next
        var temp = new DoublyLinkedListNode(value);
        // "temp.prev = this.tail;" means add the current tail
        // which is "1" and make
        // the last tail we did earlier to become the head
        // And now our head is "2" and the tail is "1"
        // But the "temp.prev" said "make 2 as the tail"
        // Because that's the last node we add in "temp.prev"
        temp.prev = this.tail; // Working for "head"
        // "this.tail.next = temp;" means just add the new tail
        // "this.tail.next = temp;" means "add 3 after 2"
        // Because the earlier tail  was "2"
        // And now, our current tail is "3"
        this.tail.next = temp; // Working for "tail"
        // "this.tail = temp;" means "add 2 after 1" and "add 3 after 2"
        // And now, our tail is "3" and our head is "1"
        // "this.head = temp;" makes the navigation
        // to next and prev pointer easier
        this.tail = temp;
        // "add 2 after 1" and "add 3 after 2" equate to:
        // "1 <-> 2" as our head to middle and "2 <-> 3" as middle to tail
        // And now we have head and tail
        // In insertion to the head, we just reverse this code
        // a little bit. So there's just slight change in this code
    }
    this.size++;
}

// Log
DoublyLinkedList.prototype.log = function () {
    return {
        head: this.head.data,
        tail: this.tail.data
    };
    // You can try "this.head" and "this.tail" to see
    // the tree structure and study them
}

// Instance(example) of the Doubly Linked List class
var dll = new DoublyLinkedList();

// Add
dll.addAtTail(1);
dll.addAtTail(2);
dll.addAtTail(3);

// Result
dll.log() // Prints "{ head: 1, tail: 3 }"

Example:

// Doubly Linked List Node function DoublyLinkedListNode(data) { this.data = data; this.next = null; this.prev = null; } // Doubly Linked List function DoublyLinkedList() { this.head = null; this.tail = null; this.size = 0; } // Add DoublyLinkedList.prototype.addAtTail = function (value) { // At first, the tail is null if (this.tail === null) { // So this is the first code block to be executed // "this.tail = new DoublyLinkedListNode(value);" means // Add "1" to data at current tail this.tail = new DoublyLinkedListNode(value); // "this.head = this.tail;" means // Add "1" to data at current head this.head = this.tail; // This means both head and tail have the // same value of "1" at first. // After "1", it will go to "else statement" // Because "this.tail" is now not null } else { // This is the code block to be executed next after "1" // if "this.tail" is not null // "temp = new DoublyLinkedListNode(value);" means add new node to "this.data" // And that is "2". Because that's next var temp = new DoublyLinkedListNode(value); // "temp.prev = this.tail;" means add the current tail // which is "1" and make // the last tail we did earlier to become the head // And now our head is "2" and the tail is "1" // But the "temp.prev" said "make 2 as the tail" // Because that's the last node we add in "temp.prev" temp.prev = this.tail; // Working for "head" // "this.tail.next = temp;" means just add the new tail // "this.tail.next = temp;" means "add 3 after 2" // Because the earlier tail was "2" // And now, our current tail is "3" this.tail.next = temp; // Working for "tail" // "this.tail = temp;" means "add 2 after 1" and "add 3 after 2" // And now, our tail is "3" and our head is "1" // "this.head = temp;" makes the navigation // to next and prev pointer easier this.tail = temp; // "add 2 after 1" and "add 3 after 2" equate to: // "1 <-> 2" as our head to middle and "2 <-> 3" as middle to tail // And now we have head and tail // In insertion to the head, we just reverse this code // a little bit. So there's just slight change in this code } this.size++; } // Log DoublyLinkedList.prototype.log = function () { return { head: this.head.data, tail: this.tail.data }; // You can try "this.head" and "this.tail" to see // the tree structure and study them } // Instance(example) of the Doubly Linked List class var dll = new DoublyLinkedList(); // Add dll.addAtTail(1); dll.addAtTail(2); dll.addAtTail(3); // Result dll.log() // Prints "{ head: 1, tail: 3 }"

Time Complexity: O(1)O(1)

Deletion at the Head (โŒโ†”๏ธโ†”๏ธ)

Removing a node at the head from a doubly linked list can be done in O(1)O(1) time. If there is only one item, both the head and the tail are set to null. Otherwise, the head is set to the headโ€™s next pointer. Finally, the new headโ€™s prev is set to null to remove the reference of the old head. This is implemented in the following code block. This is great because it can be used like a dequeue function from the queue data structure. Let's look at some example code below:

Example:

// Doubly Linked List Node
function DoublyLinkedListNode(data) {
    this.data = data;
    this.next = null;
    this.prev = null;
}

// Doubly Linked List
function DoublyLinkedList() {
    this.head = null;
    this.tail = null;
    this.size = 0;
}

//  Add
DoublyLinkedList.prototype.addAtFront = function (value) {
    if (this.head === null) {
        this.head = new DoublyLinkedListNode(value);
        this.tail = this.head;
    } else {
        var temp = new DoublyLinkedListNode(value);
        temp.next = this.head;
        this.head.prev = temp;
        this.head = temp;
    }
    this.size++;
}

// Delete
DoublyLinkedList.prototype.deleteAtHead = function () {
    var toReturn = null;

    if (this.head !== null) {
        toReturn = this.head.data;
        if (this.tail === this.head) {
            this.head = this.tail = null;
        } else {
            this.head = this.head.next;
            this.head.prev = null;
        }
    }
    this.size--;
    return toReturn;
}

// Log 1
DoublyLinkedList.prototype.log1 = function () {
    return {
        head: this.head.data,
        tail: this.tail.data
    };
}

// Log 2
DoublyLinkedList.prototype.log2 = function () {
    return {
        head: this.head.data,
        tail: this.tail.data
    };
}

// Instance(example) of the Doubly Linked List class
var dll = new DoublyLinkedList();

// Add
dll.addAtFront(1);
dll.addAtFront(2);
dll.addAtFront(3);

// Result
console.log(dll.log1()) // Prints "{ head: 3, tail: 1 }"

// Delete
dll.deleteAtHead();

// Result
console.log(dll.log2()) // Prints "{ head: 2, tail: 1 }"

Execution:

// Doubly Linked List Node function DoublyLinkedListNode(data) { this.data = data; this.next = null; this.prev = null; } // Doubly Linked List function DoublyLinkedList() { this.head = null; this.tail = null; this.size = 0; } // Add DoublyLinkedList.prototype.addAtFront = function (value) { if (this.head === null) { this.head = new DoublyLinkedListNode(value); this.tail = this.head; } else { var temp = new DoublyLinkedListNode(value); temp.next = this.head; this.head.prev = temp; this.head = temp; } this.size++; } // Delete DoublyLinkedList.prototype.deleteAtHead = function () { var toReturn = null; if (this.head !== null) { toReturn = this.head.data; if (this.tail === this.head) { this.head = this.tail = null; } else { this.head = this.head.next; this.head.prev = null; } } this.size--; return toReturn; } // Log 1 DoublyLinkedList.prototype.log1 = function () { return { head: this.head.data, tail: this.tail.data }; } // Log 2 DoublyLinkedList.prototype.log2 = function () { return { head: this.head.data, tail: this.tail.data }; } // Instance(example) of the Doubly Linked List class var dll = new DoublyLinkedList(); // Add dll.addAtFront(1); dll.addAtFront(2); dll.addAtFront(3); // Result console.log(dll.log1()) // Prints "{ head: 3, tail: 1 }" // Delete dll.deleteAtHead(); // Result console.log(dll.log2()) // Prints "{ head: 2, tail: 1 }"

Time Complexity: O(1)O(1)

Deletion at the Tail (โ†”๏ธโ†”๏ธโŒ)

The tail node can be removed in O(1)O(1) time. By having the ability to remove at , the doubly linked list can also be thought of as a bidirectional(two-way) queue data structure. A queue can dequeue the first-added item, but a doubly linked list can dequeue the tail the item at the tail or the item at the head in O(1)O(1) time. Let's look at some example code below:

Example:

// Doubly Linked List Node
function DoublyLinkedListNode(data) {
    this.data = data;
    this.next = null;
    this.prev = null;
}

// Doubly Linked List
function DoublyLinkedList() {
    this.head = null;
    this.tail = null;
    this.size = 0;
}

//  Add
DoublyLinkedList.prototype.addAtTail = function (value) {
    if (this.tail === null) {
        this.tail = new DoublyLinkedListNode(value);
        this.head = this.tail;
    } else {
        var temp = new DoublyLinkedListNode(value);
        temp.prev = this.tail;
        this.tail.next = temp;
        this.tail = temp;
    }
    this.size++;
}

// Delete
DoublyLinkedList.prototype.deleteAtTail = function () {
    var toReturn = null;

    if (this.tail !== null) {
        toReturn = this.tail.data;

        if (this.tail == this.head) {
            this.head = this.tail = null;
        } else {
            this.tail = this.tail.prev;
            this.tail.next = null;
        }
        this.size--;
        return toReturn;
    }
}

// Log 1
DoublyLinkedList.prototype.log1 = function () {
    return {
        head: this.head.data,
        tail: this.tail.data
    };
}

// Log 2
DoublyLinkedList.prototype.log2 = function () {
    return {
        head: this.head.data,
        tail: this.tail.data
    };
}

// Instance(example) of the Doubly Linked List class
var dll = new DoublyLinkedList();

// Add
dll.addAtTail(1);
dll.addAtTail(2);
dll.addAtTail(3);

// Result
console.log(dll.log1()) // Prints "{ head: 1, tail: 3 }"

// Delete
dll.deleteAtTail();

//  Result
dll.log2() // Prints "{ head: 1, tail: 2 }"

Execution:

// Doubly Linked List Node function DoublyLinkedListNode(data) { this.data = data; this.next = null; this.prev = null; } // Doubly Linked List function DoublyLinkedList() { this.head = null; this.tail = null; this.size = 0; } // Add DoublyLinkedList.prototype.addAtTail = function (value) { if (this.tail === null) { this.tail = new DoublyLinkedListNode(value); this.head = this.tail; } else { var temp = new DoublyLinkedListNode(value); temp.prev = this.tail; this.tail.next = temp; this.tail = temp; } this.size++; } // Delete DoublyLinkedList.prototype.deleteAtTail = function () { var toReturn = null; if (this.tail !== null) { toReturn = this.tail.data; if (this.tail == this.head) { this.head = this.tail = null; } else { this.tail = this.tail.prev; this.tail.next = null; } this.size--; return toReturn; } } // Log 1 DoublyLinkedList.prototype.log1 = function () { return { head: this.head.data, tail: this.tail.data }; } // Log 2 DoublyLinkedList.prototype.log2 = function () { return { head: this.head.data, tail: this.tail.data }; } // Instance(example) of the Doubly Linked List class var dll = new DoublyLinkedList(); // Add dll.addAtTail(1); dll.addAtTail(2); dll.addAtTail(3); // Result console.log(dll.log1()) // Prints "{ head: 1, tail: 3 }" // Delete dll.deleteAtTail(); // Result dll.log2() // Prints "{ head: 1, tail: 2 }"

Time Complexity: O(1)O(1)

Search (โ†”๏ธ๐Ÿ”โ†”๏ธ)

To find out whether a value exists in a doubly linked list, you can start at the head and use the next pointer. The following code
block is the same implementation as the singly linked list search implementation, which starts at the head and looks for the item:

Example:

// Doubly Linked List Node
function DoublyLinkedListNode(data) {
    this.data = data;
    this.next = null;
    this.prev = null;
}

// Doubly Linked List
function DoublyLinkedList() {
    this.head = null;
    this.tail = null;
    this.size = 0;
}

//  Add
DoublyLinkedList.prototype.addAtFront = function (value) {
    if (this.head === null) {
        this.head = new DoublyLinkedListNode(value);
        this.tail = this.head;
    } else {
        var temp = new DoublyLinkedListNode(value);
        temp.next = this.head;
        this.head.prev = temp;
        this.head = temp;
    }
    this.size++;
}

// Search
DoublyLinkedList.prototype.findStartingHead = function (value) {
    var currentHead = this.head;
    while (currentHead.next) {
        if (currentHead.data == value) {
            return true;
        }
        currentHead = currentHead.next;
    }
    return false;
}

// Instance(example) of the Doubly Linked List class
var dll = new DoublyLinkedList();

// Add
dll.addAtFront(3);
dll.addAtFront(2);
dll.addAtFront(1);

// Search
dll.findStartingHead(1) // Prints "true"

Execution:

// Doubly Linked List Node function DoublyLinkedListNode(data) { this.data = data; this.next = null; this.prev = null; } // Doubly Linked List function DoublyLinkedList() { this.head = null; this.tail = null; this.size = 0; } // Add DoublyLinkedList.prototype.addAtFront = function (value) { if (this.head === null) { this.head = new DoublyLinkedListNode(value); this.tail = this.head; } else { var temp = new DoublyLinkedListNode(value); temp.next = this.head; this.head.prev = temp; this.head = temp; } this.size++; } // Search DoublyLinkedList.prototype.findStartingHead = function (value) { var currentHead = this.head; while (currentHead.next) { if (currentHead.data == value) { return true; } currentHead = currentHead.next; } return false; } // Instance(example) of the Doubly Linked List class var dll = new DoublyLinkedList(); // Add dll.addAtFront(3); dll.addAtFront(2); dll.addAtFront(1); // Search dll.findStartingHead(1) // Prints "true"

Time Complexity: O(n)O(n)

The following code traverses the doubly linked list starting with the tail using prev pointers:

Example:

// Doubly Linked List Node
function DoublyLinkedListNode(data) {
    this.data = data;
    this.next = null;
    this.prev = null;
}

// Doubly Linked List
function DoublyLinkedList() {
    this.head = null;
    this.tail = null;
    this.size = 0;
}

//  Add
DoublyLinkedList.prototype.addAtTail = function (value) {
    if (this.tail === null) {
        this.tail = new DoublyLinkedListNode(value);
        this.head = this.tail;
    } else {
        var temp = new DoublyLinkedListNode(value);
        temp.prev = this.tail;
        this.tail.next = temp;
        this.tail = temp;
    }
    this.size++;
}

// Search
DoublyLinkedList.prototype.findStartingTail = function (value) {
    var currentTail = this.tail;
    while (currentTail.prev) {
        if (currentTail.data == value) {
            return true;
        }
        currentTail = currentTail.prev;
    }
    return false;
}

// Instance(example) of the Doubly Linked List class
var dll = new DoublyLinkedList();

// Add
dll.addAtTail(1);
dll.addAtTail(2);
dll.addAtTail(3);

// Search
dll.findStartingTail(3) // Prints "true"

Execution:

// Doubly Linked List Node function DoublyLinkedListNode(data) { this.data = data; this.next = null; this.prev = null; } // Doubly Linked List function DoublyLinkedList() { this.head = null; this.tail = null; this.size = 0; } // Add DoublyLinkedList.prototype.addAtTail = function (value) { if (this.tail === null) { this.tail = new DoublyLinkedListNode(value); this.head = this.tail; } else { var temp = new DoublyLinkedListNode(value); temp.prev = this.tail; this.tail.next = temp; this.tail = temp; } this.size++; } // Search DoublyLinkedList.prototype.findStartingTail = function (value) { var currentTail = this.tail; while (currentTail.prev) { if (currentTail.data == value) { return true; } currentTail = currentTail.prev; } return false; } // Instance(example) of the Doubly Linked List class var dll = new DoublyLinkedList(); // Add dll.addAtTail(1); dll.addAtTail(2); dll.addAtTail(3); // Search dll.findStartingTail(3) // Prints "true"

Time Complexity: O(n)O(n)

Note (๐Ÿ“): Although the time complexity for search is the same as the singly linked listโ€™s search, only the doubly linked list can search bidirectionally (using prev or next). This means that if given a reference to a doubly linked list node, doubly linked lists can perform a full search, but a singly linked list is limited to only its next pointers. (๐Ÿ˜‰)

Summary (๐Ÿ“š๐Ÿ“š)

Alt text

The linked list works by having a next pointer (and previous, pointer if doubly linked) to a different node. Insertion for both singly and doubly linked lists has a constant time complexity of O(1)O(1) . The time complexity of deleting from the head of the singly and doubly linked lists is O(1)O(1) as well.

However, searching for an item in both singly and doubly linked list takes O(n)O(n) time. Doubly linked lists should be used when bidirectional(two-way) search is required. Furthermore, doubly linked lists allow you to pop from either the tail or the head of the linked list for a fast O(1)O(1) operation.

Challenge (๐Ÿ”ฅ๐Ÿ”ฅ)

Alt text

These challenge on Linked Lists cover varying problems to aid you solidify the information you have learned from this section. And also, don't forget to post your answer in the comment(with explanation too!): (๐Ÿ˜ƒ)


REVERSE A SINGLY LINKED LIST

Problem: To reverse a singly linked list, simply iterate through each node and set the next property on the current node to the previous node. Give me a code with a time complexity of O(n)O(n) and space complexity of O(1)O(1)

Note (๐Ÿ“): To fully reverse a linked list, the entire N elements of the linked list must be traversed.

Sample:

function reverseSingleLinkedList(sll) { // your code here... }

DELETE DUPLICATES IN A LINKED LIST

Problem: Deleting an item in a linked list is simple. Simply iterate and store visited nodes inside an array. Delete the current element if the current element has already been seen previously. Give me a code with a time complexity of O(n2)O\lparen n^{2}\rparen and a space complexity of O(n)O(n)

Note (๐Ÿ“): Use of the JavaScript Object as a hash table to store and check for seen elements cuts it down to O(n)O(n) but O(n)O(n) in space as extra memory is required for the hash table.

Sample:

function deleteDuplicateInUnsortedSll(sll1) { // You code here... }

Problem: However, this algorithm must iterate over the array with the .indexOf() method, which is O(n)O(n) as well as iterating n times. Hence, it is O(n2)O\lparen n^{2}\rparen in time complexity. In addition, the track array grows to size of NN , and this causes the space complexity to be O(n)O(n) . Letโ€™s cut the time complexity down to O(n)O(n) . So, give me a code with a time complexity of O(n)O\lparen n\rparen and a space complexity of O(n)O(n) .

Sample:

function deleteDuplicateInUnsortedSllBest(sll1) { // You code here... }

Up Next๐Ÿ‘‰ Part 14: Caching (๐Ÿ”ฅ๐Ÿ”ฅ) (August 21-22, 2020)


Alt Text

Discussion

markdown guide


Okay, in part 14, the concept of caching comes from the world of operating systems. You can read more about it in a lecture presentation by Jeff Zarnett from the University of Waterloo here ๐Ÿ‘‰ L21-slides-Memory_Segmentation_Pag...
