Level-up your web images with Unpic picture tags

Responsive images are among the most important tools for improving the performance and user experience of a site. At its most basic, this means helping the browser load images with different resolutions according to the device's window size, and fluidly resizing the image to fit. This is done by including a srcset and sizes in your image tags, and using CSS for responsive resizing. The Unpic <Image> component is the easiest way to do this. It works automatically with your CMS, e-commerce provider or image CDN to deliver the right size and format for the device and has support for ten different frontend frameworks, including React, Astro, Svelte and Vue. However until now it has only supported this core use case. Now, I have added support for <picture> tags, which unlocks many powerful new features including art direction and even loading different images in dark mode.

Note: the images embedded in this post don't use Unpic, because dev.to doesn't support it.

Art direction

While normally you just want to change the size of an image for smaller screens, sometimes you want to get more creative. A beautiful panoramic shot might be best for a high resolution desktop, but a tight portrait or square crop might be better on a phone. Sometimes you might want to use an entirely different image. Art direction with a picture tag lets you do this, with different sources selected using media queries. Let's look at an example.

This dramatic lighthouse shot would be a great hero image, and can be shown in massive resolution on desktop

pigeon point

Photo by Karthik Sreenivas on Unsplash

Unsplash is a supported image CDN, so embedding it is super easy with Unpic. The example here is Astro, but it's similar in all supported frameworks.

<Image
  src="https://images.unsplash.com/photo-1654099749558-84ac187eb292"
  layout="fullWidth"
  alt="Lighthouse"
/>
Enter fullscreen mode Exit fullscreen mode

The Unpic <Image> component generates the following html:

<img
        alt="Lighthouse"
        loading="eager"
        fetchpriority="high"
        style="object-fit:cover;width:100%"
        srcset="https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=640&fit=min&auto=format 640w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=750&fit=min&auto=format 750w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=828&fit=min&auto=format 828w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=960&fit=min&auto=format 960w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1080&fit=min&auto=format 1080w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1280&fit=min&auto=format 1280w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1668&fit=min&auto=format 1668w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1920&fit=min&auto=format 1920w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=2048&fit=min&auto=format 2048w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=2560&fit=min&auto=format 2560w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=3200&fit=min&auto=format 3200w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=3840&fit=min&auto=format 3840w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=4480&fit=min&auto=format 4480w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=5120&fit=min&auto=format 5120w,
https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=6016&fit=min&auto=format 6016w"
        src="https://images.unsplash.com/photo-1654099749558-84ac187eb292?fit=min&auto=format"
      />
Enter fullscreen mode Exit fullscreen mode

Not something you want to generate by hand! It gives a responsive image that works on the largest displays and smallest phones, loads eagerly to keep LCP low and includes sources for all common screen sizes. However with a picture tag we can do something more interesting.

Here's another image of the same lighthouse, but a closer cropped portrait view. We can use a <picture> tag to display it on mobile, while keeping the hero image for larger screens.

Pigeon point light

Photo by Y S on Unsplash

The way you do it is with a normal <picture> tag, and the new Unpic <Source> component.

<picture>
  <!-- Hero image, displayed on screens 768px or wider -->
  <Source
    src="https://images.unsplash.com/photo-1654099749558-84ac187eb292"
    media="(min-width: 768px)"
    layout="fullWidth"
  />
  <!-- Portrait image for screens below that size -->
  <Source
    src="https://images.unsplash.com/photo-1601962468178-9f84128bd046"
    media="(max-width: 767px)"
    width={600}
    height={800}
  />
  <!-- Fallback image, also used for shared alt and loading props -->
  <Image
    src="https://images.unsplash.com/photo-1654099749558-84ac187eb292"
    layout="fullWidth"
    alt="Lighthouse"
    priority
    unstyled
  />
</picture>
Enter fullscreen mode Exit fullscreen mode

We've added the unstyled prop to the Image because otherwise the inline styles will override our responsive styling. This is the generated HTML:

<picture>
  <!-- Hero image, displayed on screens 768px or wider -->
  <source
    srcset="https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=640&fit=min&auto=format 640w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=750&fit=min&auto=format 750w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=828&fit=min&auto=format 828w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=960&fit=min&auto=format 960w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1080&fit=min&auto=format 1080w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1280&fit=min&auto=format 1280w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1668&fit=min&auto=format 1668w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1920&fit=min&auto=format 1920w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=2048&fit=min&auto=format 2048w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=2560&fit=min&auto=format 2560w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=3200&fit=min&auto=format 3200w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=3840&fit=min&auto=format 3840w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=4480&fit=min&auto=format 4480w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=5120&fit=min&auto=format 5120w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=6016&fit=min&auto=format 6016w"
    media="(min-width: 768px)"
  />
  <!-- Portrait image for screens below that size -->
  <source
    sizes="(min-width: 600px) 600px, 100vw"
    srcset="https://images.unsplash.com/photo-1601962468178-9f84128bd046?w=600&h=800&fit=min&auto=format 600w,
  https://images.unsplash.com/photo-1601962468178-9f84128bd046?w=640&h=853&fit=min&auto=format 640w,
  https://images.unsplash.com/photo-1601962468178-9f84128bd046?w=750&h=1000&fit=min&auto=format 750w,
  https://images.unsplash.com/photo-1601962468178-9f84128bd046?w=828&h=1104&fit=min&auto=format 828w,
  https://images.unsplash.com/photo-1601962468178-9f84128bd046?w=960&h=1280&fit=min&auto=format 960w,
  https://images.unsplash.com/photo-1601962468178-9f84128bd046?w=1080&h=1440&fit=min&auto=format 1080w,
  https://images.unsplash.com/photo-1601962468178-9f84128bd046?w=1200&h=1600&fit=min&auto=format 1200w"
    media="(max-width: 767px)"
  />
  <!-- Fallback image, which is also used for shared alt and loading props -->
  <img
    alt="Lighthouse"
    loading="eager"
    fetchpriority="high"
    srcset="https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=640&fit=min&auto=format 640w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=750&fit=min&auto=format 750w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=828&fit=min&auto=format 828w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=960&fit=min&auto=format 960w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1080&fit=min&auto=format 1080w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1280&fit=min&auto=format 1280w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1668&fit=min&auto=format 1668w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=1920&fit=min&auto=format 1920w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=2048&fit=min&auto=format 2048w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=2560&fit=min&auto=format 2560w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=3200&fit=min&auto=format 3200w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=3840&fit=min&auto=format 3840w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=4480&fit=min&auto=format 4480w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=5120&fit=min&auto=format 5120w,
  https://images.unsplash.com/photo-1654099749558-84ac187eb292?w=6016&fit=min&auto=format 6016w"
    src="https://images.unsplash.com/photo-1654099749558-84ac187eb292?fit=min&auto=format"
  />
</picture>
Enter fullscreen mode Exit fullscreen mode

A normal Unpic <Image> component handles all the styling for you, but we had to use unstyled here because we can't use responsive breakpoint with inline styles. Instead we'll be adding CSS to do the styling. In Astro we're using a regular <style> tag, but you can use your favourite styling solution.

We need a breakpoint for each size, but the actual CSS is quite simple:

<picture>
  <!-- Hero image, displayed on screens 768px or wider -->
  <Source src="https://images.unsplash.com/photo-1654099749558-84ac187eb292" media="(min-width: 768px)"
    layout="fullWidth" />
  <!-- Portrait image for screens below that size -->
  <Source src="https://images.unsplash.com/photo-1601962468178-9f84128bd046" media="(max-width: 767px)"
    layout="constrained" width={600} height={800} />
  <!-- Fallback image, which is also used for shared alt and loading props -->
  <Image src="https://images.unsplash.com/photo-1654099749558-84ac187eb292" layout="fullWidth" alt="Lighthouse" priority
    unstyled />
</picture>

<style>
  /* Style for all layouts */
  .hero img {
    object-fit: cover;
    width: 100%;
  }

  @media (min-width: 768px) {
    /* Optionally add styles you want for full width here, e.g. max-height */
  }

  @media (max-width: 767px) {
    /* Style for constrained layout */
    .hero img {
      max-width: 600px;
      aspect-ratio: 3/4;
    }
  }
</style>
Enter fullscreen mode Exit fullscreen mode

This gives a full width hero image for large screens which uses the image's intrinsic size to set the aspect ratio, and smaller screens get a portrait image that keeps the 3:4 (i.e. 600x800) aspect ratio, while being constrained to 600px wide. You can use as many Source images and breakpoints as you need to work with your design.

Dark mode

While the <source> media attributes only supports a subset of media queries, it covers most of the ones you might need. Another interesting option is prefers-color-scheme, which lets you have different images for light and dark mode. This offers some creative possibilities. Let's find another photo of the lighthouse, this time a night shot.

lighthouse at night

Photo by Casey Horner on Unsplash

We can create a picture tag which switches the image according to the current color scheme.

<picture>
  <!-- Daytime, for light mode -->
  <Source
    src="https://images.unsplash.com/photo-1654099749558-84ac187eb292"
    media="(prefers-color-scheme: light)"
    width={800}
    height={600}
  />
  <!-- Nighttime, for dark mode -->
  <Source
    src="https://images.unsplash.com/photo-1522303099041-44f71373af66"
    media="(prefers-color-scheme: dark)"
    width={800}
    height={600}
  />
  <!-- Always include the <Image> last -->
  <Image
    src="https://images.unsplash.com/photo-1654099749558-84ac187eb292"
    width={800}
    height={600}
    alt="Lighthouse"
  />
</picture>
Enter fullscreen mode Exit fullscreen mode

We can use the automatic styling here, because the layouts and sizes are all the same.

Formats

All current browsers support modern image formats such as WebP and AVIF, which can offer much better quality and compression than old formats like JPEG and PNG. Most image CDNs support content negotiation, which means they will deliver the best format supported by the browser. This is handled automatically by Unpic, so normally you don't need to worry about it. Just put in your image URL and the user will be served AVIF, WebP or JPEG according to their browser. However not all image CDNs can do this. In these cases you need to specify the generated format, which means you need to use a <picture> tag if you want to deliver the best images to your users. Probably the most prominent example of a CDN that does this is Contentful. We can use this method to deliver AVIF, WebP or JPEG even though it doesn't support content negotiation.

---
import { Image } from "@unpic/astro"

const toy =
 "https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg";
---
<picture>
  <Source src={toy} type="image/avif" width={800} height={600} />
  <Source src={toy} type="image/webp" width={800} height={600} />
  <Image src={toy} width={800} height={600} alt="Toy" />
</picture>
Enter fullscreen mode Exit fullscreen mode

This time you set type instead of media. This is the mimetype of the image, which tell the browser which image to request. You can see we're using the same src for each โ€“ Unpic will automatically trasform the URL to request the correct format for each. This is the generated HTML. You can see that the URLs include the fm parameter to specify the format. Unpic handles this automatically for all supported image CDNs.

<picture>
  <source sizes="(min-width: 800px) 800px, 100vw"
    srcset="https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=640&h=480&fm=avif&fit=fill 640w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=750&h=563&fm=avif&fit=fill 750w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=800&h=600&fm=avif&fit=fill 800w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=828&h=621&fm=avif&fit=fill 828w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=960&h=720&fm=avif&fit=fill 960w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=1080&h=810&fm=avif&fit=fill 1080w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=1280&h=960&fm=avif&fit=fill 1280w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=1600&h=1200&fm=avif&fit=fill 1600w"
    type="image/avif" />
  <source sizes="(min-width: 800px) 800px, 100vw"
    srcset="https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=640&h=480&fm=webp&fit=fill 640w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=750&h=563&fm=webp&fit=fill 750w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=800&h=600&fm=webp&fit=fill 800w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=828&h=621&fm=webp&fit=fill 828w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=960&h=720&fm=webp&fit=fill 960w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=1080&h=810&fm=webp&fit=fill 1080w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=1280&h=960&fm=webp&fit=fill 1280w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=1600&h=1200&fm=webp&fit=fill 1600w"
    type="image/webp" /><img alt="Toy" loading="lazy" decoding="async" sizes="(min-width: 800px) 800px, 100vw"
    style="object-fit:cover;max-width:800px;max-height:600px;aspect-ratio:1.3333333333333333;width:100%"
    srcset="https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=640&h=480&fit=fill 640w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=750&h=563&fit=fill 750w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=800&h=600&fit=fill 800w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=828&h=621&fit=fill 828w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=960&h=720&fit=fill 960w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=1080&h=810&fit=fill 1080w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=1280&h=960&fit=fill 1280w,
  https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=1600&h=1200&fit=fill 1600w"
    src="https://images.ctfassets.net/yadj1kx9rmg0/wtrHxeu3zEoEce2MokCSi/cf6f68efdcf625fdc060607df0f3baef/quwowooybuqbl6ntboz3.jpg?w=800&h=600&fit=fill" />
</picture>
Enter fullscreen mode Exit fullscreen mode

Remember: you don't need this for most hosts, just for ones that don't support content negotiation.

Try it out

This is just a taste of the things you can do with the <picture> tag in Unpic. You can combine media queries to give all kinds of combination. Try it out - it almost certainly supports your favourite frontend framework. Note that at time of writing, <picture> in Unpic is in beta and does not support web component frameworks (Lit and WebC).
