Kiro with MCP for GitHub Integration, Docs, Diagrams and AWS Recommendations

#aws #terraform #kiro #mcp

How I Used Kiro + MCP to Document, Analyze, Improve and Visualize My AWS Linktree-Style Project

As an AWS Community Builder, I love experimenting with new developer workflows that combine automation, cloud architecture and AI tooling. This article describes how I used Kiro equipped with Model Context Protocol (MCP) servers to automatically analyze, document, diagram, audit and improve a real production project I run on AWS.

My Personal Project: A Fully Serverless "Linktree-Style" Website on AWS

Before diving into MCP, here’s the context.

I maintain a personal production project:

a Linktree-style website built entirely by me, deployed on AWS with:

S3 (static hosting, private bucket)
CloudFront (global delivery)
OAC (Origin Access Control)
CloudFront Functions (routing logic)
Route 53 (DNS and ALIAS records)
ACM Certificate (TLS)
GitHub Actions CI/CD
Terraform IaC (complete infrastructure automation)

This project has grown over time, and I wanted a faster — and smarter — way to:

Understand and document the system
Validate architecture decisions
Receive AWS best-practice recommendations
Generate diagrams using official AWS icons
Improve Terraform (security, cost and performance)
Inspect GitHub workflows and suggest enhancements

That’s when Kiro + MCP changed everything.

What Kiro + MCP Did for This Project

After installing five MCP servers, Kiro became a full cloud architecture assistant.

Here is exactly what it did:

1. Generated a complete Spec File

Kiro analyzed my GitHub repo, Terraform code, static files and folder structure.

Then it produced a clear, structured Spec File describing:

System purpose
AWS services used
CI/CD workflow
Deployment strategy
Security posture
Future improvements

This Spec became a “living blueprint” for the project.

2. Created a full AWS architecture diagram (Draw.io) by itself

Using the diagram MCP, Kiro generated a .drawio file with:

Official AWS icons (mxgraph.aws4)
S3, CloudFront, Route 53, IAM, OAC
Data flows with arrow labels
Component descriptions
Legend and grouping

The diagram opens perfectly in app.diagrams.net.

3. Produced complete documentation using AWS official MCPs

Using:

awslabs.aws-documentation-mcp-server
awslabs.core-mcp-server
mcp-server-fetch
github MCP
diagram-ai MCP

Kiro:

Looked up AWS best practices
Compared my architecture to AWS recommendations
Generated docs in clear, well-structured English
Validated my CloudFront, S3 and Route 53 setup
Suggested improvements using AWS Well-Architected

All with citations and references to AWS documentation pages.

4. Identified improvements and generated new Spec Files to implement them

Examples Kiro suggested (and generated code/specs for):

Security

Add AWS WAF to CloudFront
Enforce TLS 1.3
Ensure S3 bucket has encryption + private access
IAM improvements for GitHub OIDC

Logging

Enable CloudFront logging
Optimize TTLs
Split long-cache and short-cache assets (I implemented this)

Performance

Gzip/Brotli checks
Image resizing recommendations
Use CloudFront Functions instead of Lambda@Edge when possible

Kiro even generated Terraform snippets to apply each change.

My MCP Config (Workspace)

{
  "mcpServers": {
    "fetch": {
      "command": "uvx",
      "args": [
        "mcp-server-fetch"
      ],
      "env": {
        "PYTHONIOENCODING": "utf-8",
        "UV_PYTHON": "python3.12",
        "UV_NO_LAUNCH": "1"
      },
      "disabled": false,
      "autoApprove": [
        "*",
        "fetch"
      ]
    },
    "aws-docs": {
      "command": "uv",
      "args": [
        "tool",
        "run",
        "--from",
        "awslabs.aws-documentation-mcp-server@latest",
        "awslabs.aws-documentation-mcp-server.exe"
      ],
      "env": {
        "FASTMCP_LOG_LEVEL": "ERROR",
        "AWS_DOCUMENTATION_PARTITION": "aws",
        "PYTHONIOENCODING": "utf-8",
        "UV_PYTHON": "python3.12",
        "UV_NO_LAUNCH": "1"
      },
      "disabled": false,
      "autoApprove": [
        "search_documentation"
      ]
    },
    "awslabs.core-mcp-server": {
      "command": "uv",
      "args": [
        "tool",
        "run",
        "--from",
        "awslabs.core-mcp-server@latest",
        "awslabs.core-mcp-server.exe"
      ],
      "env": {
        "FASTMCP_LOG_LEVEL": "ERROR",
        "PYTHONIOENCODING": "utf-8",
        "UV_PYTHON": "python3.12",
        "UV_NO_LAUNCH": "1"
      },
      "disabled": false
    },
    "github": {
      "command": "C:\\Program Files\\nodejs\\npx.cmd",
      "args": [
        "-y",
        "@modelcontextprotocol/server-github"
      ],
      "env": {},
      "disabled": false,
      "autoApprove": [
        "*",
        "search_repositories",
        "list_commits"
      ]
    },
    "diagram-ai": {
      "command": "<!-- replace-here-->
![ ](https://dev-to-uploads.s3.amazonaws.com/uploads/articles/7nko510nmh5rk0xyn3b3.png)\\python.exe",
      "args": [
        "-m",
        "src.application.mcp.server_modular"
      ],
      "env": {
        "DIAGRAM_OUTPUT_DIR": "<!-- replace-here-->\\diagrams",
        "PYTHONIOENCODING": "utf-8"
      },
      "disabled": false,
      "autoApprove": ["*"]
    }
  }
}

AWS WAF Example (from the recommendations)


hcl
resource "aws_wafv2_web_acl" "site" {
  provider = aws.us_east_1
  name     = "site-waf"
  scope    = "CLOUDFRONT"

  rule {
    name     = "AWS-AWSManagedRulesCommonRuleSet"
    priority = 1
    override_action { none {} }

    statement {
      managed_rule_group_statement {
        vendor_name = "AWS"
        name        = "AWSManagedRulesCommonRuleSet"
      }
    }
    visibility_config {
      cloudwatch_metrics_enabled = true
      metric_name                = "common-rules"
      sampled_requests_enabled   = true
    }
  }
}
