How to configure the style of pager arrow in VChart legend?

Problem Description

I used a dark theme and hope to make the page flipper style more prominent. How should I configure it?

Solution

Legend pager corresponds to the configuration of pager.

  • The pager text color can be configured through pager.textStyle.fill.
  • The page flipper button color can be configured through pager.handler.style.
  • The style of the page turning button in the unavailable state needs to be configured through pager.handler.state.disable.fill.
  legends: {
    visible: true,
    pager:{
      textStyle:{
        fill:"rgb(170,170,170)"
      },
      handler:{
        style:{
          fill:'rgb(170,170,170)'
        },
        state:{
          disable:{
            fill:'rgb(47,69,84)'
          }
        }
      }
    }
  },
Enter fullscreen mode Exit fullscreen mode

Code Example

πŸ”” The following code can be copied and pasted into the editor to see the effect.


const spec = {
  type: 'pie',
  theme:"dark",
  width: 300,
  height: 300,
  data: [
    {
      id: 'id0',
      values: [
        { type: 'oxygen', value: '46.60' },
        { type: 'silicon', value: '27.72' },
        { type: 'aluminum', value: '8.13' },
        { type: 'iron', value: '5' },
        { type: 'calcium', value: '3.63' },
        { type: 'sodium', value: '2.83' },
        { type: 'potassium', value: '2.59' },
        { type: 'others', value: '3.5' }
      ]
    }
  ],
  outerRadius: 0.8,
  innerRadius: 0.5,
  padAngle: 0.6,
  valueField: 'value',
  categoryField: 'type',
  legends: {
    visible: true,
    pager:{
      textStyle:{
        fill:"rgb(170,170,170)"
      },
      handler:{
        style:{
          fill:'rgb(170,170,170)'
        },
        state:{
          disable:{
            fill:'rgb(47,69,84)'
          }
        }
      }
    }
  },
}

const vchart = new VChart((spec), { dom: CONTAINER_ID });
vchart.renderSync();

vchart.getCanvas().style.outline = '1px solid orange';
Enter fullscreen mode Exit fullscreen mode

Results
