Angular 8 + Tailwind CSS Guide (Updated for Angular 9 + 10)

seankerwin profile image Sean Kerwin Updated on ・3 min read

So, I've found a lot of crappy guides on the internet about how to integrate TailwindCSS with Angular 8, a lot of them involve some nasty hacks that I think are basically, shit. I've collated some information from various sources online to show you how I go about implementing TailwindCSS with Angular 8. If you're reading this and you don't know what TailwindCSS is, two things, one, where the hell have you been the past few years and two, go to tailwindcss.com and feast in the amazingness (is that even a word) that is Tailwind.

We'll be utilising the @angular-builders/custom-webpack package which will essentially allow us to tailor the webpack build to add tailwind into the build process.

First things first, install the following:

npm i tailwindcss postcss-scss postcss-import postcss-loader @angular-builders/custom-webpack -D

Next you need to open up your Angular project, I'm going to assume you're using sass, as well, why the fuck not?

Open your styles.scss file and add the following at the top.

@import 'tailwindcss/base';
@import 'tailwindcss/components';
@import 'tailwindcss/utilities';
Enter fullscreen mode Exit fullscreen mode

Next, you need to create the tailwind config file, to do so, open your terminal and smash in the following (inside the directory of your app of course).

npx tailwind init

Now we need to extend the webpack config, first, start by creating webpack.config.js at the root of your project, this is what it should look like

module.exports = {
    module: {
        rules: [
            {
                test: /\.scss$/,
                loader: 'postcss-loader',
                options: {
                    ident: 'postcss',
                    syntax: 'postcss-scss',
                    plugins: () => [
                        require('postcss-import'),
                        require('tailwindcss'),
                        require('autoprefixer'),
                    ]
                }
            }
        ]
    }
};
Enter fullscreen mode Exit fullscreen mode

Once you've added that, modify the angular.json file to tell it to use the custom builder and config file.

{
  "architect": {
    "build": {
      "builder": "@angular-builders/custom-webpack:browser",
      "options": {
        "customWebpackConfig": {
          "path": "./webpack.config.js"
        }
      }
    },
    "serve": {
      "builder": "@angular-builders/custom-webpack:dev-server",
      "options": {
        "customWebpackConfig": {
          "path": "./webpack.config.js"
        }
      }
    }
  }
}
Enter fullscreen mode Exit fullscreen mode

Now we're all up and ready to rumble, add some tailwind classes to an object and run

npm start

Extra

The whole point of Tailwind is to create custom utilities, you can do so by doing the following:

Modify your styles.scss and add 2 new custom imports.

@import 'tailwindcss/base';
@import 'tailwindcss/components';
@import './custom-tailwind/custom-components.css'; // added
@import 'tailwindcss/utilities';
@import './custom-tailwind/custom-utilities.css'; // added
Enter fullscreen mode Exit fullscreen mode

Make sure that they're added in the exact order above.

You can now create a folder inside the src directory called custom-tailwind
Inside this, you create the 2 files the same names as above, now you can create custom reusable utilities and components, for example:

custom-components.css

.btn {
  @apply px-4;
  @apply py-2;
  @apply rounded;
  @apply bg-indigo-500;
  @apply text-white;
  transition: 200ms;
}

.btn:hover {
  @apply bg-indigo-600;
}
Enter fullscreen mode Exit fullscreen mode

And now anywhere you want a button, just give it the class .btn and it will apply all the tailwind classes.

For custom-utilities.css, you can do the following:

.rotate-0 {
    transform: rotate(0deg);
}
.rotate-90 {
    transform: rotate(90deg);
}
.rotate-180 {
    transform: rotate(180deg);
}
.rotate-270 {
    transform: rotate(270deg);
}
Enter fullscreen mode Exit fullscreen mode

And now anywhere, you can just call these classes. Neat huh!

Enjoy the power that is TailwindCSS + Angular 8!

Update:

I realise this is a repeated post, for some reason I had 3 dev.to accounts (god knows why) and this is the account I wanted to use, so I deleted this post along with the other account and re-created it here.

Update 2:

This also works the same way with Angular 9, I have this working using angular version "@angular/core": "~9.0.0",

Update 3: Angular 10.X

postcss-loader came with some breaking changes when it jumped from version 3 to 4.

I managed to get Angular 10 and Tailwind to play nicely by changing my webpack.config.js to the following:

module.exports = {
  module: {
    rules: [
      {
        test: /\.scss$/,
        loader: 'postcss-loader',
        options: {
-          ident: 'postcss',
-          syntax: 'postcss-scss',
-          plugins: () => [
-            require('postcss-import'),
-            require('tailwindcss'),
-            require('autoprefixer'),
-          ],
+          postcssOptions: {
+           ident: 'postcss',
+            syntax: 'postcss-scss',
+            plugins: [
+              require('postcss-import'),
+              require('tailwindcss'),
+              require('autoprefixer'),
            ],
          },
        },
      },
    ],
  },
};
Enter fullscreen mode Exit fullscreen mode

Thanks to @phileagleson for spotting this!

You can also skip the entire above process and just the the Schematic that was created to do the work for you.

garygrossgarten/ngx-tailwind

Note, you will still need to change the webpack.config.js even if you use the Schematic when using this with postcss-loader Version 4 and Angular 10

Update

Thanks to thieugiatri4492 for pointing out that if you used my manual method of installing Tailwind, and then moved over to use the schematic, you'll need to remove the webpack.config.js before using the schematic otherwise it will throw an error that it already exists!

Discussion (60)

pic
Editor guide
Collapse
elglogins profile image
Elgars Logins

Hi,

Is it possible to use tailwind @apply function inside of component specific style files? Instead of global one?

Currently my component html might become overloaded of classes and is harder to read.
Instead I could give component context meaningful classes to component HTML elements, and style them with @apply function inside of component stylesheet.

Do you know if it is possible?

Thanks, nice article 👍

Collapse
seankerwin profile image
Sean Kerwin Author

As far as i know, I haven't found a way to use @apply inside a component specific style file. this is because webpack needs to know the file to compile into normal CSS.

There's nothing wrong with having loads of css classes inside HTML, some of mine are full of it, pointless making a class if im only going to use it once, or it's a specific instance i need styling. things like buttons and what not just go inside the custom-components.

If you do find a way of doing it, let me know!

Happy coding!

Collapse
egorpavlikhin profile image
Egor Pavlikhin

Did you find an answer to this? Without it Tailwind is unusable on any significant project.

Collapse
seankerwin profile image
Sean Kerwin Author

I have used Tailwind on some Huge projects...

In fact, apart from some reusable items in my global styles.scss like .btn classes and input classes, all my "component" css files are empty... as i use the tailwind classes within the HTML. I have no need to write component specific styling.

Collapse
airaamane profile image
airaamane

But you can indeed use @apply inside a component's style file, what am I missing? could you talk us through the issue you're facing please.

Thread Thread
egorpavlikhin profile image
Egor Pavlikhin

Unfortunately not, because tailwind is built through custom webpack process, adding component's styles to that is difficult and not supported.

Thread Thread
airaamane profile image
airaamane • Edited

I have actually just checked and this works fine for me, using scss, postcss-loader for webpack, and "tailwindcss": "^1.4.4".
dev-to-uploads.s3.amazonaws.com/i/...

sorry new here don't know why i cant attach photos.

Thread Thread
hohnzy profile image
Jan Dvorak

Same for me. Works just fine when I've followed the implementation described in tis article.

Collapse
applicafroguy profile image
Sivuyile Magutywa

Hi, I created a Schematic using this guide.

npmjs.com/package/@ikamva/ngx-tail...

Collapse
estylzz profile image
Eric Barb

I just tried this, and while it seemed to work just fine, it appears to have removed the configurations sections under build and serve in the angular.json file. I'm still learning, but is this expected or might I have done something wrong? I'm not sure if customWebpackConfig and configurations live and work in harmony, or if the former replaces the later.

Collapse
riscie profile image
riscie • Edited

I saw this too. Not sure if it's expected but you could probably add them back to the config yourself. What do you say @Sivuyile?

Thanks for writing the package, btw!

Collapse
seankerwin profile image
Sean Kerwin Author

I have only just seen this. I've just tested it out and it works perfectly! Good work.
Mind if I fork it to add TailwindUI for those of us that use that too?

Collapse
applicafroguy profile image
Sivuyile Magutywa

It's open-source, Feel free to do whatever you want.

Collapse
applicafroguy profile image
Sivuyile Magutywa

Sorry late reply, I fixed that issue

Collapse
marknt15 profile image
Mark Edward Tan

Hi Sean, can I use both Angular Material and Tailwind CSS at the same time? I'm worried that it will bloat my project and some CSS utility classes might conflict? Have you tried it before?

I'd like to use Angular Material components and style them with Tailwind CSS. Thanks!

Collapse
seankerwin profile image
Sean Kerwin Author

I do just that! I use material for things like Modals/Dialogs and Snackbars and Tailwind to style everything.

I don't actually include the Material CSS into my application!

Collapse
ryanhedges profile image
Ryan Hedges

This is encouraging but I haven't been able to get Angular/Material and Tailwind to work together with this config. It's possible I'm misunderstanding the build process in Angular 9.

If Tailwind is installed this way before running add for Material it warns you that you are not using the default builder and can't add Material.

If you add Material before tailwind, it borks on @import '~@angular/material/theming'; (which the add command adds for you) in styles.scss with Failed to find '~@angular/material/theming'.

Can you share how you have your projects set up to get them to work together?

Thread Thread
seankerwin profile image
Sean Kerwin Author

Oh I forgot to say. You need to add material first, double check all is working and then add tailwind.

Doing it the other way causes issues with webpack

Thread Thread
zuratama profile image
zuratama

I found the solution to this angular theme and tailwind conflict.
change '~@angular/material/theming' to either '~@angular/material/_theming.scss' or
'relative_path_to_node_module (../../node_modules/@angular/material/_theme.scss'

html.developreference.com/article/...

Collapse
plvbroker profile image
plvbroker • Edited

🖐
first, thanks a lot for your article!

i'm facing a problem after setting up custom-webpack

i just tried to implement this to an existing project but it seems that it creates error with previous dependencies (like @angular/material or flickity in my case).

Do I have to do something to import/include third party packages?

Example of an error

ERROR in ./src/app/orpheo/orpheo-presentation/orpheo-presentation.component.scss
Module build failed (from ./node_modules/postcss-loader/src/index.js):
ReferenceError: window is not defined
at Object. (C:\Users\Bams\Documents\plvbroker\plvbroker\node_modules\flickity\js\index.js:39:5)
at Module._compile (internal/modules/cjs/loader.js:776:30)
at Object.Module._extensions..js (internal/modules/cjs/loader.js:787:10)
at Module.load (internal/modules/cjs/loader.js:653:32)
at tryModuleLoad (internal/modules/cjs/loader.js:593:12)
at Function.Module._load (internal/modules/cjs/loader.js:585:3)
at Module.require (internal/modules/cjs/loader.js:690:17)
at require (internal/modules/cjs/helpers.js:25:18)
at Object.plugins (C:\Users\Bams\Documents\plvbroker\plvbroker\webpack.config.js:14:23)
at Object.parseOptions (C:\Users\Bams\Documents\plvbroker\plvbroker\node_modules\postcss-loader\src\options.js:18:23)
at Promise.resolve.then (C:\Users\Bams\Documents\plvbroker\plvbroker\node_modules\postcss-loader\src\index.js:51:27)
at process._tickCallback (internal/process/next_tick.js:68:7)

Collapse
jayantsr83 profile image
Jayant • Edited

Have you got the solution I having this problem

Error after ng serve

Error

Web Config file

module.exports = {
module: {
rules: [
{
test: /.scss$/,
loader: 'postcss-loader',
options: {
ident: 'postcss',
syntax: 'postcss-scss',
plugins: () => [
require('postcss-import'),
require('tailwindcss'),
require('autoprefixer'),
]
}
}
]
}
};

Collapse
applicafroguy profile image
Sivuyile Magutywa

// Don't import like this
@import '~@angular/material/prebuilt-themes/deeppurple-amber.css';

// Remove this ~
@import '@angular/material/prebuilt-themes/deeppurple-amber.css';

Collapse
amprasath profile image
AM Guru Prasath

Data path "" should NOT have additional properties(customWebpackConfig).

Collapse
lukaszj1 profile image
lukaszj1

Go to angular.json and modify builder in build and serve sections:

"projects": {
...
"example-app": {
...
"architect": {
...
"build": {
"builder": "@angular-builders/custom-webpack:browser"
"options": {
...
}

Collapse
anassl profile image
AnassL

Then get error:
Schema validation failed with the following errors:
Data path "" should NOT have additional properties(browserTarget).

Thread Thread
vankeer profile image
Laurens Van Keer

Found this when searching for this error. Just for reference for people who run into the same error in the future: I forgot to replace the default builder (@angular-devkit/build-angular) with @angular-builders/custom-webpack

Collapse
thieugiatri4492 profile image
thieugiatri4492

I have this problem when i try to start the app with ng serve. Can you please help me? :
Alt text of image

Collapse
seankerwin profile image
Sean Kerwin Author

By any chance are you using Angular 10.x?

I think i have encountered the same issue when making a new application using angular 10, I didn't spend much time looking into fixing it. I was just playing with something...

I will update here once I have a working example and how i did it for Angular 10.

Collapse
thieugiatri4492 profile image
thieugiatri4492

Yes, im using angular 10. I occured this problem , i think i have to revert to angular 9

Thread Thread
seankerwin profile image
Sean Kerwin Author

Read the update to my guide. I changed it to work with Angular10

Thread Thread
thieugiatri4492 profile image
thieugiatri4492 • Edited

Now i face the problem with custom webpack builder, did you have occured this problem with angular 10?
Alt text of image
Alt text of image

Thread Thread
seankerwin profile image
Sean Kerwin Author

I have moved to use the schematic garygrossgarten/ngx-tailwind which i dont use a custom-webpack anymore, my angular.json looks like this

"architect": {
        "build": {
          "builder": "ngx-build-plus:browser",
          "options": {
            "outputPath": "dist/my-app",
            "index": "src/index.html",
            "main": "src/main.ts",
            "polyfills": "src/polyfills.ts",
            "tsConfig": "tsconfig.app.json",
            "aot": true,
            "assets": [
              "src/favicon.ico",
              "src/assets"
            ],
            "styles": [
              "src/styles.scss"
            ],
            "scripts": [],
            "extraWebpackConfig": "./webpack.config.js"
          },
          "configurations": {
            "production": {
              "fileReplacements": [
                {
                  "replace": "src/environments/environment.ts",
                  "with": "src/environments/environment.prod.ts"
                }
              ],
              "optimization": true,
              "outputHashing": "all",
              "sourceMap": false,
              "extractCss": true,
              "namedChunks": false,
              "extractLicenses": true,
              "vendorChunk": false,
              "buildOptimizer": true,
              "budgets": [
                {
                  "type": "initial",
                  "maximumWarning": "2mb",
                  "maximumError": "5mb"
                },
                {
                  "type": "anyComponentStyle",
                  "maximumWarning": "6kb",
                  "maximumError": "10kb"
                }
              ]
            }
          }
        },
        "serve": {
          "builder": "ngx-build-plus:dev-server",
          "options": {
            "browserTarget": "my-app:build",
            "extraWebpackConfig": "./webpack.config.js"
          },
          "configurations": {
            "production": {
              "browserTarget": "my-app:build:production"
            }
          }
        },

I suggest you try installing the schematic and go from there!

Thread Thread
thieugiatri4492 profile image
thieugiatri4492

So, do i have to remove the custom webpack ? Or just install the schematic garygrossgarten/ngx-tailwind directly on my project?

Thread Thread
seankerwin profile image
Sean Kerwin Author

You can try just installing the schematic. I’ve never tried undoing my own work in favour of the schematic.

If you do install it. All you should need to do is update the angular.Json to match mine

Thread Thread
thieugiatri4492 profile image
thieugiatri4492

Thank you, i have successfully run with tailwind thank to your guide. But in your post, you have to warn people who already create webpack.config.js, remove it before install schematic because it will throw error that webpack.config.js already exist

Thread Thread
seankerwin profile image
Sean Kerwin Author

Glad you got it to work!

Collapse
alexbjorlig profile image
Alex Bjørlig

I'm trying to follow this guide in a project using angular custom elements. Can't get it to work, the /postcss-loader is looking for my styles.scssin ~projects/eddy-library/src/app/styles.scss. But the correct director is without app, i.e. ~projects/eddy-library/src/styles.scss. How do I fix this?

Collapse
jasontalon profile image
Jason Talon • Edited

Thanks, this helps me to install tailwind to an old Angular 8 app. Though I encounter several issues because the install script provided will install latest versions of its packages, thus breaks due to incompatibility with each other.

I added specific versions to correct them.

npm i tailwindcss@1.9.6 postcss-scss@3.0.4 postcss-import@12.0.1 postcss-loader@3.0.0 @angular-builders/custom-webpack@8.4.1 postcss@7.0.35 -D

Collapse
kienlc1610 profile image
Kien Lam

This work with me in angular 8.

Collapse
carlparrish profile image
Carl Parrish • Edited

I think I'm missing something. I have the following code in my angular app.

<div class="grid grid-cols-1 md:grid-cols-3 gap-4">
  <div class="bg-gray-400">1</div>
  <div class="bg-gray-400">2</div>
  <div class="bg-blue-300">3</div>
</div>

In my angular app the grid doesn't work when I look at it in my dev inspector the grid classes don't seem to be there. The same code in a codepen and the class is there. So I'm assuming somehow the grid classes didn't get installed in my angular app. Other tailwind classes (ie bg-gray-400) are working. Anyone have any suggestions on how to fix this?

Collapse
seankerwin profile image
Sean Kerwin Author

Code looks fine. What version of tailwind are you using? I’m using 1.2 and grids work fine like that.

Collapse
carlparrish profile image
Carl Parrish • Edited
` "tailwindcss": "^1.2.0",`

From my package.json

New error in style.scss. This wasn't there before but I recopied and pasted from your post and now I'm getting this.

ERROR in ./src/styles.scss (./node_modules/@angular-devkit/build-angular/src/angular-cli-files/plugins/raw-css-loader.js!./node_modules/postcss-loader/src??embedded!./node_modules/sass-loader/lib/loader.js??ref--15-3!./node_modules/postcss-loader/src??postcss!./src/styles.scss)
Module build failed (from ./node_modules/postcss-loader/src/index.js):
Error: Failed to find './custom-tailwind/custom-utilities.css'
  in [
    /workspace/fcc-drum-machine/src
  ]
    at resolveModule.catch.catch (/workspace/fcc-drum-machine/node_modules/postcss-import/lib/resolve-id.js:35:13)
Thread Thread
carlparrish profile image
Carl Parrish

must have been something there. recompiled with an empty custom-utilities.css file
while I'm getting the following waring.

WARNING in ./src/styles.scss (./node_modules/@angular-devkit/build-angular/src/angular-cli-files/plugins/raw-css-loader.js!./node_modules/postcss-loader/src??embedded!./node_modules/sass-loader/lib/loader.js??ref--15-3!./node_modules/postcss-loader/src??postcss!./src/styles.scss)
Module Warning (from ./node_modules/postcss-loader/src/index.js):
Warning

(6:1) /workspace/fcc-drum-machine/src/custom-tailwind/custom-utilities.css is empty

It's compiling now and the grid is now working.

Collapse
roberttom profile image
robert-tom • Edited

Hi,

After setting it with the custom webpack builder before using the schema is easy.

We implemented the apply via custom repository packages.
To make this work we modified the webpack config to also use the sass loader and url-resolver:

module.exports = {
module: {
rules: [
{
test: /\.scss$/,
use: [
{
loader: 'postcss-loader',
options: {
postcssOptions: {
ident: 'postcss',
syntax: 'postcss-scss',
plugins: [
require('postcss-import'),
require('tailwindcss'),
require('autoprefixer'),
],
},
},
},
"resolve-url-loader",
"sass-loader",
]
},
],
},
};

So in the style.scss we can add
@import 'tailwindcss/base';

@import 'tailwindcss/components';

@import 'tailwindcss/utilities';
/* You can add global styles to this file, and also import other style files */

@import "~@"; @import "~@....";

Collapse
elroy910 profile image
elroy910 • Edited

Hi,

Great tutorial on how to implement Tailwind within Angular 9. Thanks for the easy to follow Tutorial. I do come across an issue. I see tailwind being loaded correctly but somehow my components are not getting styled. The styling only goes till root level. Any idea what I'm doing wrong?

Thanks in advance.

Leroy

Collapse
seankerwin profile image
Sean Kerwin Author

This will only work for the style.scss at root level, the custom web pack doesn't know about the deep level component css files so you can't use the @apply method in component level stylesheets.

In fact, you shouldn't do this as a rule of thumb with Tailwind anyway. Creating your own custom utilities at root level is fine to use everywhere like a .btn class globally, but there is no need for component level utilities, just use the classes in the html. There's a really good video from Adam Watham about the best practices of Tailwind.

youtube.com/watch?v=J_7_mnFSLDg

Collapse
rjmf2 profile image
Mohamed Fawzy • Edited

for everyone having this error i found a solution at stackOverflow by changing the plugins to array here is the link stackoverflow.com/questions/638589...

Collapse
efraimla profile image
Efraim

But how to get tailwind classes autocompletion?

Collapse
berkayyildiz profile image
Berkay Yıldız

marketplace.visualstudio.com/items...
You can use this extension if you use vscode.

Collapse
alexbjorlig profile image
Alex Bjørlig

I can't get the above extension to work with the provided example

Collapse
dbeetoven profile image
Beetoven Desir

After a few hours of trying to install tailwind, finally, I found this (garygrossgarten/ngx-tailwind) in your article, it's work great.
Thanks. 🤟🏼🥳

Great post

Collapse
iryanjan18 profile image
Ryan Jan Borja

I can't seem to make the style work. I'm currently running Angular 11 and Tailwindcss 2. Followed webpack and tailwindcss config and updated angular.json. It runs but the style is not reflecting

Collapse
seankerwin profile image
Sean Kerwin Author

I haven’t look at Angular 11 with the new Tailwind2 - I will look at this and get back to you

Collapse
briansanchez profile image
Brian Sanchez

thank you.. this is great

Collapse
tehpsalmist profile image
Ben Steward

As the guy writing the "crappy guides" prior to the advent of angular 8, I'm happy to hear we can finally do this "the Angular way." 😁

Collapse
martinsotirov profile image
Martin Sotirov • Edited

Thanks. This works and I can even use @apply in individual components' .scss files.

Collapse
pascalmann profile image
pascalmann

Hi,

  • Using Material and Tailwind together doesn't increase the bundle size ?
  • How skinning the Material components without including his css ?
  • Is it possible to use all the Material components ?
Collapse
applicafroguy profile image
Collapse
joanserna profile image
JoanSerna

With purcecss ?
All clases of tailwindcss are compiled and not remove unsed class

Collapse
25to8 profile image
25to8

You can check this PR: github.com/tailwindcss/setup-examp...
I use Tailwind 1.4.4 and angular 9 and checked it - unused classes will be removed only if you add @fullhuman/postcss-purgecss to webpack.config for production build.
