Déployer et exposer globalement une application multi-clusters via K8GB et Liqo …

https://docs.liqo.io/en/v0.5.2/examples/global-ingress.html

L’équilibrage global de la charge des serveurs (Global server load balancing, GSLB) est une méthode de distribution du trafic Internet vers un réseau de serveurs à travers le monde, créant ainsi une expérience utilisateur plus rapide et plus fiable comme l’explique très bien cet article :

[What is Global Server Load Balancing? Definition & FAQs | Avi Networks](https://avinetworks.com/glossary/global-server-load-balancing-2/#:~:text=Global%20server%20load%20balancing%20(GSLB,servers%20that%20are%20dispersed%20geographically.)

La question est de savoir s’il est possible de bénéficier d’un répartiteur de charge global au niveau de plusieurs clusters Kubernetes et c’est ce que propose le projet open source K8GB qui offre la capacité d’équilibrer la charge des requêtes HTTP sur plusieurs clusters Kubernetes.

En bref, la possibilité de diriger les requêtes HTTP vers un équilibreur de charge local (instances de contrôleur Kubernetes Ingress) en fonction de la santé des services (Pods) dans plusieurs clusters Kubernetes potentiellement dispersés géographiquement, que ce soit sur site ou dans le cloud. Avec des options supplémentaires concernant les critères à utiliser (round robin, pondération, actif/passif, etc.) lors de la détermination du meilleur équilibreur de charge local/instance d’entrée à résoudre …

k8gb

L’objectif de ce projet est de fournir une implémentation d’un GSLB natif cloud qui répond aux exigences suivantes :

• Est léger en termes de besoins en ressources et de complexité d’exécution
• Fonctionne bien dans un cluster Kubernetes
• Pour obtenir une haute disponibilité/redondance, nous devrions être en mesure d’exécuter plusieurs instances (potentiellement sur plusieurs centres de données ou clouds) avec un état partagé
• Utilisez d’autres projets open source éprouvés et populaires, le cas échéant. Ne pas réinventer la roue là où ce n’est pas nécessaire …
• Autoriser les utilisateurs finaux à définir leur configuration GSLB via les moyens natifs de Kubernetes (annotations de ressources, CRD, etc.)
• Fournir une observabilité de la santé opérationnelle de la solution …

Je pars dans la découverte de cette solution avec la création d’une instance Ubuntu 22.04 LTS dans DigitalOcean encore une fois :

doctl compute droplet create \
    --image ubuntu-22-04-x64 \
    --size s-8vcpu-16gb \
    --region ams3 \
    --vpc-uuid 2812643c-3dd8-484a-b9f4-1fce42903731 \
    k8gb

Pour une rapide démo, je clone le dépôt GitHub du projet sur l’instance en récupérant au passage le binaire de k3d (K3s in Docker). Docker est déjà installé …

root@k8gb:~# curl -fsSL https://get.docker.com | sh -
# Executing docker install script, commit: 4f282167c425347a931ccfd95cc91fab041d414f
+ sh -c apt-get update -qq >/dev/null
+ sh -c DEBIAN_FRONTEND=noninteractive apt-get install -y -qq apt-transport-https ca-certificates curl >/dev/null
+ sh -c mkdir -p /etc/apt/keyrings && chmod -R 0755 /etc/apt/keyrings
+ sh -c curl -fsSL "https://download.docker.com/linux/ubuntu/gpg" | gpg --dearmor --yes -o /etc/apt/keyrings/docker.gpg
+ sh -c chmod a+r /etc/apt/keyrings/docker.gpg
+ sh -c echo "deb [arch=amd64 signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/ubuntu jammy stable" > /etc/apt/sources.list.d/docker.list
+ sh -c apt-get update -qq >/dev/null
+ sh -c DEBIAN_FRONTEND=noninteractive apt-get install -y -qq --no-install-recommends docker-ce docker-ce-cli containerd.io docker-compose-plugin docker-scan-plugin >/dev/null
+ version_gte 20.10
+ [-z]
+ return 0
+ sh -c DEBIAN_FRONTEND=noninteractive apt-get install -y -qq docker-ce-rootless-extras >/dev/null
+ sh -c docker version
Client: Docker Engine - Community
 Version: 20.10.21
 API version: 1.41
 Go version: go1.18.7
 Git commit: baeda1f
 Built: Tue Oct 25 18:01:58 2022
 OS/Arch: linux/amd64
 Context: default
 Experimental: true

Server: Docker Engine - Community
 Engine:
  Version: 20.10.21
  API version: 1.41 (minimum version 1.12)
  Go version: go1.18.7
  Git commit: 3056208
  Built: Tue Oct 25 17:59:49 2022
  OS/Arch: linux/amd64
  Experimental: false
 containerd:
  Version: 1.6.9
  GitCommit: 1c90a442489720eec95342e1789ee8a5e1b9536f
 runc:
  Version: 1.1.4
  GitCommit: v1.1.4-0-g5fd4c4d
 docker-init:
  Version: 0.19.0
  GitCommit: de40ad0

================================================================================

To run Docker as a non-privileged user, consider setting up the
Docker daemon in rootless mode for your user:

    dockerd-rootless-setuptool.sh install

Visit https://docs.docker.com/go/rootless/ to learn about rootless mode.

To run the Docker daemon as a fully privileged service, but granting non-root
users access, refer to https://docs.docker.com/go/daemon-access/

WARNING: Access to the remote API on a privileged Docker daemon is equivalent
         to root access on the host. Refer to the 'Docker daemon attack surface'
         documentation for details: https://docs.docker.com/go/attack-surface/

================================================================================

root@k8gb:~# docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES

root@k8gb:~# git clone https://github.com/k8gb-io/k8gb
Cloning into 'k8gb'...
remote: Enumerating objects: 11114, done.
remote: Counting objects: 100% (12/12), done.
remote: Compressing objects: 100% (12/12), done.
remote: Total 11114 (delta 2), reused 2 (delta 0), pack-reused 11102
Receiving objects: 100% (11114/11114), 10.55 MiB | 15.73 MiB/s, done.
Resolving deltas: 100% (5805/5805), done.
root@k8gb:~# cd k8gb/

root@k8gb:~/k8gb# curl -s https://raw.githubusercontent.com/k3d-io/k3d/main/install.sh | bash

Preparing to install k3d into /usr/local/bin
k3d installed into /usr/local/bin/k3d
Run 'k3d --help' to see what you can do with it.
root@k8gb:~/k8gb#
root@k8gb:~/k8gb# k3d --help
https://k3d.io/
k3d is a wrapper CLI that helps you to easily create k3s clusters inside docker.
Nodes of a k3d cluster are docker containers running a k3s image.
All Nodes of a k3d cluster are part of the same docker network.

Usage:
  k3d [flags]
  k3d [command]

Available Commands:
  cluster Manage cluster(s)
  completion Generate completion scripts for [bash, zsh, fish, powershell | psh]
  config Work with config file(s)
  help Help about any command
  image Handle container images.
  kubeconfig Manage kubeconfig(s)
  node Manage node(s)
  registry Manage registry/registries
  version Show k3d and default k3s version

Flags:
  -h, --help help for k3d
      --timestamps Enable Log timestamps
      --trace Enable super verbose output (trace logging)
      --verbose Enable verbose output (debug logging)
      --version Show k3d and default k3s version

Use "k3d [command] --help" for more information about a command.

root@k8gb:~/k8gb# snap install kubectl --classic
snap "kubectl" is already installed, see 'snap help refresh'

root@k8gb:~/k8gb# curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash
  % Total % Received % Xferd Average Speed Time Time Time Current
                                 Dload Upload Total Spent Left Speed
100 11156 100 11156 0 0 51694 0 --:--:-- --:--:-- --:--:-- 51888
Downloading https://get.helm.sh/helm-v3.10.2-linux-amd64.tar.gz
Verifying checksum... Done.
Preparing to install helm into /usr/local/bin
helm installed into /usr/local/bin/helm

Les différents outils de base mis en place, lancement de la démo qui créé localement trois clusters k3s. Plus précisemment, deux clusters k3s locaux via k3d, exposition du service CoreDNS associé pour le trafic DNS UDP, et installation de K8GB avec des applications de test et deux exemples de ressources GSLB par-dessus.

Cette configuration est adaptée aux scénarios locaux et fonctionne sans dépendre d’un fournisseur DNS externe.

root@k8gb:~/k8gb# make deploy-full-local-setup

Creating 3 k8s clusters
make create-local-cluster CLUSTER_NAME=edge-dns
make[1]: Entering directory '/root/k8gb'

Create local cluster edge-dns
k3d cluster create -c k3d/edge-dns.yaml
INFO[0000] Using config file k3d/edge-dns.yaml (k3d.io/v1alpha4#simple)
INFO[0000] Prep: Network
INFO[0000] Re-using existing network 'k3d-action-bridge-network' (ee0b6bae78a46fd6d885e84a0af19bc4cfc93c3af1aee9c0815e198b1baeaf4a)
INFO[0000] Created image volume k3d-edgedns-images
INFO[0000] Starting new tools node...
INFO[0000] Starting Node 'k3d-edgedns-tools'
INFO[0001] Creating node 'k3d-edgedns-server-0'
INFO[0001] Using the k3d-tools node to gather environment information
INFO[0001] HostIP: using network gateway 172.18.0.1 address
INFO[0001] Starting cluster 'edgedns'
INFO[0001] Starting servers...
INFO[0001] Starting Node 'k3d-edgedns-server-0'
INFO[0009] All agents already running.
INFO[0009] All helpers already running.
INFO[0009] Injecting records for hostAliases (incl. host.k3d.internal) and for 1 network members into CoreDNS configmap...
INFO[0011] Cluster 'edgedns' created successfully!
INFO[0011] You can now use it like this:
kubectl cluster-info
make[1]: Leaving directory '/root/k8gb'
make[1]: Entering directory '/root/k8gb'

Create local cluster test-gslb1
k3d cluster create -c k3d/test-gslb1.yaml
INFO[0000] Using config file k3d/test-gslb1.yaml (k3d.io/v1alpha4#simple)
INFO[0000] Prep: Network
INFO[0000] Re-using existing network 'k3d-action-bridge-network' (ee0b6bae78a46fd6d885e84a0af19bc4cfc93c3af1aee9c0815e198b1baeaf4a)
INFO[0000] Created image volume k3d-test-gslb1-images
INFO[0000] Starting new tools node...
INFO[0000] Starting Node 'k3d-test-gslb1-tools'
INFO[0001] Creating node 'k3d-test-gslb1-server-0'
INFO[0001] Creating node 'k3d-test-gslb1-agent-0'
INFO[0001] Using the k3d-tools node to gather environment information
INFO[0001] HostIP: using network gateway 172.18.0.1 address
INFO[0001] Starting cluster 'test-gslb1'
INFO[0001] Starting servers...
INFO[0001] Starting Node 'k3d-test-gslb1-server-0'
INFO[0009] Starting agents...
INFO[0009] Starting Node 'k3d-test-gslb1-agent-0'
INFO[0014] All helpers already running.
INFO[0014] Injecting records for hostAliases (incl. host.k3d.internal) and for 3 network members into CoreDNS configmap...
INFO[0016] Cluster 'test-gslb1' created successfully!
INFO[0016] You can now use it like this:
kubectl cluster-info
make[1]: Leaving directory '/root/k8gb'
make[1]: Entering directory '/root/k8gb'

Create local cluster test-gslb2
k3d cluster create -c k3d/test-gslb2.yaml
INFO[0000] Using config file k3d/test-gslb2.yaml (k3d.io/v1alpha4#simple)
INFO[0000] Prep: Network
INFO[0000] Re-using existing network 'k3d-action-bridge-network' (ee0b6bae78a46fd6d885e84a0af19bc4cfc93c3af1aee9c0815e198b1baeaf4a)
INFO[0000] Created image volume k3d-test-gslb2-images
INFO[0000] Starting new tools node...
INFO[0000] Starting Node 'k3d-test-gslb2-tools'
INFO[0001] Creating node 'k3d-test-gslb2-server-0'
INFO[0001] Creating node 'k3d-test-gslb2-agent-0'
INFO[0001] Using the k3d-tools node to gather environment information
INFO[0001] HostIP: using network gateway 172.18.0.1 address
INFO[0001] Starting cluster 'test-gslb2'
INFO[0001] Starting servers...
INFO[0001] Starting Node 'k3d-test-gslb2-server-0'
INFO[0009] Starting agents...
INFO[0009] Starting Node 'k3d-test-gslb2-agent-0'
INFO[0013] All helpers already running.
INFO[0013] Injecting records for hostAliases (incl. host.k3d.internal) and for 5 network members into CoreDNS configmap...
INFO[0016] Cluster 'test-gslb2' created successfully!
INFO[0016] You can now use it like this:
kubectl cluster-info
make[1]: Leaving directory '/root/k8gb'
make deploy-stable-version DEPLOY_APPS=true
make[1]: Entering directory '/root/k8gb'

Deploying EdgeDNS
kubectl --context k3d-edgedns apply -f deploy/edge/
secret/ddns-key created
deployment.apps/edge created
service/bind created
configmap/zone created
make[2]: Entering directory '/root/k8gb'

Deploy local cluster test-gslb1
kubectl config use-context k3d-test-gslb1
Switched to context "k3d-test-gslb1".

Create namespace
kubectl apply -f deploy/namespace.yaml
namespace/k8gb created

Deploy GSLB operator from v0.10.0
make deploy-k8gb-with-helm
make[3]: Entering directory '/root/k8gb'
# create rfc2136 secret
kubectl -n k8gb create secret generic rfc2136 --from-literal=secret=96Ah/a2g0/nLeFGK+d/0tzQcccf9hCEIy34PoXX2Qg8= || true
secret/rfc2136 created
helm repo add --force-update k8gb https://www.k8gb.io
"k8gb" has been added to your repositories
cd chart/k8gb && helm dependency update
walk.go:74: found symbolic link in path: /root/k8gb/chart/k8gb/LICENSE resolves to /root/k8gb/LICENSE. Contents of linked file included and used
Getting updates for unmanaged Helm repositories...
...Successfully got an update from the "https://absaoss.github.io/coredns-helm" chart repository
Hang tight while we grab the latest from your chart repositories...
...Successfully got an update from the "k8gb" chart repository
Update Complete. ⎈Happy Helming!⎈
Saving 1 charts
Downloading coredns from repo https://absaoss.github.io/coredns-helm
Deleting outdated charts
helm -n k8gb upgrade -i k8gb k8gb/k8gb -f "" \
        --set k8gb.clusterGeoTag='eu' --set k8gb.extGslbClustersGeoTags='us' \
        --set k8gb.reconcileRequeueSeconds=10 \
        --set k8gb.dnsZoneNegTTL=10 \
        --set k8gb.imageTag=v0.10.0 \
        --set k8gb.log.format=simple \
        --set k8gb.log.level=debug \
        --set rfc2136.enabled=true \
        --set k8gb.edgeDNSServers[0]=172.18.0.1:1053 \
        --set externaldns.image=absaoss/external-dns:rfc-ns1 \
        --wait --timeout=2m0s
Release "k8gb" does not exist. Installing it now.
NAME: k8gb
LAST DEPLOYED: Fri Nov 11 19:54:26 2022
NAMESPACE: k8gb
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:
done
   _ ___ _
  | | _( _ ) ___| |__
  | |/ / _ \ / _` | '_ \
  | < (_) | (_| | |_) |
  |_|\_\ ___/ \__ , |_.__/ & all dependencies are installed
             |___/

1. Check if your DNS Zone is served by K8GB CoreDNS
  $ kubectl -n k8gb run -it --rm --restart=Never --image=infoblox/dnstools:latest dnstools --command -- /usr/bin/dig @k8gb-coredns SOA . +short

If everything is fine then you are expected to see similar output:

ns1.dns. hostmaster.dns. 1616173200 7200 1800 86400 3600

make[3]: Leaving directory '/root/k8gb'

Deploy Ingress
helm repo add --force-update nginx-stable https://kubernetes.github.io/ingress-nginx
"nginx-stable" has been added to your repositories
helm repo update
Hang tight while we grab the latest from your chart repositories...
...Successfully got an update from the "k8gb" chart repository
...Successfully got an update from the "nginx-stable" chart repository
Update Complete. ⎈Happy Helming!⎈
helm -n k8gb upgrade -i nginx-ingress nginx-stable/ingress-nginx \
        --version 4.0.15 -f deploy/ingress/nginx-ingress-values.yaml
Release "nginx-ingress" does not exist. Installing it now.
NAME: nginx-ingress
LAST DEPLOYED: Fri Nov 11 19:54:37 2022
NAMESPACE: k8gb
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:
The ingress-nginx controller has been installed.
It may take a few minutes for the LoadBalancer IP to be available.
You can watch the status by running 'kubectl --namespace k8gb get services -o wide -w nginx-ingress-ingress-nginx-controller'

An example Ingress that makes use of the controller:
  apiVersion: networking.k8s.io/v1
  kind: Ingress
  metadata:
    name: example
    namespace: foo
  spec:
    ingressClassName: nginx
    rules:
      - host: www.example.com
        http:
          paths:
            - backend:
                service:
                  name: exampleService
                  port:
                    number: 80
              path: /
    # This section is only required if TLS is to be enabled for the Ingress
    tls:
      - hosts:
        - www.example.com
        secretName: example-tls

If TLS is enabled for the Ingress, a Secret containing the certificate and key must also be provided:

  apiVersion: v1
  kind: Secret
  metadata:
    name: example-tls
    namespace: foo
  data:
    tls.crt: <base64 encoded cert>
    tls.key: <base64 encoded key>
  type: kubernetes.io/tls
make[3]: Entering directory '/root/k8gb'

Deploy GSLB cr
kubectl apply -f deploy/crds/test-namespace.yaml
namespace/test-gslb created
sed -i 's/cloud\.example\.com/cloud.example.com/g' "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr.yaml"
kubectl apply -f "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr.yaml"
gslb.k8gb.absa.oss/test-gslb created
git checkout -- "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr.yaml"
sed -i 's/cloud\.example\.com/cloud.example.com/g' "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr_failover.yaml"
kubectl apply -f "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr_failover.yaml"
gslb.k8gb.absa.oss/test-gslb-failover created
git checkout -- "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr_failover.yaml"

Deploy podinfo
kubectl apply -f deploy/test-apps
service/unhealthy-app created
deployment.apps/unhealthy-app created
helm repo add podinfo https://stefanprodan.github.io/podinfo
"podinfo" has been added to your repositories
helm upgrade --install frontend --namespace test-gslb -f deploy/test-apps/podinfo/podinfo-values.yaml \
        --set ui.message="` kubectl -n k8gb describe deploy k8gb | awk '/CLUSTER_GEO_TAG/ { printf $2 }'`" \
        --set image.repository="ghcr.io/stefanprodan/podinfo" \
        podinfo/podinfo \
        --version 5.1.1
Release "frontend" does not exist. Installing it now.
NAME: frontend
LAST DEPLOYED: Fri Nov 11 19:54:41 2022
NAMESPACE: test-gslb
STATUS: deployed
REVISION: 1
NOTES:
1. Get the application URL by running these commands:
  echo "Visit http://127.0.0.1:8080 to use your application"
  kubectl -n test-gslb port-forward deploy/frontend-podinfo 8080:9898
make[3]: Leaving directory '/root/k8gb'

Wait until Ingress controller is ready
kubectl -n k8gb wait --for=condition=Ready pod -l app.kubernetes.io/name=ingress-nginx --timeout=600s
pod/nginx-ingress-ingress-nginx-controller-7cs7g condition met
pod/nginx-ingress-ingress-nginx-controller-qx5db condition met

test-gslb1 deployed!
make[2]: Leaving directory '/root/k8gb'
make[2]: Entering directory '/root/k8gb'

Deploy local cluster test-gslb2
kubectl config use-context k3d-test-gslb2
Switched to context "k3d-test-gslb2".

Create namespace
kubectl apply -f deploy/namespace.yaml
namespace/k8gb created

Deploy GSLB operator from v0.10.0
make deploy-k8gb-with-helm
make[3]: Entering directory '/root/k8gb'
# create rfc2136 secret
kubectl -n k8gb create secret generic rfc2136 --from-literal=secret=96Ah/a2g0/nLeFGK+d/0tzQcccf9hCEIy34PoXX2Qg8= || true
secret/rfc2136 created
helm repo add --force-update k8gb https://www.k8gb.io
"k8gb" has been added to your repositories
cd chart/k8gb && helm dependency update
walk.go:74: found symbolic link in path: /root/k8gb/chart/k8gb/LICENSE resolves to /root/k8gb/LICENSE. Contents of linked file included and used
Getting updates for unmanaged Helm repositories...
...Successfully got an update from the "https://absaoss.github.io/coredns-helm" chart repository
Hang tight while we grab the latest from your chart repositories...
...Successfully got an update from the "k8gb" chart repository
...Successfully got an update from the "podinfo" chart repository
...Successfully got an update from the "nginx-stable" chart repository
Update Complete. ⎈Happy Helming!⎈
Saving 1 charts
Downloading coredns from repo https://absaoss.github.io/coredns-helm
Deleting outdated charts
helm -n k8gb upgrade -i k8gb k8gb/k8gb -f "" \
        --set k8gb.clusterGeoTag='us' --set k8gb.extGslbClustersGeoTags='eu' \
        --set k8gb.reconcileRequeueSeconds=10 \
        --set k8gb.dnsZoneNegTTL=10 \
        --set k8gb.imageTag=v0.10.0 \
        --set k8gb.log.format=simple \
        --set k8gb.log.level=debug \
        --set rfc2136.enabled=true \
        --set k8gb.edgeDNSServers[0]=172.18.0.1:1053 \
        --set externaldns.image=absaoss/external-dns:rfc-ns1 \
        --wait --timeout=2m0s
Release "k8gb" does not exist. Installing it now.
NAME: k8gb
LAST DEPLOYED: Fri Nov 11 19:55:03 2022
NAMESPACE: k8gb
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:
done
   _ ___ _
  | | _( _ ) ___| |__
  | |/ / _ \ / _` | '_ \
  | < (_) | (_| | |_) |
  |_|\_\ ___/ \__ , |_.__/ & all dependencies are installed
             |___/

1. Check if your DNS Zone is served by K8GB CoreDNS
  $ kubectl -n k8gb run -it --rm --restart=Never --image=infoblox/dnstools:latest dnstools --command -- /usr/bin/dig @k8gb-coredns SOA . +short

If everything is fine then you are expected to see similar output:

ns1.dns. hostmaster.dns. 1616173200 7200 1800 86400 3600

make[3]: Leaving directory '/root/k8gb'

Deploy Ingress
helm repo add --force-update nginx-stable https://kubernetes.github.io/ingress-nginx
"nginx-stable" has been added to your repositories
helm repo update
Hang tight while we grab the latest from your chart repositories...
...Successfully got an update from the "k8gb" chart repository
...Successfully got an update from the "podinfo" chart repository
...Successfully got an update from the "nginx-stable" chart repository
Update Complete. ⎈Happy Helming!⎈
helm -n k8gb upgrade -i nginx-ingress nginx-stable/ingress-nginx \
        --version 4.0.15 -f deploy/ingress/nginx-ingress-values.yaml
Release "nginx-ingress" does not exist. Installing it now.
NAME: nginx-ingress
LAST DEPLOYED: Fri Nov 11 19:55:14 2022
NAMESPACE: k8gb
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:
The ingress-nginx controller has been installed.
It may take a few minutes for the LoadBalancer IP to be available.
You can watch the status by running 'kubectl --namespace k8gb get services -o wide -w nginx-ingress-ingress-nginx-controller'

An example Ingress that makes use of the controller:
  apiVersion: networking.k8s.io/v1
  kind: Ingress
  metadata:
    name: example
    namespace: foo
  spec:
    ingressClassName: nginx
    rules:
      - host: www.example.com
        http:
          paths:
            - backend:
                service:
                  name: exampleService
                  port:
                    number: 80
              path: /
    # This section is only required if TLS is to be enabled for the Ingress
    tls:
      - hosts:
        - www.example.com
        secretName: example-tls

If TLS is enabled for the Ingress, a Secret containing the certificate and key must also be provided:

  apiVersion: v1
  kind: Secret
  metadata:
    name: example-tls
    namespace: foo
  data:
    tls.crt: <base64 encoded cert>
    tls.key: <base64 encoded key>
  type: kubernetes.io/tls
make[3]: Entering directory '/root/k8gb'

Deploy GSLB cr
kubectl apply -f deploy/crds/test-namespace.yaml
namespace/test-gslb created
sed -i 's/cloud\.example\.com/cloud.example.com/g' "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr.yaml"
kubectl apply -f "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr.yaml"
gslb.k8gb.absa.oss/test-gslb created
git checkout -- "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr.yaml"
sed -i 's/cloud\.example\.com/cloud.example.com/g' "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr_failover.yaml"
kubectl apply -f "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr_failover.yaml"
gslb.k8gb.absa.oss/test-gslb-failover created
git checkout -- "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr_failover.yaml"

Deploy podinfo
kubectl apply -f deploy/test-apps
service/unhealthy-app created
deployment.apps/unhealthy-app created
helm repo add podinfo https://stefanprodan.github.io/podinfo
"podinfo" already exists with the same configuration, skipping
helm upgrade --install frontend --namespace test-gslb -f deploy/test-apps/podinfo/podinfo-values.yaml \
        --set ui.message="` kubectl -n k8gb describe deploy k8gb | awk '/CLUSTER_GEO_TAG/ { printf $2 }'`" \
        --set image.repository="ghcr.io/stefanprodan/podinfo" \
        podinfo/podinfo \
        --version 5.1.1
Release "frontend" does not exist. Installing it now.
NAME: frontend
LAST DEPLOYED: Fri Nov 11 19:55:20 2022
NAMESPACE: test-gslb
STATUS: deployed
REVISION: 1
NOTES:
1. Get the application URL by running these commands:
  echo "Visit http://127.0.0.1:8080 to use your application"
  kubectl -n test-gslb port-forward deploy/frontend-podinfo 8080:9898
make[3]: Leaving directory '/root/k8gb'

Wait until Ingress controller is ready
kubectl -n k8gb wait --for=condition=Ready pod -l app.kubernetes.io/name=ingress-nginx --timeout=600s
pod/nginx-ingress-ingress-nginx-controller-tvqn5 condition met
pod/nginx-ingress-ingress-nginx-controller-nnw6p condition met

test-gslb2 deployed!
make[2]: Leaving directory '/root/k8gb'
make[1]: Leaving directory '/root/k8gb'

Les différents clusters sont présents localement :

root@k8gb:~# k3d cluster list
NAME SERVERS AGENTS LOADBALANCER
edgedns 1/1 0/0 false
test-gslb1 1/1 1/1 false
test-gslb2 1/1 1/1 false
root@k8gb:~# kubectl cluster-info --context k3d-edgedns && kubectl cluster-info --context k3d-test-gslb1 && kubectl cluster-info --context k3d-test-gslb2
Kubernetes control plane is running at https://0.0.0.0:43459
CoreDNS is running at https://0.0.0.0:43459/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.
Kubernetes control plane is running at https://0.0.0.0:36415
CoreDNS is running at https://0.0.0.0:36415/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.
Kubernetes control plane is running at https://0.0.0.0:43505
CoreDNS is running at https://0.0.0.0:43505/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

Une brique de monitoring avec Prometheus est fournie également :

root@k8gb:~/k8gb# make deploy-prometheus

Le cluster test-gslb1 expose le DNS externe sur le port par défaut :5053 tandis que test-gslb2 sur le port :5054.

Le cluster edgedns exécute BIND et agit en tant que EdgeDNS détenant la zone déléguée pour notre configuration de test et les réponses sur le port :1053.

root@k8gb:~# dig @localhost -p 1053 roundrobin.cloud.example.com +short +tcp
;; Connection to ::1#1053(::1) for roundrobin.cloud.example.com failed: connection refused.
;; Connection to ::1#1053(::1) for roundrobin.cloud.example.com failed: connection refused.
;; Connection to ::1#1053(::1) for roundrobin.cloud.example.com failed: connection refused.
172.18.0.4
172.18.0.6
172.18.0.3
172.18.0.5

root@k8gb:~# for c in k3d-test-gslb{1,2}; do kubectl get no -ocustom-columns="NAME:.metadata.name,IP:status.addresses[0].address" --context $c; done
NAME IP
k3d-test-gslb1-server-0 172.18.0.3
k3d-test-gslb1-agent-0 172.18.0.4
NAME IP
k3d-test-gslb2-server-0 172.18.0.5
k3d-test-gslb2-agent-0 172.18.0.6

et je peux faire le test via un header spécifique pour les URLs de test :

root@k8gb:~# curl localhost:80 -H "Host:roundrobin.cloud.example.com" && curl localhost:81 -H "Host:roundrobin.cloud.example.com"
{
  "hostname": "frontend-podinfo-7cf64f696-952m9",
  "version": "5.1.1",
  "revision": "",
  "color": "#34577c",
  "logo": "https://raw.githubusercontent.com/stefanprodan/podinfo/gh-pages/cuddle_clap.gif",
  "message": "eu",
  "goos": "linux",
  "goarch": "amd64",
  "runtime": "go1.15.6",
  "num_goroutine": "9",
  "num_cpu": "8"
}{
  "hostname": "frontend-podinfo-59888d86d6-fm77n",
  "version": "5.1.1",
  "revision": "",
  "color": "#34577c",
  "logo": "https://raw.githubusercontent.com/stefanprodan/podinfo/gh-pages/cuddle_clap.gif",
  "message": "us",
  "goos": "linux",
  "goarch": "amd64",
  "runtime": "go1.15.6",
  "num_goroutine": "9",
  "num_cpu": "8"

Les deux clusters ont podinfo installé au sommet où chaque cluster a été étiqueté pour servir une région différente. Dans cette démonstration, nous allons accéder à podinfo par wget -qO — failover.cloud.example.com et selon que podinfo est exécuté dans le cluster, il renvoie uniquement eu ou us.

root@k8gb:~/k8gb# make init-failover
kubectl config use-context k3d-test-gslb2
Switched to context "k3d-test-gslb2".
kubectl apply -f "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr_failover.yaml"
gslb.k8gb.absa.oss/test-gslb-failover unchanged
kubectl config use-context k3d-test-gslb1
Switched to context "k3d-test-gslb1".
kubectl apply -f "deploy/crds/k8gb.absa.oss_v1beta1_gslb_cr_failover.yaml"
gslb.k8gb.absa.oss/test-gslb-failover unchanged
make start-test-app
make[1]: Entering directory '/root/k8gb'
kubectl scale deployment frontend-podinfo -n test-gslb --replicas=2
deployment.apps/frontend-podinfo scaled
make[1]: Leaving directory '/root/k8gb'
root@k8gb:~/k8gb# make test-failover
{
  "hostname": "frontend-podinfo-7cf64f696-c8s5s",
  "version": "5.1.1",
  "revision": "",
  "color": "#34577c",
  "logo": "https://raw.githubusercontent.com/stefanprodan/podinfo/gh-pages/cuddle_clap.gif",
  "message": "eu",
  "goos": "linux",
  "goarch": "amd64",
  "runtime": "go1.15.6",
  "num_goroutine": "8",
  "num_cpu": "8"
}pod "busybox" deleted

root@k8gb:~/k8gb# make stop-test-app
kubectl scale deployment frontend-podinfo -n test-gslb --replicas=0
deployment.apps/frontend-podinfo scaled

root@k8gb:~/k8gb# make test-failover
{
  "hostname": "frontend-podinfo-59888d86d6-fm77n",
  "version": "5.1.1",
  "revision": "",
  "color": "#34577c",
  "logo": "https://raw.githubusercontent.com/stefanprodan/podinfo/gh-pages/cuddle_clap.gif",
  "message": "us",
  "goos": "linux",
  "goarch": "amd64",
  "runtime": "go1.15.6",
  "num_goroutine": "13",
  "num_cpu": "8"
}pod "busybox" deleted

root@k8gb:~/k8gb# make start-test-app
kubectl scale deployment frontend-podinfo -n test-gslb --replicas=2
deployment.apps/frontend-podinfo scaled

root@k8gb:~/k8gb# make test-failover
{
  "hostname": "frontend-podinfo-7cf64f696-jn54t",
  "version": "5.1.1",
  "revision": "",
  "color": "#34577c",
  "logo": "https://raw.githubusercontent.com/stefanprodan/podinfo/gh-pages/cuddle_clap.gif",
  "message": "eu",
  "goos": "linux",
  "goarch": "amd64",
  "runtime": "go1.15.6",
  "num_goroutine": "9",
  "num_cpu": "8"
}pod "busybox" deleted

La partie Round Robin peut également être testée avec Podinfo qui retournera la région us ou *eu * …

root@k8gb:~/k8gb# make test-round-robin
{
  "hostname": "frontend-podinfo-7cf64f696-shlbd",
  "version": "5.1.1",
  "revision": "",
  "color": "#34577c",
  "logo": "https://raw.githubusercontent.com/stefanprodan/podinfo/gh-pages/cuddle_clap.gif",
  "message": "eu",
  "goos": "linux",
  "goarch": "amd64",
  "runtime": "go1.15.6",
  "num_goroutine": "9",
  "num_cpu": "8"
}pod "busybox" deleted
root@k8gb:~/k8gb# make test-round-robin
{
  "hostname": "frontend-podinfo-59888d86d6-fm77n",
  "version": "5.1.1",
  "revision": "",
  "color": "#34577c",
  "logo": "https://raw.githubusercontent.com/stefanprodan/podinfo/gh-pages/cuddle_clap.gif",
  "message": "us",
  "goos": "linux",
  "goarch": "amd64",
  "runtime": "go1.15.6",
  "num_goroutine": "12",
  "num_cpu": "8"
}pod "busybox" deleted

Suppression de l’environnement de test pour la suite …

root@k8gb:~/k8gb# make destroy-full-local-setup

Liqo est un projet open-source qui permet des topologies multi-clusters Kubernetes dynamiques et transparentes, prenant en charge des infrastructures hétérogènes sur site, dans le cloud et en périphérie.

Que fournit-il ?

• Peering : établissement automatique, de pair à pair, de relations de consommation de ressources et de services entre des clusters indépendants et hétérogènes

• VPN complexes et d’autorités de certification : tout est auto-négocié de manière transparente pour vous.

• Déchargement transparent des charges de travail vers des clusters distants. Le multi-clusters est rendu natif et transparent : réduisez tout un cluster distant en un nœud virtuel conforme aux approches et outils standard de Kubernetes.

• Connectivité transparente entre pods et pods et entre pods et services, quelles que soient les configurations et les plugins CNI sous-jacents.

• Accédez nativement aux services exportés par les clusters distants et répartissez les composants applicatifs interconnectés sur plusieurs infrastructures, tout le trafic inter-clusters passant par des tunnels réseau sécurisés.

• Storage fabric : prise en charge de l’exécution à distance de charges de travail à état, selon l’approche de la gravité des données. Étendez de manière transparente les techniques de déploiement de haute disponibilité standard (par exemple, pour les bases de données) aux scénarios multi-clusters, pour des garanties accrues. Tout cela sans la complexité de la gestion de plusieurs répliques indépendantes de clusters et d’applications.

• Liqo
• GitHub - liqotech/liqo: Enable dynamic and seamless Kubernetes multi-cluster topologies

Je récupère le client liqoctl localement ainsi qu’une copie du dépôt sur GitHub :

root@k8gb:~# liqoctl
liqoctl is a CLI tool to install and manage Liqo.

Liqo is a platform to enable dynamic and decentralized resource sharing across
Kubernetes clusters, either on-prem or managed. Liqo allows to run pods on a
remote cluster seamlessly and without any modification of Kubernetes and the
applications. With Liqo it is possible to extend the control and data plane of a
Kubernetes cluster across the cluster's boundaries, making multi-cluster native
and transparent: collapse an entire remote cluster to a local virtual node,
enabling workloads offloading, resource management and cross-cluster communication
compliant with the standard Kubernetes approach.

Usage:
  liqoctl [command]

Available Commands:
  completion Generate the autocompletion script for the specified shell
  generate Generate data/commands to perform additional operations
  help Help about any command
  install Install/upgrade Liqo in the selected cluster
  move Move an object to a different cluster
  offload Offload a resource to remote clusters
  peer Enable a peering towards a remote cluster
  status Show the status of Liqo
  uninstall Uninstall Liqo from the selected cluster
  unoffload Unoffload a resource from remote clusters
  unpeer Disable a peering towards a remote cluster
  version Print the liqo CLI version and the deployed Liqo version

Flags:
      --cluster string The name of the kubeconfig cluster to use
      --context string The name of the kubeconfig context to use
  -h, --help help for liqoctl
      --kubeconfig string Path to the kubeconfig file to use for CLI requests
      --user string The name of the kubeconfig user to use
  -v, --verbose Enable verbose logs (default false)

Use "liqoctl [command] --help" for more information about a command.

root@k8gb:~# git clone https://github.com/liqotech/liqo
Cloning into 'liqo'...
remote: Enumerating objects: 28194, done.
remote: Counting objects: 100% (261/261), done.
remote: Compressing objects: 100% (170/170), done.
remote: Total 28194 (delta 132), reused 173 (delta 81), pack-reused 27933
Receiving objects: 100% (28194/28194), 34.98 MiB | 23.34 MiB/s, done.
Resolving deltas: 100% (18901/18901), done.

root@k8gb:~# cd liqo/examples/global-ingress/
root@k8gb:~/liqo/examples/global-ingress# ls
manifests setup.sh

Le script de configuration dans le dépôt GitHub en exemple crée trois clusters k3s et déploie l’application d’infrastructure appropriée au-dessus d’eux, comme détaillé ci-dessous :

• edgedns : ce cluster sera utilisé pour déployer le service DNS. Dans un environnement de production, il doit s’agir d’un service DNS externe (par exemple, AWS Route53). Il inclut le serveur Bind (manifestes dans le dossier manifestes/edge).
• gslb-eu et gslb-us : ces clusters seront utilisés pour déployer l’application.

Ils comprennent :

• ExternalDNS : il est responsable de la configuration des entrées DNS.
• Ingress Nginx : il est responsable de la gestion du trafic local ingress.
• K8GB : il configure l’entrée multi-clusters.
• Liqo : il permet à l’application de s’étendre sur plusieurs clusters, et se charge de refléter les ressources requises.

root@k8gb:~/liqo/examples/global-ingress# ./setup.sh
SUCCESS No cluster "edgedns" is running.
SUCCESS No cluster "gslb-eu" is running.
SUCCESS No cluster "gslb-us" is running.
SUCCESS Cluster "edgedns" has been created.
SUCCESS Cluster "gslb-eu" has been created.
SUCCESS Cluster "gslb-us" has been created.
SUCCESS Bind server has been deployed.
SUCCESS K8gb has been installed on cluster.
SUCCESS Ingress-nginx has been installed on cluster.
SUCCESS Liqo has been installed on cluster "gslb-eu".
SUCCESS K8gb has been installed on cluster.
SUCCESS Ingress-nginx has been installed on cluster.
SUCCESS Liqo has been installed on cluster "gslb-us".

Liqo étant installé je peux procéder au peering entre les clusters :

root@k8gb:~/liqo/examples/global-ingress# export KUBECONFIG_DNS=$(k3d kubeconfig write edgedns)
export KUBECONFIG=$(k3d kubeconfig write gslb-eu)
export KUBECONFIG_US=$(k3d kubeconfig write gslb-us)

root@k8gb:~/liqo/examples/global-ingress# PEER_US=$(liqoctl generate peer-command --only-command --kubeconfig $KUBECONFIG_US)

root@k8gb:~/liqo/examples/global-ingress# echo "$PEER_US" | bash
 INFO Peering enabled
 INFO Authenticated to cluster "gslb-us"
 INFO Outgoing peering activated to the remote cluster "gslb-us"
 INFO Network established to the remote cluster "gslb-us"
 INFO Node created for remote cluster "gslb-us"
 INFO Peering successfully established

root@k8gb:~/liqo/examples/global-ingress# kubectl get foreignclusters
NAME TYPE OUTGOING PEERING INCOMING PEERING NETWORKING AUTHENTICATION AGE
gslb-us OutOfBand Established None Established Established 18s

On peut voir un nouveau noeud virtuel (liqo-gslb-us) dans le cluster gslb-eu :

root@k8gb:~/liqo/examples/global-ingress# kubectl get node --selector=liqo.io/type=virtual-node
NAME STATUS ROLES AGE VERSION
liqo-gslb-us Ready agent 93s v1.22.6+k3s1

Maintenant que le peering Liqo est établi, et que le nœud virtuel est prêt, il est possible de procéder au déploiement de l’application de démonstration podinfo. Cette application sert une page web montrant différentes informations, y compris le nom du pod, ce qui permet d’identifier facilement la réplique qui génère la réponse HTTP :

root@k8gb:~/liqo/examples/global-ingress# kubectl create namespace podinfo
namespace/podinfo created
root@k8gb:~/liqo/examples/global-ingress# liqoctl offload namespace podinfo --namespace-mapping-strategy EnforceSameName
 INFO Offloading of namespace "podinfo" correctly enabled
 INFO Offloading completed successfully
root@k8gb:~/liqo/examples/global-ingress# helm upgrade --install podinfo --namespace podinfo \
    podinfo/podinfo -f manifests/values/podinfo.yaml
Release "podinfo" does not exist. Installing it now.
NAME: podinfo
LAST DEPLOYED: Fri Nov 11 21:46:59 2022
NAMESPACE: podinfo
STATUS: deployed
REVISION: 1
NOTES:
1. Get the application URL by running these commands:
  http://liqo.cloud.example.com/

root@k8gb:~/liqo/examples/global-ingress# kubectl get ingress -n podinfo
NAME CLASS HOSTS ADDRESS PORTS AGE
podinfo nginx liqo.cloud.example.com 172.21.0.3,172.21.0.4 80 42s

Chaque installation locale de K8GB crée une ressource Gslb avec les informations Ingress et la stratégie donnée (RoundRobin dans ce cas), et ExternalDNS remplit les enregistrements DNS en conséquence :

root@k8gb:~/liqo/examples/global-ingress# kubectl get gslbs.k8gb.absa.oss -n podinfo podinfo -o yaml
apiVersion: k8gb.absa.oss/v1beta1
kind: Gslb
metadata:
  annotations:
    k8gb.io/strategy: roundRobin
    meta.helm.sh/release-name: podinfo
    meta.helm.sh/release-namespace: podinfo
  creationTimestamp: "2022-11-11T21:47:01Z"
  finalizers:
  - k8gb.absa.oss/finalizer
  generation: 2
  name: podinfo
  namespace: podinfo
  ownerReferences:
  - apiVersion: networking.k8s.io/v1
    blockOwnerDeletion: true
    controller: true
    kind: Ingress
    name: podinfo
    uid: e4fe5d03-5aa6-4883-b204-5e63ef8a0b31
  resourceVersion: "1858"
  uid: a450617c-7922-4272-865b-4cbc7e09ce03
spec:
  ingress:
    ingressClassName: nginx
    rules:
    - host: liqo.cloud.example.com
      http:
        paths:
        - backend:
            service:
              name: podinfo
              port:
                number: 9898
          path: /
          pathType: ImplementationSpecific
  strategy:
    dnsTtlSeconds: 30
    splitBrainThresholdSeconds: 300
    type: roundRobin
status:
  geoTag: eu
  healthyRecords:
    liqo.cloud.example.com:
    - 172.21.0.3
    - 172.21.0.4
    - 172.21.0.5
    - 172.21.0.6
  serviceHealth:
    liqo.cloud.example.com: Healthy

root@k8gb:~/liqo/examples/global-ingress# kubectl get gslbs.k8gb.absa.oss -n podinfo podinfo -o yaml --kubeconfig $KUBECONFIG_US
apiVersion: k8gb.absa.oss/v1beta1
kind: Gslb
metadata:
  annotations:
    k8gb.io/strategy: roundRobin
    meta.helm.sh/release-name: podinfo
    meta.helm.sh/release-namespace: podinfo
  creationTimestamp: "2022-11-11T21:47:01Z"
  finalizers:
  - k8gb.absa.oss/finalizer
  generation: 2
  name: podinfo
  namespace: podinfo
  ownerReferences:
  - apiVersion: networking.k8s.io/v1
    blockOwnerDeletion: true
    controller: true
    kind: Ingress
    name: podinfo
    uid: 7519e30f-0a46-4c23-86b4-5970c9c030bb
  resourceVersion: "1692"
  uid: 1c3422c8-8c4f-4d2c-a659-9f0907694ab0
spec:
  ingress:
    ingressClassName: nginx
    rules:
    - host: liqo.cloud.example.com
      http:
        paths:
        - backend:
            service:
              name: podinfo
              port:
                number: 9898
          path: /
          pathType: ImplementationSpecific
  strategy:
    dnsTtlSeconds: 30
    splitBrainThresholdSeconds: 300
    type: roundRobin
status:
  geoTag: us
  healthyRecords:
    liqo.cloud.example.com:
    - 172.21.0.5
    - 172.21.0.6
    - 172.21.0.3
    - 172.21.0.4
  serviceHealth:
    liqo.cloud.example.com: Healthy

Dans les deux clusters, les ressources Gslb sont à peu près identiques ; elles ne diffèrent que pour le champ geoTag : “ eu ” ou “ us ” dans ce cas …

root@k8gb:~/liqo/examples/global-ingress# kubectl get po,svc -A
NAMESPACE NAME READY STATUS RESTARTS AGE
kube-system pod/coredns-96cc4f57d-ss69w 1/1 Running 0 18m
k8gb pod/k8gb-6ff7b8d894-mqv4g 1/1 Running 0 18m
k8gb pod/external-dns-6bd44c4856-47k5q 1/1 Running 0 18m
k8gb pod/nginx-ingress-ingress-nginx-controller-68jkc 1/1 Running 0 18m
k8gb pod/nginx-ingress-ingress-nginx-controller-w6jgj 1/1 Running 0 18m
liqo pod/liqo-network-manager-7f775cdbf9-q2dcb 1/1 Running 0 18m
liqo pod/liqo-route-tmqfl 1/1 Running 0 18m
liqo pod/liqo-controller-manager-db9cf996d-qvdtl 1/1 Running 0 18m
liqo pod/liqo-route-h5mk7 1/1 Running 0 18m
liqo pod/liqo-gateway-59b8745db9-t9gtw 1/1 Running 0 18m
liqo pod/liqo-crd-replicator-68cb95df4f-9r2cm 1/1 Running 0 18m
liqo pod/liqo-proxy-54bf9dbb8d-h48vm 1/1 Running 0 18m
liqo pod/liqo-auth-6f6d6946fb-pqdj9 1/1 Running 0 18m
liqo pod/liqo-metric-agent-94f8b96fc-62p7s 1/1 Running 0 18m
k8gb pod/k8gb-coredns-5bc6689949-pv8bs 1/1 Running 0 18m
liqo-tenant-gslb-us-726836 pod/virtual-kubelet-5657cbd4bb-p79jv 1/1 Running 0 15m
podinfo pod/podinfo-68f5575b95-wqqbg 1/1 Running 0 10m
podinfo pod/podinfo-68f5575b95-vlbgp 1/1 Running 0 10m

NAMESPACE NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
default service/kubernetes ClusterIP 10.30.0.1 <none> 443/TCP 19m
kube-system service/kube-dns ClusterIP 10.30.0.10 <none> 53/UDP,53/TCP,9153/TCP 19m
k8gb service/k8gb-coredns ClusterIP 10.30.154.126 <none> 53/UDP 18m
liqo service/liqo-network-manager ClusterIP 10.30.183.107 <none> 6000/TCP 18m
liqo service/liqo-metric-agent ClusterIP 10.30.194.131 <none> 443/TCP 18m
liqo service/liqo-auth NodePort 10.30.38.82 <none> 443:31758/TCP 18m
liqo service/liqo-controller-manager ClusterIP 10.30.137.139 <none> 9443/TCP 18m
liqo service/liqo-proxy ClusterIP 10.30.181.12 <none> 8118/TCP 18m
liqo service/liqo-gateway NodePort 10.30.49.231 <none> 5871:31366/UDP 18m
podinfo service/podinfo ClusterIP 10.30.150.228 <none> 9898/TCP,9999/TCP 10m

root@k8gb:~/liqo/examples/global-ingress# k3d cluster list
NAME SERVERS AGENTS LOADBALANCER
edgedns 1/1 0/0 false
gslb-eu 1/1 1/1 false
gslb-us 1/1 1/1 false

root@k8gb:~/liqo/examples/global-ingress# kubectl get po,svc -A --kubeconfig $KUBECONFIG_US
NAMESPACE NAME READY STATUS RESTARTS AGE
kube-system pod/coredns-96cc4f57d-88b9s 1/1 Running 0 21m
k8gb pod/external-dns-768c97f5c8-dqstb 1/1 Running 0 20m
k8gb pod/k8gb-864c495ddb-9jv2b 1/1 Running 0 20m
k8gb pod/nginx-ingress-ingress-nginx-controller-g26vh 1/1 Running 0 20m
k8gb pod/nginx-ingress-ingress-nginx-controller-jrjjl 1/1 Running 0 20m
liqo pod/liqo-route-796x7 1/1 Running 0 20m
liqo pod/liqo-crd-replicator-68cb95df4f-zbdsb 1/1 Running 0 20m
liqo pod/liqo-proxy-54bf9dbb8d-l77mr 1/1 Running 0 20m
liqo pod/liqo-metric-agent-94f8b96fc-rc8vz 1/1 Running 0 20m
liqo pod/liqo-controller-manager-d54767454-z2zg8 1/1 Running 0 20m
liqo pod/liqo-gateway-59b8745db9-4n6gv 1/1 Running 0 20m
liqo pod/liqo-network-manager-7f775cdbf9-7tn7j 1/1 Running 0 20m
liqo pod/liqo-route-zcqmc 1/1 Running 0 20m
k8gb pod/k8gb-coredns-5bc6689949-twc27 1/1 Running 0 20m
liqo pod/liqo-auth-95c87b89b-nk9jb 1/1 Running 0 20m
podinfo pod/podinfo-68f5575b95-wqqbg 1/1 Running 0 13m

NAMESPACE NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
default service/kubernetes ClusterIP 10.30.0.1 <none> 443/TCP 21m
kube-system service/kube-dns ClusterIP 10.30.0.10 <none> 53/UDP,53/TCP,9153/TCP 21m
k8gb service/k8gb-coredns ClusterIP 10.30.180.140 <none> 53/UDP 20m
liqo service/liqo-network-manager ClusterIP 10.30.133.122 <none> 6000/TCP 20m
liqo service/liqo-metric-agent ClusterIP 10.30.157.244 <none> 443/TCP 20m
liqo service/liqo-proxy ClusterIP 10.30.27.174 <none> 8118/TCP 20m
liqo service/liqo-auth NodePort 10.30.128.127 <none> 443:31335/TCP 20m
liqo service/liqo-controller-manager ClusterIP 10.30.138.46 <none> 9443/TCP 20m
liqo service/liqo-gateway NodePort 10.30.156.207 <none> 5871:30349/UDP 20m
podinfo service/podinfo ClusterIP 10.30.48.175 <none> 9898/TCP,9999/TCP 13m

Comme podinfo est un service HTTP, on peut le contacter en utilisant la commande curl avec l’option -v pour comprendre lequel des nœuds est visé. Le serveur DNS est utilisé afin de résoudre le nom d’hôte vers l’adresse IP du service …

root@k8gb:~/liqo/examples/global-ingress# HOSTNAME="liqo.cloud.example.com"
K8GB_COREDNS_IP=$(kubectl get svc k8gb-coredns -n k8gb -o custom-columns='IP:spec.clusterIP' --no-headers)

kubectl run -it --rm curl --restart=Never --image=curlimages/curl:7.82.0 --command \
    --overrides "{\"spec\":{\"dnsConfig\":{\"nameservers\":[\"${K8GB_COREDNS_IP}\"]},\"dnsPolicy\":\"None\"}}" \
    -- curl $HOSTNAME -v
* Trying 172.21.0.3:80...
* Connected to liqo.cloud.example.com (172.21.0.3) port 80 (#0)
> GET / HTTP/1.1
> Host: liqo.cloud.example.com
> User-Agent: curl/7.82.0-DEV
> Accept: */*
>
* Mark bundle as not supporting multiuse
< HTTP/1.1 200 OK
< Date: Fri, 11 Nov 2022 21:55:06 GMT
< Content-Type: application/json; charset=utf-8
< Content-Length: 392
< Connection: keep-alive
< X-Content-Type-Options: nosniff
<
{
  "hostname": "podinfo-68f5575b95-vlbgp",
  "version": "6.2.3",
  "revision": "8615cb75d926ea0ba5353b1d56867868c737bf5e",
  "color": "#34577c",
  "logo": "https://raw.githubusercontent.com/stefanprodan/podinfo/gh-pages/cuddle_clap.gif",
  "message": "greetings from podinfo v6.2.3",
  "goos": "linux",
  "goarch": "amd64",
  "runtime": "go1.19.3",
  "num_goroutine": "8",
  "num_cpu": "8"
* Connection #0 to host liqo.cloud.example.com left intact
}pod "curl" deleted

root@k8gb:~/liqo/examples/global-ingress# kubectl run -it --rm curl --restart=Never --image=curlimages/curl:7.82.0 --command \
    --overrides "{\"spec\":{\"dnsConfig\":{\"nameservers\":[\"${K8GB_COREDNS_IP}\"]},\"dnsPolicy\":\"None\"}}" \
    -- curl $HOSTNAME -v
* Trying 172.21.0.4:80...
* Connected to liqo.cloud.example.com (172.21.0.4) port 80 (#0)
> GET / HTTP/1.1
> Host: liqo.cloud.example.com
> User-Agent: curl/7.82.0-DEV
> Accept: */*
>
* Mark bundle as not supporting multiuse
< HTTP/1.1 200 OK
< Date: Fri, 11 Nov 2022 21:55:31 GMT
< Content-Type: application/json; charset=utf-8
< Content-Length: 392
< Connection: keep-alive
< X-Content-Type-Options: nosniff
<
{
  "hostname": "podinfo-68f5575b95-wqqbg",
  "version": "6.2.3",
  "revision": "8615cb75d926ea0ba5353b1d56867868c737bf5e",
  "color": "#34577c",
  "logo": "https://raw.githubusercontent.com/stefanprodan/podinfo/gh-pages/cuddle_clap.gif",
  "message": "greetings from podinfo v6.2.3",
  "goos": "linux",
  "goarch": "amd64",
  "runtime": "go1.19.3",
  "num_goroutine": "8",
  "num_cpu": "8"
* Connection #0 to host liqo.cloud.example.com left intact
}pod "curl" deleted

En lançant ce pod plusieurs fois, on peut voir différentes adresses IP et différents pods frontaux en réponse (comme défini dans la politique du GSLB en outre ici K8GB) …

Il est possible de coupler K8GB avec un autre projet open source : Admiralty

• Quick Start | Admiralty
• GitHub - admiraltyio/admiralty: A system of Kubernetes controllers that intelligently schedules workloads across clusters.

En effet, la combinaison de K8GB et d’Admiralty offre de puissantes capacités globales en mode multi-clusters. Admiralty va programmer globalement les ressources. Et K8GB assurera l’équilibrage au niveau mondial comme le montre cet exemple =>

Integration with Admiralty

La capacité d’équilibrer la charge des requêtes HTTP sur plusieurs clusters Kubernetes, s’exécutant dans plusieurs centres de données/clouds est une exigence clé pour un système résilient.

Et il ne semble pas exister beaucoup de solution open source GSLB (Global Server Load Balancer) existante qui prenne en charge cette exigence de manière native dans le cloud et conviviale pour Kubernetes. D’ailleurs, les projets suivants représentent des exemples d’autres mises en œuvre de la GSLB qui pourraient être exploités ou utilisés comme référence :

Open Source =>

• GitHub - polaris-gslb/polaris-gslb: A free, open source GSLB (Global Server Load Balancing) solution.
• GitHub - AlekseyChudov/powergslb: PowerGSLB - PowerDNS Remote GSLB Backend
• GitHub - datianshi/opensource-gslb

Commercial =>

• What is Global Server Load Balancing? Definition & FAQs | Avi Networks
• Global Server Load Balancing
• DNS Traffic Control | Accelerate Application Delivery & Performance
• Deploying OpenShift Applications to Multiple Datacenters

À suivre !
