I'm an Expert in Memory Management & Segfaults, Ask Me Anything!

I'm an expert-level C and C++ developer, with a specialty in memory management. I have experience writing memory-safe code with both the modern safe techniques and the ancient unsafe techniques. I've used malloc and free without killing myself. I love pointers. I've debugged more than my share of undefined behavior, and authored the canonical StackOverflow question on segfault debugging.

Any burning questions about dynamic allocation, undefined behavior, pointers, memory safety, or anything even remotely related? Ask me anything!

(My main languages are C++, C, and Python, although I also deeply grok the underlying computer science principles.)

Discussion (151)

Collapse
kyrlon profile image
kyrlon

Hello Jason! I am encountering a peculiar issue. On one system after compiling I am getting no errors with pthreads in C++. On the second I am running across a Segfault

[Thread 0x7ffff4ccc700 (LWP 1735) exited]

Thread 2 "a.out" received signal SIGABRT, Aborted.
[Switching to Thread 0x7ffff54cd700 (LWP 1734)]
__GI_raise (sig=sig@entry=6) at ../sysdeps/unix/sysv/linux/raise.c:50
50      ../sysdeps/unix/sysv/linux/raise.c: No such file or directory.

On the other I am recieving no errors. My wild guess is that the issue might stem from the systems having different kernels:

No Problems:
cat /proc/version
Linux version 4.15.0-29-generic (buildd@lgw01-amd64-057) (gcc version 7.3.0 (Ubuntu 7.3.0-16ubuntu3)) #31-Ubuntu SMP Tue Jul 17 15:39:52 UTC 2018

Problems(SegFault):
cat /proc/version
Linux version 5.4.0-42-generic (buildd@lgw01-amd64-038) (gcc version 9.3.0 (Ubuntu 9.3.0-10ubuntu2)) #46-Ubuntu SMP Fri Jul 10 00:24:02 UTC 2020

Please let me know if any other information is needed

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything

Every time I see "No such file or directory," the first thing I check is the path. What is the current working directory from which you're running a.out, and does the path ../sysdeps/unix/sysv/linux/raise.c indeed exist relative to that working directory? (Remember that .. means "parent directory".)

Collapse
kyrlon profile image
kyrlon

My working path is the same as the pwd for where I am running a.out. In this case it would be something on the lines of /home/red/recorder. I have no idea of where the path ../sysdeps/unix/sysv/linux/raise.c is coming from, so I would say no it does not exist. I am assuming it is a segfault of some variant when I receive a response of double free or corruption (out) and Aborted (core dumped).

Thread Thread
kyrlon profile image
kyrlon

I can provide a recent valgrind and or gdb bt if needed.

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

Yeah, that relative path is spooky.

To diagnose the double free or corrupted, you'd want to run your program through Valgrind. Meanwhile, you may need to use gdb to step through your program (compiled with -g) to determine precisely when control leaves your code, onward to the abort.

Thread Thread
kyrlon profile image
kyrlon

Alright the first block is a gdb output with a backtrace:


gdb ./a.out                                                                                                                                                                                       [0/0]
GNU gdb (Ubuntu 9.1-0ubuntu1) 9.1
Copyright (C) 2020 Free Software Foundation, Inc.
License GPLv3+: GNU GPL version 3 or later <http://gnu.org/licenses/gpl.html>
This is free software: you are free to change and redistribute it.
There is NO WARRANTY, to the extent permitted by law.
Type "show copying" and "show warranty" for details.
This GDB was configured as "x86_64-linux-gnu".
Type "show configuration" for configuration details.
For bug reporting instructions, please see:
<http://www.gnu.org/software/gdb/bugs/>.
Find the GDB manual and other documentation resources online at:
    <http://www.gnu.org/software/gdb/documentation/>.

For help, type "help".
Type "apropos word" to search for commands related to "word"...
Reading symbols from ./a.out...
(gdb) run
Starting program: /home/red/recorder/sidekiq/a.out
[Thread debugging using libthread_db enabled]
Using host libthread_db library "/lib/x86_64-linux-gnu/libthread_db.so.1".
this is the current epoch:  1598981433
Waiting for pps epoch
Info: configured 1PPS source to 1
[New Thread 0x7ffff54cd700 (LWP 4245)]
[New Thread 0x7ffff4ccc700 (LWP 4246)]
Info: starting 0 Rx handle(s) for card 0 on next 1PPS pulse
Info: streaming started on card 0
Error: timestamp error for card 0 handle A1 (blk 0) ... expected 0x0000000000000000 but got 0x0000000000000004 (delta 4)
Info: all 0 card(s) started streaming
Info: sleeping for 3 seconds
Info: signaling to all 1 card(s) to stop streaming
Info: waiting for control thread for card 0
Info: stopping 0 Rx handle(s) on card 0 on next 1PPS pulse
Info: streaming stopped on card 0
double free or corruption (out)
Info: waiting for receive thread for card 0
[Thread 0x7ffff4ccc700 (LWP 4246) exited]

Thread 2 "a.out" received signal SIGABRT, Aborted.
[Switching to Thread 0x7ffff54cd700 (LWP 4245)]
__GI_raise (sig=sig@entry=6) at ../sysdeps/unix/sysv/linux/raise.c:50
50      ../sysdeps/unix/sysv/linux/raise.c: No such file or directory.
(gdb) bt
#0  __GI_raise (sig=sig@entry=6) at ../sysdeps/unix/sysv/linux/raise.c:50
#1  0x00007ffff74f9859 in __GI_abort () at abort.c:79
#2  0x00007ffff75643ee in __libc_message (action=action@entry=do_abort, fmt=fmt@entry=0x7ffff768e285 "%s\n") at ../sysdeps/posix/libc_fatal.c:155
#3  0x00007ffff756c47c in malloc_printerr (str=str@entry=0x7ffff7690670 "double free or corruption (out)") at malloc.c:5347
#4  0x00007ffff756e120 in _int_free (av=0x7ffff76bfb80 <main_arena>, p=0x7ffff0000b50, have_lock=<optimized out>) at malloc.c:4314
#5  0x0000555555566af0 in __gnu_cxx::new_allocator<int>::deallocate (this=<synthetic pointer>, __p=0x7ffff0000b60) at /usr/include/c++/9/ext/new_allocator.h:119
#6  std::allocator_traits<std::allocator<int> >::deallocate (__a=<synthetic pointer>..., __n=<optimized out>, __p=0x7ffff0000b60) at /usr/include/c++/9/bits/alloc_traits.h:470
#7  std::_Vector_base<int, std::allocator<int> >::_M_deallocate (this=<synthetic pointer>, __n=<optimized out>, __p=0x7ffff0000b60) at /usr/include/c++/9/bits/stl_vector.h:351
#8  std::_Vector_base<int, std::allocator<int> >::~_Vector_base (this=<synthetic pointer>, __in_chrg=<optimized out>) at /usr/include/c++/9/bits/stl_vector.h:332
#9  std::vector<int, std::allocator<int> >::~vector (this=<synthetic pointer>, __in_chrg=<optimized out>) at /usr/include/c++/9/bits/stl_vector.h:680
#10 sidekiq_class::receive_data (card=0 '\000', p_rconfig=<optimized out>) at src/testing_cpp.cpp:598
#11 0x0000555555567cf8 in sidekiq_class::receive_run (data=<optimized out>) at src/testing_cpp.cpp:705
#12 0x00007ffff7a27609 in start_thread (arg=<optimized out>) at pthread_create.c:477
#13 0x00007ffff75f6103 in clone () at ../sysdeps/unix/sysv/linux/x86_64/clone.S:95
Thread Thread
kyrlon profile image
kyrlon

This is the valgrind dump (sorry for double comment; couldn't get the markdown to capture all of the code cleanly):



valgrind --leak-check=yes --track-origins=yes ./a.out
==4364== Memcheck, a memory error detector
==4364== Copyright (C) 2002-2017, and GNU GPL'd, by Julian Seward et al.
==4364== Using Valgrind-3.15.0 and LibVEX; rerun with -h for copyright info
==4364== Command: ./a.out
==4364==
Error: unable to initialize libsidekiq with status -16
==4364==
==4364== HEAP SUMMARY:
==4364==     in use at exit: 0 bytes in 0 blocks
==4364==   total heap usage: 5 allocs, 5 frees, 75,144 bytes allocated
==4364==
==4364== All heap blocks were freed -- no leaks are possible
==4364==
==4364== For lists of detected and suppressed errors, rerun with: -s
==4364== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
red@red-NUC8v5PNK:~/recorder/sidekiq$ valgrind --leak-check=yes --track-origins=yes ./a.out
==4367== Memcheck, a memory error detector
==4367== Copyright (C) 2002-2017, and GNU GPL'd, by Julian Seward et al.
==4367== Using Valgrind-3.15.0 and LibVEX; rerun with -h for copyright info
==4367== Command: ./a.out
==4367==
this is the current epoch:  1598982515
Waiting for pps epoch
Info: configured 1PPS source to 1
Info: starting 0 Rx handle(s) for card 0 on next 1PPS pulse
Info: streaming started on card 0
==4367== Thread 2:
==4367== Conditional jump or move depends on uninitialised value(s)
==4367==    at 0x11B078: sidekiq_class::update_rx_stats(sidekiq_class::rx_stats*, skiq_rx_block_t*) (testing_cpp.cpp:569)
==4367==    by 0x11B95F: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:646)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
==4367== Conditional jump or move depends on uninitialised value(s)
==4367==    at 0x11B964: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:647)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
==4367== Conditional jump or move depends on uninitialised value(s)
==4367==    at 0x11B97C: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:657)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
==4367== Use of uninitialised value of size 8
==4367==    at 0x51AB7BA: _itoa_word (_itoa.c:180)
==4367==    by 0x51C76F4: __vfprintf_internal (vfprintf-internal.c:1687)
==4367==    by 0x51CA021: buffered_vfprintf (vfprintf-internal.c:2377)
==4367==    by 0x51C6EA3: __vfprintf_internal (vfprintf-internal.c:1346)
==4367==    by 0x527E022: __fprintf_chk (fprintf_chk.c:33)
==4367==    by 0x11B9CD: fprintf (stdio2.h:100)
==4367==    by 0x11B9CD: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:662)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
==4367== Conditional jump or move depends on uninitialised value(s)
==4367==    at 0x51AB7CC: _itoa_word (_itoa.c:180)
==4367==    by 0x51C76F4: __vfprintf_internal (vfprintf-internal.c:1687)
==4367==    by 0x51CA021: buffered_vfprintf (vfprintf-internal.c:2377)
==4367==    by 0x51C6EA3: __vfprintf_internal (vfprintf-internal.c:1346)
==4367==    by 0x527E022: __fprintf_chk (fprintf_chk.c:33)
==4367==    by 0x11B9CD: fprintf (stdio2.h:100)
==4367==    by 0x11B9CD: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:662)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
==4367== Conditional jump or move depends on uninitialised value(s)
==4367==    at 0x51C83A8: __vfprintf_internal (vfprintf-internal.c:1687)
==4367==    by 0x51CA021: buffered_vfprintf (vfprintf-internal.c:2377)
==4367==    by 0x51C6EA3: __vfprintf_internal (vfprintf-internal.c:1346)
==4367==    by 0x527E022: __fprintf_chk (fprintf_chk.c:33)
==4367==    by 0x11B9CD: fprintf (stdio2.h:100)
==4367==    by 0x11B9CD: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:662)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
==4367== Conditional jump or move depends on uninitialised value(s)
==4367==    at 0x51C786E: __vfprintf_internal (vfprintf-internal.c:1687)
==4367==    by 0x51CA021: buffered_vfprintf (vfprintf-internal.c:2377)
==4367==    by 0x51C6EA3: __vfprintf_internal (vfprintf-internal.c:1346)
==4367==    by 0x527E022: __fprintf_chk (fprintf_chk.c:33)
==4367==    by 0x11B9CD: fprintf (stdio2.h:100)
==4367==    by 0x11B9CD: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:662)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
==4367== Conditional jump or move depends on uninitialised value(s)
==4367==    at 0x51C7AD8: __vfprintf_internal (vfprintf-internal.c:1687)
==4367==    by 0x51CA021: buffered_vfprintf (vfprintf-internal.c:2377)
==4367==    by 0x51C6EA3: __vfprintf_internal (vfprintf-internal.c:1346)
==4367==    by 0x527E022: __fprintf_chk (fprintf_chk.c:33)
==4367==    by 0x11B9CD: fprintf (stdio2.h:100)
==4367==    by 0x11B9CD: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:662)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
==4367== Use of uninitialised value of size 8
==4367==    at 0x51AB81B: _itoa_word (_itoa.c:179)
==4367==    by 0x51C76F4: __vfprintf_internal (vfprintf-internal.c:1687)
==4367==    by 0x51CA021: buffered_vfprintf (vfprintf-internal.c:2377)
==4367==    by 0x51C6EA3: __vfprintf_internal (vfprintf-internal.c:1346)
==4367==    by 0x527E022: __fprintf_chk (fprintf_chk.c:33)
==4367==    by 0x11B9CD: fprintf (stdio2.h:100)
==4367==    by 0x11B9CD: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:662)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
==4367== Conditional jump or move depends on uninitialised value(s)
==4367==    at 0x51AB82D: _itoa_word (_itoa.c:179)
==4367==    by 0x51C76F4: __vfprintf_internal (vfprintf-internal.c:1687)
==4367==    by 0x51CA021: buffered_vfprintf (vfprintf-internal.c:2377)
==4367==    by 0x51C6EA3: __vfprintf_internal (vfprintf-internal.c:1346)
==4367==    by 0x527E022: __fprintf_chk (fprintf_chk.c:33)
==4367==    by 0x11B9CD: fprintf (stdio2.h:100)
==4367==    by 0x11B9CD: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:662)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Uninitialised value was created by a stack allocation
==4367==    at 0x11B860: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:596)
==4367==
Error: timestamp error for card 0 handle A1 (blk 0) ... expected 0x0000000000000000 but got 0x0000000003938724 (delta 60000036)
Info: all 0 card(s) started streaming
Info: sleeping for 3 seconds
Info: signaling to all 1 card(s) to stop streaming
Info: waiting for control thread for card 0
Info: stopping 0 Rx handle(s) on card 0 on next 1PPS pulse
==4367== Invalid read of size 2
==4367==    at 0x11BB31: __copy_m<short int volatile*, int*> (stl_algobase.h:340)
==4367==    by 0x11BB31: __copy_move_a<false, short int volatile*, int*> (stl_algobase.h:404)
==4367==    by 0x11BB31: __copy_move_a2<false, short int volatile*, int*> (stl_algobase.h:440)
==4367==    by 0x11BB31: copy<short int volatile*, int*> (stl_algobase.h:474)
==4367==    by 0x11BB31: _M_assign_aux<short int volatile*> (vector.tcc:321)
==4367==    by 0x11BB31: _M_assign_dispatch<short int volatile*> (stl_vector.h:1625)
==4367==    by 0x11BB31: assign<short int volatile*> (stl_vector.h:766)
==4367==    by 0x11BB31: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:674)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Address 0x7745000 is 0 bytes after a block of size 33,554,432 alloc'd
==4367==    at 0x483E0F0: memalign (in /usr/lib/x86_64-linux-gnu/valgrind/vgpreload_memcheck-amd64-linux.so)
==4367==    by 0x483E212: posix_memalign (in /usr/lib/x86_64-linux-gnu/valgrind/vgpreload_memcheck-amd64-linux.so)
==4367==    by 0x17A722: DmaInterfaceInit (in /home/red/recorder/sidekiq/a.out)
==4367==    by 0x3: ???
==4367==    by 0x1FFF00002F: ???
==4367==    by 0x3FFF: ???
==4367==    by 0x53560BF: ???
==4367==    by 0x7FF: ???
==4367==
==4367== Invalid read of size 2
==4367==    at 0x11BB20: __copy_m<short int volatile*, int*> (stl_algobase.h:342)
==4367==    by 0x11BB20: __copy_move_a<false, short int volatile*, int*> (stl_algobase.h:404)
==4367==    by 0x11BB20: __copy_move_a2<false, short int volatile*, int*> (stl_algobase.h:440)
==4367==    by 0x11BB20: copy<short int volatile*, int*> (stl_algobase.h:474)
==4367==    by 0x11BB20: _M_assign_aux<short int volatile*> (vector.tcc:321)
==4367==    by 0x11BB20: _M_assign_dispatch<short int volatile*> (stl_vector.h:1625)
==4367==    by 0x11BB20: assign<short int volatile*> (stl_vector.h:766)
==4367==    by 0x11BB20: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:674)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==  Address 0x7745002 is 2 bytes after a block of size 33,554,432 alloc'd
==4367==    at 0x483E0F0: memalign (in /usr/lib/x86_64-linux-gnu/valgrind/vgpreload_memcheck-amd64-linux.so)
==4367==    by 0x483E212: posix_memalign (in /usr/lib/x86_64-linux-gnu/valgrind/vgpreload_memcheck-amd64-linux.so)
==4367==    by 0x17A722: DmaInterfaceInit (in /home/red/recorder/sidekiq/a.out)
==4367==    by 0x3: ???
==4367==    by 0x1FFF00002F: ???
==4367==    by 0x3FFF: ???
==4367==    by 0x53560BF: ???
==4367==    by 0x7FF: ???
==4367==
==4367==
==4367== Process terminating with default action of signal 11 (SIGSEGV)
==4367==  Bad permissions for mapped region at address 0x7746000
==4367==    at 0x11BB31: __copy_m<short int volatile*, int*> (stl_algobase.h:340)
==4367==    by 0x11BB31: __copy_move_a<false, short int volatile*, int*> (stl_algobase.h:404)
==4367==    by 0x11BB31: __copy_move_a2<false, short int volatile*, int*> (stl_algobase.h:440)
==4367==    by 0x11BB31: copy<short int volatile*, int*> (stl_algobase.h:474)
==4367==    by 0x11BB31: _M_assign_aux<short int volatile*> (vector.tcc:321)
==4367==    by 0x11BB31: _M_assign_dispatch<short int volatile*> (stl_vector.h:1625)
==4367==    by 0x11BB31: assign<short int volatile*> (stl_vector.h:766)
==4367==    by 0x11BB31: sidekiq_class::receive_data(unsigned char, sidekiq_class::radio_config*) (testing_cpp.cpp:674)
==4367==    by 0x11BCF7: sidekiq_class::receive_run(void*) (testing_cpp.cpp:705)
==4367==    by 0x4DDB608: start_thread (pthread_create.c:477)
==4367==    by 0x526F102: clone (clone.S:95)
==4367==
==4367== HEAP SUMMARY:
==4367==     in use at exit: 33,633,366 bytes in 188 blocks
==4367==   total heap usage: 197 allocs, 9 frees, 33,839,742 bytes allocated
==4367==
==4367== Thread 1:
==4367== 288 bytes in 1 blocks are possibly lost in loss record 8 of 16
==4367==    at 0x483DD99: calloc (in /usr/lib/x86_64-linux-gnu/valgrind/vgpreload_memcheck-amd64-linux.so)
==4367==    by 0x40149CA: allocate_dtv (dl-tls.c:286)
==4367==    by 0x40149CA: _dl_allocate_tls (dl-tls.c:532)
==4367==    by 0x4DDC322: allocate_stack (allocatestack.c:622)
==4367==    by 0x4DDC322: pthread_create@@GLIBC_2.2.5 (pthread_create.c:660)
==4367==    by 0x11B58C: sidekiq_class::read_iq_on_pps(unsigned long, unsigned long) (testing_cpp.cpp:314)
==4367==    by 0x11AC73: main (testing_cpp.cpp:845)
==4367==
==4367== 288 bytes in 1 blocks are possibly lost in loss record 9 of 16
==4367==    at 0x483DD99: calloc (in /usr/lib/x86_64-linux-gnu/valgrind/vgpreload_memcheck-amd64-linux.so)
==4367==    by 0x40149CA: allocate_dtv (dl-tls.c:286)
==4367==    by 0x40149CA: _dl_allocate_tls (dl-tls.c:532)
==4367==    by 0x4DDC322: allocate_stack (allocatestack.c:622)
==4367==    by 0x4DDC322: pthread_create@@GLIBC_2.2.5 (pthread_create.c:660)
==4367==    by 0x11B5A2: sidekiq_class::read_iq_on_pps(unsigned long, unsigned long) (testing_cpp.cpp:316)
==4367==    by 0x11AC73: main (testing_cpp.cpp:845)
==4367==
==4367== LEAK SUMMARY:
==4367==    definitely lost: 0 bytes in 0 blocks
==4367==    indirectly lost: 0 bytes in 0 blocks
==4367==      possibly lost: 576 bytes in 2 blocks
==4367==    still reachable: 33,632,790 bytes in 186 blocks
==4367==         suppressed: 0 bytes in 0 blocks
==4367== Reachable blocks (those to which a pointer was found) are not shown.
==4367== To see them, rerun with: --leak-check=full --show-leak-kinds=all
==4367==
==4367== For lists of detected and suppressed errors, rerun with: -s
==4367== ERROR SUMMARY: 17000 errors from 14 contexts (suppressed: 0 from 0)
Segmentation fault (core dumped)
Thread Thread
kyrlon profile image
kyrlon

The most puzzling part is that I get this error on one system but not the other:

No Problems:
cat /proc/version
Linux version 4.15.0-29-generic (buildd@lgw01-amd64-057) (gcc version 7.3.0 (Ubuntu 7.3.0-16ubuntu3)) #31-Ubuntu SMP Tue Jul 17 15:39:52 UTC 2018

Problems(SegFault):
cat /proc/version
Linux version 5.4.0-42-generic (buildd@lgw01-amd64-038) (gcc version 9.3.0 (Ubuntu 9.3.0-10ubuntu2)) #46-Ubuntu SMP Fri Jul 10 00:24:02 UTC 2020

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

You must remember that undefined behavior is exactly that. It may appear to work, and then not work elsewhere. When it doesn't work, anything could happen, including "making demons fly out your nose". So, I'd start by going through that Valgrind output, bit by bit, and fixing each problem in your code it highlights. (The error and location of that error in your code is on the last line of each traceback block in Valgrind.)

Once your //own// code runs Valgrind pure, we can tackle any remaining weirdness.

Thread Thread
kyrlon profile image
kyrlon

After furious placements of std::cout everywhere, I discovered that my function that my thread was calling was missing its return statement. Not sure how my first system was able to bypass that issue but it arised on my second system.

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

So, it's resolved, then?

Thread Thread
kyrlon profile image
kyrlon

The issue yes. My curiosity, not so much lol. It shouldn't have compiled however that behavior I believe isactually allowed, it's grandfathered in from C. Since the function returns a variable and a return is not explicitly called then the first value in the stack frame is reinterpreted as the return type and returned instead

int foo(int bar) {
int blah= 8;
blah += 4;
int zayxxy = 0;
} //returns 12

So I believe that is the reason how my first system was able to execute without any problems. However, I do not fully understand how on the second system the function was never able to terminate the function but stay stuck in a while loop and result in a segfault.

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

What you described, not returning a value from a non-void function, is actually undefined behavior in C. Therefore, once again, it is legal for the compiler to make demons fly out your nose. Anything can happen. There is no rhyme or reason.

Here's C99 on it — ISO/IEC 9899:1999, section 6.9.1 paragraph 12:

If the } that terminates a function is reached, and the value of the function call is used by the caller, the behavior is undefined.

One system's compiler was able to figure it out anyway, and it worked, which is legal (because anything is). The other system's compiler was not, and it had a snit.

P.S. Thanks for asking! I learned something new today, namely that the above is undefined behavior.

Thread Thread
kyrlon profile image
kyrlon

Glad I could help! I have definitely learned alot from this experience as well!

Thread Thread
ac000 profile image
Andrew Clayton

OK, firstly, a small nitpick, you weren't getting a segfault (SIGSEGV) but a SIGABRT

As for failing to return a value from a non-void function, you should at the very least compile with -Wall, which would have caught that. e.g

/* n.c - no return from non-void function */

static int test(void)
{
}
$ gcc -c n.c
$

vs

$ gcc -Wall -c n.c
n.c: In function ‘test’:
n.c:5:1: warning: no return statement in function returning non-void [-Wreturn-type]
    5 | }
      | ^
At top level:
n.c:3:12: warning: ‘test’ defined but not used [-Wunused-function]
    3 | static int test(void)
      |            ^~~~
$

And of course we also get the second warning...

I always compile with at least '-Wall -Wextra'

Collapse
rishabh900 profile image
all_yours

Hello, I am learning robotics and using ros-kinetic with gazebo7. I am trying to launch my model in gazebo but got stuck on a "segmentation fault(core dump)" error at

0x00007fffc96ac0ed in ros::NodeHandle::destruct() ()
from /opt/ros/kinetic/lib/libroscpp.so

Kindly advice

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything

There are only two ways to debug a segmentation fault, ordinarily:

1) If you have access to the source code for ros-kinetic, you would need to compile it yourself with the -g flag (debug flag), and then try to use it the same way as before. Then, when the segfault occurs, you'll get a file and line number instead of the raw memory address (0x00007fffc96ac0ed), and that will tell you where in the code the segfault is (probably) happening from.

2) To get more information, you can run the code (again, compiled with -g) through a dynamic memory analyser like Valgrind. That will not only give you the file and line number where the segfault is probably occurring, but also a hint about what's going on, and possibly a longer stack track.

Given the information from (1) or (2) (and a snippet of the offending source code), I could probably help you from there.

However, if ros-kinetic is not your project, you'll be best off filing a bug report on their issue tracker.

Collapse
rishabh900 profile image
all_yours • Edited

Thanks for the advice. I did compile ros-kinetic from source but now gdb wasn't launching, I don't know why. So i reinstalled ros-kinetic from apt and ran it, gdb was working. Well I did find the source file for the function pointing to segmentation fault :-

void NodeHandle::destruct()
{
  delete collection_;

  boost::mutex::scoped_lock lock(g_nh_refcount_mutex);

  --g_nh_refcount;

  if (g_nh_refcount == 0 && g_node_started_by_nh)
  {
    ros::shutdown();
  }
}

The backtrace went till 24 frames I could provide them too if the fault is not in this part of code.
If you could help me find the error it would really boost my learning.

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

The stack trace would be really helpful. Also, please be sure to precede your code example with three backticks (`) on the line above the example, and three on the line below.

Thread Thread
rishabh900 profile image
all_yours

The stack trace is here :-

#0  0x00007fffc96ac0ed in ros::NodeHandle::destruct() ()
   from /opt/ros/kinetic/lib/libroscpp.so

#1  0x00007fffc96ac269 in ros::NodeHandle::~NodeHandle() ()
   from /opt/ros/kinetic/lib/libroscpp.so

#2  0x00007fff101bf4b4 in realtime_tools::RealtimePublisher<pr2_mechanism_msgs::MechanismStatistics_<std::allocator<void> > >::~RealtimePublisher (
    this=0x7fff0d7a1508, __in_chrg=<optimized out>)
    at /opt/ros/kinetic/include/realtime_tools/realtime_publisher.h:84

#3  pr2_controller_manager::ControllerManager::~ControllerManager (
    this=0x7fff0d7a0e80, __in_chrg=<optimized out>)
    at /home/deadmanlogan/i_am_from_source/ros_catkin_ws/src/pr2_mechanism/pr2_controller_manager/src/controller_manager.cpp:63

#4  0x00007fff101bfed9 in pr2_controller_manager::ControllerManager::~ControllerManager (this=0x7fff0d7a0e80, __in_chrg=<optimized out>)
    at /home/deadmanlogan/i_am_from_source/ros_catkin_ws/src/pr2_mechanism/pr2_controller_manager/src/controller_manager.cpp:67

#5  0x00007fff104ab96a in gazebo::GazeboRosControllerManager::~GazeboRosControllerManager (this=0x7fff0d7a0960, __in_chrg=<optimized out>)
    at /home/deadmanlogan/i_am_from_source/ros_catkin_ws/src/pr2_simulator/pr2_gazebo_plugins/src/gazebo_ros_controller_manager.cpp:85

#6  0x00007fff104abaf6 in gazebo::GazeboRosControllerManager::~GazeboRosControllerManager (this=0x7fff0d7a0960, __in_chrg=<optimized out>)
    at /home/deadmanlogan/i_am_from_source/ros_catkin_ws/src/pr2_simulator/pr2_g---Type <return> to continue, or q <return> to quit---
azebo_plugins/src/gazebo_ros_controller_manager.cpp:94

#7  0x00007ffff5ba80c9 in boost::checked_delete<gazebo::ModelPlugin> (
    x=0x7fff0d7a0960) at /usr/include/boost/core/checked_delete.hpp:34

#8  0x00007ffff5baadd6 in boost::detail::sp_counted_impl_p<gazebo::ModelPlugin>::dispose (this=0x7fff2e023430)
    at /usr/include/boost/smart_ptr/detail/sp_counted_impl.hpp:78

#9  0x00007ffff59b4efe in boost::detail::sp_counted_base::release (
    this=0x7fff2e023430)
    at /usr/include/boost/smart_ptr/detail/sp_counted_base_gcc_x86.hpp:146

#10 0x00007ffff59b4f91 in boost::detail::shared_count::~shared_count (
    this=0x7fff63ffb3d8, __in_chrg=<optimized out>)
    at /usr/include/boost/smart_ptr/detail/shared_count.hpp:443

#11 0x00007ffff5b9f086 in boost::shared_ptr<gazebo::ModelPlugin>::~shared_ptr (
    this=0x7fff63ffb3d0, __in_chrg=<optimized out>)
    at /usr/include/boost/smart_ptr/shared_ptr.hpp:323

#12 0x00007ffff5b9a392 in gazebo::physics::Model::LoadPlugin (
    this=0x7fff3c24d3b0, _sdf=std::shared_ptr (count 3, weak 5) 0x7fff368df840)
    at /home/deadmanlogan/i_am_from_source/Gazebo-7/gazebo/physics/Model.cc:1002

#13 0x00007ffff5b999e2 in gazebo::physics::Model::LoadPlugins (
    this=0x7fff3c24d3b0)
    at /home/deadmanlogan/i_am_from_source/Gazebo-7/gazebo/physics/Model.cc:915

#14 0x00007ffff5c08bd9 in gazebo::physics::World::ProcessFactoryMsgs (this=0x14f2480)
    at /home/deadmanlogan/i_am_from_source/Gazebo-7/gazebo/physics/World.cc:1958

#15 0x00007ffff5c0b9de in gazebo::physics::World::ProcessMessages (
    this=0x14f2480)
    at /home/deadmanlogan/i_am_from_source/Gazebo-7/gazebo/physics/World.cc:2282

#16 0x00007ffff5c0069f in gazebo::physics::World::Step (this=0x14f2480)
    at /home/deadmanlogan/i_am_from_source/Gazebo-7/gazebo/physics/World.cc:688

#17 0x00007ffff5bff06c in gazebo::physics::World::RunLoop (this=0x14f2480)
    at /home/deadmanlogan/i_am_from_source/Gazebo-7/gazebo/physics/World.cc:481

#18 0x00007ffff5c2e413 in boost::_mfi::mf0<void, gazebo::physics::World>::operator() (this=0x128c3b8, p=0x14f2480)
    at /usr/include/boost/bind/mem_fn_template.hpp:49

#19 0x00007ffff5c2d4be in boost::_bi::list1<boost::_bi::value<gazebo::physics::World*> >::operator()<boost::_mfi::mf0<void, gazebo::physics::World>, boost::_bi::list0> (this=0x128c3c8, f=..., a=...) at /usr/include/boost/bind/bind.hpp:253

#20 0x00007ffff5c2b74a in boost::_bi::bind_t<void, boost::_mfi::mf0<void, gazebo::physics::World>, boost::_bi::list1<boost::_bi::value<gazebo::physics::World*> > >::operator() (this=0x128c3b8) at /usr/include/boost/bind/bind.hpp:893

#21 0x00007ffff5c3070a in boost::detail::thread_data<boost::_bi::bind_t<void, boost::_mfi::mf0<void, gazebo::physics::World>, boost::_bi::list1<boost::_bi::value<gazebo::physics::World*> > > >::run (this=0x128c200)at /usr/include/boost/thread/detail/thread.hpp:116

#22 0x00007ffff35c65d5 in boost::(anonymous namespace)::thread_proxy (
    param=<optimized out>) at libs/thread/src/pthread/thread.cpp:168

#23 0x00007ffff79086ba in start_thread (arg=0x7fff63ffd700)
    at pthread_create.c:333

#24 0x00007ffff64c741d in clone ()
    at ../sysdeps/unix/sysv/linux/x86_64/clone.S:109
Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

Awesome, and the code you posted earlier, is that the context for /opt/ros/kinetic/include/realtime_tools/realtime_publisher.h:84?

Also, what is the rest of the Valgrind output? Any more details? Segfaults have many causes, so knowing which one was detected helps narrow down the problem.

Thread Thread
rishabh900 profile image
all_yours

The code I posted earlier is the context for frame 1&2. Actually this is the gdb output which I posted.

Well I just ran the same in valgrind and it gave:-

deadmanlogan@war:~$ roslaunch pr2_description pr2.launch
... logging to /home/deadmanlogan/.ros/log/12f716ec-e077-11e9-af75-68071520849c/roslaunch-war-13334.log
Checking log directory for disk usage. This may take awhile.
Press Ctrl-C to interrupt
Done checking log file disk usage. Usage is <1GB.

xacro: Traditional processing is deprecated. Switch to --inorder processing!
To check for compatibility of your document, use option --check-order.
For more infos, see http://wiki.ros.org/xacro#Processing_Order
xacro.py is deprecated; please use xacro instead
started roslaunch server http://war:36573/

SUMMARY
========

PARAMETERS
 * /robo_state_publisher/publish_frequency: 30.0
 * /robot_description: <?xml version="1....
 * /rosdistro: kinetic
 * /rosversion: 1.12.14
 * /use_sim_time: True

NODES
  /
    gazebo (gazebo_ros/gzserver)
    robo_state_publisher (robot_state_publisher/robot_state_publisher)
    urdf_spawner (gazebo_ros/spawn_model)

auto-starting new master
process[master]: started with pid [13348]
ROS_MASTER_URI=http://localhost:11311

setting /run_id to 12f716ec-e077-11e9-af75-68071520849c
process[rosout-1]: started with pid [13361]
started core service [/rosout]
process[gazebo-2]: started with pid [13384]
process[urdf_spawner-3]: started with pid [13386]
process[robo_state_publisher-4]: started with pid [13387]
==13384== Memcheck, a memory error detector
==13384== Copyright (C) 2002-2015, and GNU GPL'd, by Julian Seward et al.
==13384== Using Valgrind-3.11.0 and LibVEX; rerun with -h for copyright info
==13384== Command: /home/deadmanlogan/i_am_from_source/ros_catkin_ws/src/gazebo_ros_pkgs/gazebo_ros/scripts/gzserver -e ode worlds/empty.world __name:=gazebo __log:=/home/deadmanlogan/.ros/log/12f716ec-e077-11e9-af75-68071520849c/gazebo-2.log
==13384==
SpawnModel script started
[INFO] [1569513769.345868, 0.000000]: Loading model XML from ros parameter
[INFO] [1569513769.363155, 0.000000]: Waiting for service /gazebo/spawn_urdf_model
==13447== Warning: invalid file descriptor -1 in syscall close()
==13448==
==13448== HEAP SUMMARY:
==13448==     in use at exit: 23,063 bytes in 127 blocks
==13448==   total heap usage: 220 allocs, 93 frees, 96,415 bytes allocated
==13448==
==13448== LEAK SUMMARY:
==13448==    definitely lost: 0 bytes in 0 blocks
==13448==    indirectly lost: 0 bytes in 0 blocks
==13448==      possibly lost: 0 bytes in 0 blocks
==13448==    still reachable: 23,063 bytes in 127 blocks
==13448==         suppressed: 0 bytes in 0 blocks
==13448== Rerun with --leak-check=full to see details of leaked memory
==13448==
==13448== For counts of detected and suppressed errors, rerun with: -v
==13448== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13447==
==13447== HEAP SUMMARY:
==13447==     in use at exit: 14,899 bytes in 127 blocks
==13447==   total heap usage: 219 allocs, 92 frees, 88,235 bytes allocated
==13447==
==13447== LEAK SUMMARY:
==13447==    definitely lost: 0 bytes in 0 blocks
==13447==    indirectly lost: 0 bytes in 0 blocks
==13447==      possibly lost: 0 bytes in 0 blocks
==13447==    still reachable: 14,899 bytes in 127 blocks
==13447==         suppressed: 0 bytes in 0 blocks
==13447== Rerun with --leak-check=full to see details of leaked memory
==13447==
==13447== For counts of detected and suppressed errors, rerun with: -v
==13447== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13450== Warning: invalid file descriptor -1 in syscall close()
==13451==
==13451== HEAP SUMMARY:
==13451==     in use at exit: 23,112 bytes in 129 blocks
==13451==   total heap usage: 226 allocs, 97 frees, 96,533 bytes allocated
==13451==
==13451== LEAK SUMMARY:
==13451==    definitely lost: 0 bytes in 0 blocks
==13451==    indirectly lost: 0 bytes in 0 blocks
==13451==      possibly lost: 0 bytes in 0 blocks
==13451==    still reachable: 23,112 bytes in 129 blocks
==13451==         suppressed: 0 bytes in 0 blocks
==13451== Rerun with --leak-check=full to see details of leaked memory
==13451==
==13451== For counts of detected and suppressed errors, rerun with: -v
==13451== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13450==
==13450== HEAP SUMMARY:
==13450==     in use at exit: 14,948 bytes in 129 blocks
==13450==   total heap usage: 225 allocs, 96 frees, 88,353 bytes allocated
==13450==
==13450== LEAK SUMMARY:
==13450==    definitely lost: 0 bytes in 0 blocks
==13450==    indirectly lost: 0 bytes in 0 blocks
==13450==      possibly lost: 0 bytes in 0 blocks
==13450==    still reachable: 14,948 bytes in 129 blocks
==13450==         suppressed: 0 bytes in 0 blocks
==13450== Rerun with --leak-check=full to see details of leaked memory
==13450==
==13450== For counts of detected and suppressed errors, rerun with: -v
==13450== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13453== Warning: invalid file descriptor -1 in syscall close()
==13454==
==13454== HEAP SUMMARY:
==13454==     in use at exit: 23,131 bytes in 129 blocks
==13454==   total heap usage: 231 allocs, 102 frees, 96,638 bytes allocated
==13454==
==13454== LEAK SUMMARY:
==13454==    definitely lost: 0 bytes in 0 blocks
==13454==    indirectly lost: 0 bytes in 0 blocks
==13454==      possibly lost: 0 bytes in 0 blocks
==13454==    still reachable: 23,131 bytes in 129 blocks
==13454==         suppressed: 0 bytes in 0 blocks
==13454== Rerun with --leak-check=full to see details of leaked memory
==13454==
==13454== For counts of detected and suppressed errors, rerun with: -v
==13454== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13453==
==13453== HEAP SUMMARY:
==13453==     in use at exit: 14,967 bytes in 129 blocks
==13453==   total heap usage: 230 allocs, 101 frees, 88,458 bytes allocated
==13453==
==13453== LEAK SUMMARY:
==13453==    definitely lost: 0 bytes in 0 blocks
==13453==    indirectly lost: 0 bytes in 0 blocks
==13453==      possibly lost: 0 bytes in 0 blocks
==13453==    still reachable: 14,967 bytes in 129 blocks
==13453==         suppressed: 0 bytes in 0 blocks
==13453== Rerun with --leak-check=full to see details of leaked memory
==13453==
==13453== For counts of detected and suppressed errors, rerun with: -v
==13453== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13456== Warning: invalid file descriptor -1 in syscall close()
==13457==
==13457== HEAP SUMMARY:
==13457==     in use at exit: 23,146 bytes in 129 blocks
==13457==   total heap usage: 236 allocs, 107 frees, 96,758 bytes allocated
==13457==
==13457== LEAK SUMMARY:
==13457==    definitely lost: 0 bytes in 0 blocks
==13457==    indirectly lost: 0 bytes in 0 blocks
==13457==      possibly lost: 0 bytes in 0 blocks
==13457==    still reachable: 23,146 bytes in 129 blocks
==13457==         suppressed: 0 bytes in 0 blocks
==13457== Rerun with --leak-check=full to see details of leaked memory
==13457==
==13457== For counts of detected and suppressed errors, rerun with: -v
==13457== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13456==
==13456== HEAP SUMMARY:
==13456==     in use at exit: 14,982 bytes in 129 blocks
==13456==   total heap usage: 235 allocs, 106 frees, 88,578 bytes allocated
==13456==
==13456== LEAK SUMMARY:
==13456==    definitely lost: 0 bytes in 0 blocks
==13456==    indirectly lost: 0 bytes in 0 blocks
==13456==      possibly lost: 0 bytes in 0 blocks
==13456==    still reachable: 14,982 bytes in 129 blocks
==13456==         suppressed: 0 bytes in 0 blocks
==13456== Rerun with --leak-check=full to see details of leaked memory
==13456==
==13456== For counts of detected and suppressed errors, rerun with: -v
==13456== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13460== Warning: invalid file descriptor -1 in syscall close()
==13461==
==13461== HEAP SUMMARY:
==13461==     in use at exit: 23,275 bytes in 131 blocks
==13461==   total heap usage: 242 allocs, 111 frees, 96,968 bytes allocated
==13461==
==13461== LEAK SUMMARY:
==13461==    definitely lost: 0 bytes in 0 blocks
==13461==    indirectly lost: 0 bytes in 0 blocks
==13461==      possibly lost: 0 bytes in 0 blocks
==13461==    still reachable: 23,275 bytes in 131 blocks
==13461==         suppressed: 0 bytes in 0 blocks
==13461== Rerun with --leak-check=full to see details of leaked memory
==13461==
==13461== For counts of detected and suppressed errors, rerun with: -v
==13461== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13460==
==13460== HEAP SUMMARY:
==13460==     in use at exit: 15,111 bytes in 131 blocks
==13460==   total heap usage: 241 allocs, 110 frees, 88,788 bytes allocated
==13460==
==13460== LEAK SUMMARY:
==13460==    definitely lost: 0 bytes in 0 blocks
==13460==    indirectly lost: 0 bytes in 0 blocks
==13460==      possibly lost: 0 bytes in 0 blocks
==13460==    still reachable: 15,111 bytes in 131 blocks
==13460==         suppressed: 0 bytes in 0 blocks
==13460== Rerun with --leak-check=full to see details of leaked memory
==13460==
==13460== For counts of detected and suppressed errors, rerun with: -v
==13460== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13463== Warning: invalid file descriptor -1 in syscall close()
==13464==
==13464== HEAP SUMMARY:
==13464==     in use at exit: 23,278 bytes in 131 blocks
==13464==   total heap usage: 247 allocs, 116 frees, 97,149 bytes allocated
==13464==
==13464== LEAK SUMMARY:
==13464==    definitely lost: 0 bytes in 0 blocks
==13464==    indirectly lost: 0 bytes in 0 blocks
==13464==      possibly lost: 0 bytes in 0 blocks
==13464==    still reachable: 23,278 bytes in 131 blocks
==13464==         suppressed: 0 bytes in 0 blocks
==13464== Rerun with --leak-check=full to see details of leaked memory
==13464==
==13464== For counts of detected and suppressed errors, rerun with: -v
==13464== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13463==
==13463== HEAP SUMMARY:
==13463==     in use at exit: 15,114 bytes in 131 blocks
==13463==   total heap usage: 246 allocs, 115 frees, 88,969 bytes allocated
==13463==
==13463== LEAK SUMMARY:
==13463==    definitely lost: 0 bytes in 0 blocks
==13463==    indirectly lost: 0 bytes in 0 blocks
==13463==      possibly lost: 0 bytes in 0 blocks
==13463==    still reachable: 15,114 bytes in 131 blocks
==13463==         suppressed: 0 bytes in 0 blocks
==13463== Rerun with --leak-check=full to see details of leaked memory
==13463==
==13463== For counts of detected and suppressed errors, rerun with: -v
==13463== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13466== Warning: invalid file descriptor -1 in syscall close()
==13467==
==13467== HEAP SUMMARY:
==13467==     in use at exit: 23,388 bytes in 131 blocks
==13467==   total heap usage: 252 allocs, 121 frees, 97,367 bytes allocated
==13467==
==13467== LEAK SUMMARY:
==13467==    definitely lost: 0 bytes in 0 blocks
==13467==    indirectly lost: 0 bytes in 0 blocks
==13467==      possibly lost: 0 bytes in 0 blocks
==13467==    still reachable: 23,388 bytes in 131 blocks
==13467==         suppressed: 0 bytes in 0 blocks
==13467== Rerun with --leak-check=full to see details of leaked memory
==13467==
==13467== For counts of detected and suppressed errors, rerun with: -v
==13467== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13466==
==13466== HEAP SUMMARY:
==13466==     in use at exit: 15,224 bytes in 131 blocks
==13466==   total heap usage: 251 allocs, 120 frees, 89,187 bytes allocated
==13466==
==13466== LEAK SUMMARY:
==13466==    definitely lost: 0 bytes in 0 blocks
==13466==    indirectly lost: 0 bytes in 0 blocks
==13466==      possibly lost: 0 bytes in 0 blocks
==13466==    still reachable: 15,224 bytes in 131 blocks
==13466==         suppressed: 0 bytes in 0 blocks
==13466== Rerun with --leak-check=full to see details of leaked memory
==13466==
==13466== For counts of detected and suppressed errors, rerun with: -v
==13466== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13469== Warning: invalid file descriptor -1 in syscall close()
==13470==
==13470== HEAP SUMMARY:
==13470==     in use at exit: 23,391 bytes in 131 blocks
==13470==   total heap usage: 257 allocs, 126 frees, 97,588 bytes allocated
==13470==
==13470== LEAK SUMMARY:
==13470==    definitely lost: 0 bytes in 0 blocks
==13470==    indirectly lost: 0 bytes in 0 blocks
==13470==      possibly lost: 0 bytes in 0 blocks
==13470==    still reachable: 23,391 bytes in 131 blocks
==13470==         suppressed: 0 bytes in 0 blocks
==13470== Rerun with --leak-check=full to see details of leaked memory
==13470==
==13470== For counts of detected and suppressed errors, rerun with: -v
==13470== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13469==
==13469== HEAP SUMMARY:
==13469==     in use at exit: 15,227 bytes in 131 blocks
==13469==   total heap usage: 256 allocs, 125 frees, 89,408 bytes allocated
==13469==
==13469== LEAK SUMMARY:
==13469==    definitely lost: 0 bytes in 0 blocks
==13469==    indirectly lost: 0 bytes in 0 blocks
==13469==      possibly lost: 0 bytes in 0 blocks
==13469==    still reachable: 15,227 bytes in 131 blocks
==13469==         suppressed: 0 bytes in 0 blocks
==13469== Rerun with --leak-check=full to see details of leaked memory
==13469==
==13469== For counts of detected and suppressed errors, rerun with: -v
==13469== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13472== Warning: invalid file descriptor -1 in syscall close()
==13473==
==13473== HEAP SUMMARY:
==13473==     in use at exit: 23,499 bytes in 131 blocks
==13473==   total heap usage: 262 allocs, 131 frees, 97,917 bytes allocated
==13473==
==13473== LEAK SUMMARY:
==13473==    definitely lost: 0 bytes in 0 blocks
==13473==    indirectly lost: 0 bytes in 0 blocks
==13473==      possibly lost: 0 bytes in 0 blocks
==13473==    still reachable: 23,499 bytes in 131 blocks
==13473==         suppressed: 0 bytes in 0 blocks
==13473== Rerun with --leak-check=full to see details of leaked memory
==13473==
==13473== For counts of detected and suppressed errors, rerun with: -v
==13473== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13472==
==13472== HEAP SUMMARY:
==13472==     in use at exit: 15,335 bytes in 131 blocks
==13472==   total heap usage: 261 allocs, 130 frees, 89,737 bytes allocated
==13472==
==13472== LEAK SUMMARY:
==13472==    definitely lost: 0 bytes in 0 blocks
==13472==    indirectly lost: 0 bytes in 0 blocks
==13472==      possibly lost: 0 bytes in 0 blocks
==13472==    still reachable: 15,335 bytes in 131 blocks
==13472==         suppressed: 0 bytes in 0 blocks
==13472== Rerun with --leak-check=full to see details of leaked memory
==13472==
==13472== For counts of detected and suppressed errors, rerun with: -v
==13472== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13446== Warning: invalid file descriptor -1 in syscall close()
==13475==
==13475== HEAP SUMMARY:
==13475==     in use at exit: 22,463 bytes in 130 blocks
==13475==   total heap usage: 266 allocs, 136 frees, 98,740 bytes allocated
==13475==
==13475== LEAK SUMMARY:
==13475==    definitely lost: 0 bytes in 0 blocks
==13475==    indirectly lost: 0 bytes in 0 blocks
==13475==      possibly lost: 0 bytes in 0 blocks
==13475==    still reachable: 22,463 bytes in 130 blocks
==13475==         suppressed: 0 bytes in 0 blocks
==13475== Rerun with --leak-check=full to see details of leaked memory
==13475==
==13475== For counts of detected and suppressed errors, rerun with: -v
==13475== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
==13446==
==13446== HEAP SUMMARY:
==13446==     in use at exit: 13,282 bytes in 129 blocks
==13446==   total heap usage: 264 allocs, 135 frees, 90,047 bytes allocated
==13446==
==13446== LEAK SUMMARY:
==13446==    definitely lost: 0 bytes in 0 blocks
==13446==    indirectly lost: 0 bytes in 0 blocks
==13446==      possibly lost: 0 bytes in 0 blocks
==13446==    still reachable: 13,282 bytes in 129 blocks
==13446==         suppressed: 0 bytes in 0 blocks
==13446== Rerun with --leak-check=full to see details of leaked memory
==13446==
==13446== For counts of detected and suppressed errors, rerun with: -v
==13446== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
[ INFO] [1569513770.755880492]: Finished loading Gazebo ROS API Plugin.
[ INFO] [1569513770.756283215]: waitForService: Service [/gazebo/set_physics_properties] has not been advertised, waiting...
[INFO] [1569513771.174828, 0.000000]: Calling service /gazebo/spawn_urdf_model
[ INFO] [1569513771.195916634, 0.023000000]: waitForService: Service [/gazebo/set_physics_properties] is now available.
Warning [parser_urdf.cc:1236] multiple inconsistent <gravity> exists due to fixed joint reduction overwriting previous value [true] with [false].
Warning [parser_urdf.cc:1236] multiple inconsistent <gravity> exists due to fixed joint reduction overwriting previous value [false] with [true].
[ INFO] [1569513772.678038791, 0.125000000]: Laser Plugin: Using the 'robotNamespace' param: '/'
[ INFO] [1569513772.678107422, 0.125000000]: Starting Laser Plugin (ns = /)
[ INFO] [1569513772.680463523, 0.125000000]: Laser Plugin (ns = /)  <tf_prefix_>, set to ""
[ INFO] [1569513772.984139421, 0.125000000]: Camera Plugin: Using the 'robotNamespace' param: '/'
[ INFO] [1569513772.988030718, 0.125000000]: Camera Plugin: Using the 'robotNamespace' param: '/'
[ INFO] [1569513772.989881251, 0.125000000]: Camera Plugin (ns = /)  <tf_prefix_>, set to ""
[ INFO] [1569513772.991364043, 0.125000000]: Camera Plugin (ns = /)  <tf_prefix_>, set to ""
[ INFO] [1569513772.993889515, 0.125000000]: Camera Plugin: Using the 'robotNamespace' param: '/'
[ INFO] [1569513772.999240022, 0.125000000]: Camera Plugin: Using the 'robotNamespace' param: '/'
[ INFO] [1569513773.006935967, 0.125000000]: Camera Plugin (ns = /)  <tf_prefix_>, set to ""
[ INFO] [1569513773.025098634, 0.125000000]: Camera Plugin (ns = /)  <tf_prefix_>, set to ""
[ INFO] [1569513773.042621440, 0.125000000]: bayer simulation maybe computationally expensive.
[ WARN] [1569513773.042710689, 0.125000000]: The <focal_length>[320.000105] you have provided for camera_ [wide_stereo_l_stereo_camera_sensor] is inconsistent with specified image_width [640] and HFOV [1.570800].   Please double check to see that focal_length = width_ / (2.0 * tan(HFOV/2.0)), the explected focal_lengtth value is [319.998825], please update your camera_ model description accordingly.
[ INFO] [1569513773.044398440, 0.125000000]: bayer simulation maybe computationally expensive.
[ WARN] [1569513773.044485198, 0.125000000]: The <focal_length>[320.000105] you have provided for camera_ [wide_stereo_r_stereo_camera_sensor] is inconsistent with specified image_width [640] and HFOV [1.570800].   Please double check to see that focal_length = width_ / (2.0 * tan(HFOV/2.0)), the explected focal_lengtth value is [319.998825], please update your camera_ model description accordingly.
[ INFO] [1569513773.074322637, 0.125000000]: Camera Plugin: Using the 'robotNamespace' param: '/'
[ INFO] [1569513773.078731037, 0.125000000]: Camera Plugin: Using the 'robotNamespace' param: '/'
[ INFO] [1569513773.081757643, 0.125000000]: Camera Plugin (ns = /)  <tf_prefix_>, set to ""
[ INFO] [1569513773.084314022, 0.125000000]: Camera Plugin (ns = /)  <tf_prefix_>, set to ""
[ INFO] [1569513773.098842781, 0.125000000]: trigger_mode trigger_mode streaming
[ WARN] [1569513773.099203446, 0.125000000]: The <focal_length>[320.000105] you have provided for camera_ [l_forearm_cam_sensor] is inconsistent with specified image_width [640] and HFOV [1.570800].   Please double check to see that focal_length = width_ / (2.0 * tan(HFOV/2.0)), the explected focal_lengtth value is [319.998825], please update your camera_ model description accordingly.
[ INFO] [1569513773.775768464, 0.125000000]: Laser Plugin: Using the 'robotNamespace' param: '/'
[ INFO] [1569513773.775826138, 0.125000000]: Starting Laser Plugin (ns = /)
[ INFO] [1569513773.777002086, 0.125000000]: Laser Plugin (ns = /)  <tf_prefix_>, set to ""
[ INFO] [1569513773.798381464, 0.125000000]: Camera Plugin: Using the 'robotNamespace' param: '/'
[ INFO] [1569513773.801075468, 0.125000000]: Camera Plugin (ns = /)  <tf_prefix_>, set to ""
[ WARN] [1569513773.812511053, 0.125000000]: The <focal_length>[320.000105] you have provided for camera_ [r_forearm_cam_sensor] is inconsistent with specified image_width [640] and HFOV [1.570800].   Please double check to see that focal_length = width_ / (2.0 * tan(HFOV/2.0)), the explected focal_lengtth value is [319.998825], please update your camera_ model description accordingly.
[INFO] [1569513773.845363, 0.125000]: Spawn status: SpawnModel: Successfully spawned entity
[ INFO] [1569513773.864237580, 0.125000000]: Physics dynamic reconfigure ready.
[ INFO] [1569513773.912607340, 0.125000000]: starting gazebo_ros_controller_manager plugin in ns: /
[ INFO] [1569513773.913094029, 0.125000000]: Callback thread id=7f4d2487f700
[ INFO] [1569513773.915389709, 0.125000000]: gazebo controller manager plugin is waiting for urdf: //robot_description on the param server.  (make sure there is a rosparam by that name in the ros parameter server, otherwise, this plugin blocks simulation forever).
[ INFO] [1569513774.019387318, 0.125000000]: gazebo controller manager got pr2.xml from param server, parsing it...
[urdf_spawner-3] process has finished cleanly
log file: /home/deadmanlogan/.ros/log/12f716ec-e077-11e9-af75-68071520849c/urdf_spawner-3*.log
Segmentation fault (core dumped)
==13384==
==13384== HEAP SUMMARY:
==13384==     in use at exit: 12,284 bytes in 120 blocks
==13384==   total heap usage: 214 allocs, 94 frees, 86,495 bytes allocated
==13384==
==13384== LEAK SUMMARY:
==13384==    definitely lost: 0 bytes in 0 blocks
==13384==    indirectly lost: 0 bytes in 0 blocks
==13384==      possibly lost: 0 bytes in 0 blocks
==13384==    still reachable: 12,284 bytes in 120 blocks
==13384==         suppressed: 0 bytes in 0 blocks
==13384== Rerun with --leak-check=full to see details of leaked memory
==13384==
==13384== For counts of detected and suppressed errors, rerun with: -v
==13384== ERROR SUMMARY: 0 errors from 0 contexts (suppressed: 0 from 0)
[gazebo-2] process has died [pid 13384, exit code 139, cmd valgrind /home/deadmanlogan/i_am_from_source/ros_catkin_ws/src/gazebo_ros_pkgs/gazebo_ros/scripts/gzserver -e ode worlds/empty.world __name:=gazebo __log:=/home/deadmanlogan/.ros/log/12f716ec-e077-11e9-af75-68071520849c/gazebo-2.log].
log file: /home/deadmanlogan/.ros/log/12f716ec-e077-11e9-af75-68071520849c/gazebo-2*.log

Speaking of any more details, I have Ubuntu xenial and trying to use my "launch file" to launch my robotic model in gazebo7(robotic simulation software) and this simulation software is giving segmentation fault on running my launch file. Since this launch file is readymade from Github I think probably there is no error in that launch file.

What do you think is causing the error based on my provided information?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

o.O

Wow, I've never seen this one before. The segfault is occurring, but Valgrind doesn't seem to be catching it.

I'm curious how you're invoking Valgrind. Usually I'd just pass the executable right to it:

$ valgrind roslaunch pr2_description pr2.launch
Thread Thread
rishabh900 profile image
all_yours

I invoked valgrind by specifying it as an option in the launch file itself and the same way i invoked gdb.

<node name="gazebo" pkg="gazebo_ros"  type="$(arg script_type)" respawn="$(arg respawn_gazebo)" output="$(arg output)" launch-prefix="valgrind"

I am very stressed with this problem but i don't want to give up.
What do you suggest for this problem?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

You know, I'd be really curious to know what would happen if you ran the launch file itself through Valgrind! If you look at the output from a moment ago, there's quite a lot that is occuring outside of Valgrind (all the lines not preceded with ==nnnnn== (where nnnnn is some number). The segfault at the end appears to be occuring outside of that context as well. That leads me to believe the segfault might actually be within the launch file.

Thread Thread
rishabh900 profile image
all_yours

I just ran it through valgrind

Thread Thread
Sloan, the sloth mascot
Comment deleted
Sloan, the sloth mascot
Comment deleted
Sloan, the sloth mascot
Comment deleted
Sloan, the sloth mascot
Comment deleted
Sloan, the sloth mascot
Comment deleted
Sloan, the sloth mascot
Comment deleted
Sloan, the sloth mascot
Comment deleted
Sloan, the sloth mascot
Comment deleted
codemouse92 profile image
Jason C. McDonald Ask Me Anything

Yikes. Could you delete that comment chain and put it in a Gist or bpaste.net or some such? It'll be easier to read.

In any case, that confirmed my suspicion; the launcher is the problem. it's not memory pure at all.

Thread Thread
Sloan, the sloth mascot
Comment deleted
Sloan, the sloth mascot
Comment deleted
rishabh900 profile image
all_yours

After ending the process manually I further got the output

^C[robo_state_publisher-4] killing on exit
[rosout-1] killing on exit
[master] killing on exit
shutting down processing monitor...
... shutting down processing monitor complete
done
==15557== Invalid read of size 4
==15557==    at 0x41964F: PyObject_Free (in /usr/bin/python2.7)
==15557==    by 0x4D07FA: ??? (in /usr/bin/python2.7)
==15557==    by 0x4AA262: ??? (in /usr/bin/python2.7)
==15557==    by 0x4E0C11: ??? (in /usr/bin/python2.7)
==15557==    by 0x4FC2C9: _PyModule_Clear (in /usr/bin/python2.7)
==15557==    by 0x4FBADC: PyImport_Cleanup (in /usr/bin/python2.7)
==15557==    by 0x4F8D83: Py_Finalize (in /usr/bin/python2.7)
==15557==    by 0x4936F1: Py_Main (in /usr/bin/python2.7)
==15557==    by 0x507782F: (below main) (libc-start.c:291)
==15557==  Address 0x62f2020 is 2,592 bytes inside an unallocated block of size 2,768 in arena "client"
==15557==
==15557== Invalid read of size 4
==15557==    at 0x41964F: PyObject_Free (in /usr/bin/python2.7)
==15557==    by 0x4AA262: ??? (in /usr/bin/python2.7)
==15557==    by 0x4E0C11: ??? (in /usr/bin/python2.7)
==15557==    by 0x4FC2C9: _PyModule_Clear (in /usr/bin/python2.7)
==15557==    by 0x4FBADC: PyImport_Cleanup (in /usr/bin/python2.7)
==15557==    by 0x4F8D83: Py_Finalize (in /usr/bin/python2.7)
==15557==    by 0x4936F1: Py_Main (in /usr/bin/python2.7)
==15557==    by 0x507782F: (below main) (libc-start.c:291)
==15557==  Address 0x7f37020 is 128 bytes inside a block of size 552 free'd
==15557==    at 0x4C2EDEB: free (vg_replace_malloc.c:530)
==15557==    by 0x50C4362: fclose@@GLIBC_2.2.5 (iofclose.c:84)
==15557==    by 0x43CEFB: ??? (in /usr/bin/python2.7)
==15557==    by 0x4A63FD: PyObject_Call (in /usr/bin/python2.7)
==15557==    by 0x5385A5: _PyObject_CallMethod_SizeT (in /usr/bin/python2.7)
==15557==    by 0x53F4CE: ??? (in /usr/bin/python2.7)
==15557==    by 0x4AEF42: PyObject_CallFunctionObjArgs (in /usr/bin/python2.7)
==15557==    by 0x4BF668: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4BA915: PyEval_EvalCodeEx (in /usr/bin/python2.7)
==15557==    by 0x4C2C3B: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4BA915: PyEval_EvalCodeEx (in /usr/bin/python2.7)
==15557==    by 0x4C24E9: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==  Block was alloc'd at
==15557==    at 0x4C2DB8F: malloc (vg_replace_malloc.c:299)
==15557==    by 0x50C4CDC: __fopen_internal (iofopen.c:69)
==15557==    by 0x53D247: ??? (in /usr/bin/python2.7)
==15557==    by 0x4AB6FA: ??? (in /usr/bin/python2.7)
==15557==    by 0x53CDBE: ??? (in /usr/bin/python2.7)
==15557==    by 0x4BD1D9: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4BA915: PyEval_EvalCodeEx (in /usr/bin/python2.7)
==15557==    by 0x4C2C3B: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4BA915: PyEval_EvalCodeEx (in /usr/bin/python2.7)
==15557==    by 0x4C24E9: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4BA915: PyEval_EvalCodeEx (in /usr/bin/python2.7)
==15557==    by 0x4C24E9: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==
==15557== Invalid read of size 4
==15557==    at 0x41964F: PyObject_Free (in /usr/bin/python2.7)
==15557==    by 0x4FC2C9: _PyModule_Clear (in /usr/bin/python2.7)
==15557==    by 0x4FBADC: PyImport_Cleanup (in /usr/bin/python2.7)
==15557==    by 0x4F8D83: Py_Finalize (in /usr/bin/python2.7)
==15557==    by 0x4936F1: Py_Main (in /usr/bin/python2.7)
==15557==    by 0x507782F: (below main) (libc-start.c:291)
==15557==  Address 0x7eea020 is 0 bytes inside a block of size 8 free'd
==15557==    at 0x4C2EDEB: free (vg_replace_malloc.c:530)
==15557==    by 0x49B1E4: ??? (in /usr/bin/python2.7)
==15557==    by 0x4D878E: ??? (in /usr/bin/python2.7)
==15557==    by 0x4BD778: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4BA915: PyEval_EvalCodeEx (in /usr/bin/python2.7)
==15557==    by 0x4D6218: ??? (in /usr/bin/python2.7)
==15557==    by 0x4EEC7D: ??? (in /usr/bin/python2.7)
==15557==    by 0x4A63FD: PyObject_Call (in /usr/bin/python2.7)
==15557==    by 0x4C6C2F: PyEval_CallObjectWithKeywords (in /usr/bin/python2.7)
==15557==    by 0x6EB480C: ??? (in /usr/lib/python2.7/lib-dynload/pyexpat.x86_64-linux-gnu.so)
==15557==    by 0x6EBCF3D: ??? (in /usr/lib/python2.7/lib-dynload/pyexpat.x86_64-linux-gnu.so)
==15557==    by 0x710D68F: ??? (in /lib/x86_64-linux-gnu/libexpat.so.1.6.0)
==15557==  Block was alloc'd at
==15557==    at 0x4C2DB8F: malloc (vg_replace_malloc.c:299)
==15557==    by 0x493F0E: PyList_New (in /usr/bin/python2.7)
==15557==    by 0x510D4D: ??? (in /usr/bin/python2.7)
==15557==    by 0x4BD1D9: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4BA915: PyEval_EvalCodeEx (in /usr/bin/python2.7)
==15557==    by 0x4D6218: ??? (in /usr/bin/python2.7)
==15557==    by 0x4EEC7D: ??? (in /usr/bin/python2.7)
==15557==    by 0x4A63FD: PyObject_Call (in /usr/bin/python2.7)
==15557==    by 0x4C6C2F: PyEval_CallObjectWithKeywords (in /usr/bin/python2.7)
==15557==    by 0x6EB480C: ??? (in /usr/lib/python2.7/lib-dynload/pyexpat.x86_64-linux-gnu.so)
==15557==    by 0x6EBCF3D: ??? (in /usr/lib/python2.7/lib-dynload/pyexpat.x86_64-linux-gnu.so)
==15557==    by 0x710D68F: ??? (in /lib/x86_64-linux-gnu/libexpat.so.1.6.0)
==15557==
==15557== Invalid read of size 4
==15557==    at 0x41964F: PyObject_Free (in /usr/bin/python2.7)
==15557==    by 0x4D0C94: ??? (in /usr/bin/python2.7)
==15557==    by 0x4D086B: ??? (in /usr/bin/python2.7)
==15557==    by 0x4FC2C9: _PyModule_Clear (in /usr/bin/python2.7)
==15557==    by 0x4FBADC: PyImport_Cleanup (in /usr/bin/python2.7)
==15557==    by 0x4F8D83: Py_Finalize (in /usr/bin/python2.7)
==15557==    by 0x4936F1: Py_Main (in /usr/bin/python2.7)
==15557==    by 0x507782F: (below main) (libc-start.c:291)
==15557==  Address 0x611c020 is 48,736 bytes inside a block of size 49,152 free'd
==15557==    at 0x4C2EDEB: free (vg_replace_malloc.c:530)
==15557==    by 0x4AA3C4: ??? (in /usr/bin/python2.7)
==15557==    by 0x495BCA: PyDict_SetItem (in /usr/bin/python2.7)
==15557==    by 0x4FC278: _PyModule_Clear (in /usr/bin/python2.7)
==15557==    by 0x4FBADC: PyImport_Cleanup (in /usr/bin/python2.7)
==15557==    by 0x4F8D83: Py_Finalize (in /usr/bin/python2.7)
==15557==    by 0x4936F1: Py_Main (in /usr/bin/python2.7)
==15557==    by 0x507782F: (below main) (libc-start.c:291)
==15557==  Block was alloc'd at
==15557==    at 0x4C2FB55: calloc (vg_replace_malloc.c:711)
==15557==    by 0x498D2C: ??? (in /usr/bin/python2.7)
==15557==    by 0x4A252E: PyDict_Merge (in /usr/bin/python2.7)
==15557==    by 0x512275: ??? (in /usr/bin/python2.7)
==15557==    by 0x4BD1D9: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4C210E: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4BA915: PyEval_EvalCodeEx (in /usr/bin/python2.7)
==15557==    by 0x4C2C3B: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4C210E: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4C210E: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4C210E: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==    by 0x4C210E: PyEval_EvalFrameEx (in /usr/bin/python2.7)
==15557==
==15557== Invalid read of size 4
==15557==    at 0x41964F: PyObject_Free (in /usr/bin/python2.7)
==15557==    by 0x4D0B76: ??? (in /usr/bin/python2.7)
==15557==    by 0x4D086B: ??? (in /usr/bin/python2.7)
==15557==    by 0x495BCA: PyDict_SetItem (in /usr/bin/python2.7)
==15557==    by 0x4FC278: _PyModule_Clear (in /usr/bin/python2.7)
==15557==    by 0x4FBBBD: PyImport_Cleanup (in /usr/bin/python2.7)
==15557==    by 0x4F8D83: Py_Finalize (in /usr/bin/python2.7)
==15557==    by 0x4936F1: Py_Main (in /usr/bin/python2.7)
==15557==    by 0x507782F: (below main) (libc-start.c:291)
==15557==  Address 0x6083020 is 3,200 bytes inside a block of size 3,218 free'd
==15557==    at 0x4C2EDEB: free (vg_replace_malloc.c:530)
==15557==    by 0x4D0A85: ??? (in /usr/bin/python2.7)
==15557==    by 0x4D086B: ??? (in /usr/bin/python2.7)
==15557==    by 0x495BCA: PyDict_SetItem (in /usr/bin/python2.7)
==15557==    by 0x4FC278: _PyModule_Clear (in /usr/bin/python2.7)
==15557==    by 0x4FBBBD: PyImport_Cleanup (in /usr/bin/python2.7)
==15557==    by 0x4F8D83: Py_Finalize (in /usr/bin/python2.7)
==15557==    by 0x4936F1: Py_Main (in /usr/bin/python2.7)
==15557==    by 0x507782F: (below main) (libc-start.c:291)
==15557==  Block was alloc'd at
==15557==    at 0x4C2DB8F: malloc (vg_replace_malloc.c:299)
==15557==    by 0x4A0021: PyString_FromStringAndSize (in /usr/bin/python2.7)
==15557==    by 0x4B3F50: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B425C: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B414F: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B4272: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B3E65: PyMarshal_ReadObjectFromString (in /usr/bin/python2.7)
==15557==    by 0x4B3DE5: PyMarshal_ReadLastObjectFromFile (in /usr/bin/python2.7)
==15557==    by 0x4B3D2D: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B390B: ??? (in /usr/bin/python2.7)
==15557==    by 0x4A4C20: ??? (in /usr/bin/python2.7)
==15557==    by 0x4A42B2: PyImport_ImportModuleLevel (in /usr/bin/python2.7)
==15557==
==15557== Conditional jump or move depends on uninitialised value(s)
==15557==    at 0x419658: PyObject_Free (in /usr/bin/python2.7)
==15557==    by 0x4D0C94: ??? (in /usr/bin/python2.7)
==15557==    by 0x4D086B: ??? (in /usr/bin/python2.7)
==15557==    by 0x4AA262: ??? (in /usr/bin/python2.7)
==15557==    by 0x4E0C11: ??? (in /usr/bin/python2.7)
==15557==    by 0x4AA0E3: ??? (in /usr/bin/python2.7)
==15557==    by 0x4E0BFB: ??? (in /usr/bin/python2.7)
==15557==    by 0x4AA262: ??? (in /usr/bin/python2.7)
==15557==    by 0x4E0C11: ??? (in /usr/bin/python2.7)
==15557==    by 0x4FC2C9: _PyModule_Clear (in /usr/bin/python2.7)
==15557==    by 0x4FBBBD: PyImport_Cleanup (in /usr/bin/python2.7)
==15557==    by 0x4F8D83: Py_Finalize (in /usr/bin/python2.7)
==15557==
==15557== Invalid read of size 4
==15557==    at 0x502477: PyGrammar_RemoveAccelerators (in /usr/bin/python2.7)
==15557==    by 0x4F8DF3: Py_Finalize (in /usr/bin/python2.7)
==15557==    by 0x4936F1: Py_Main (in /usr/bin/python2.7)
==15557==    by 0x507782F: (below main) (libc-start.c:291)
==15557==  Address 0x615a020 is 304 bytes inside a block of size 617 free'd
==15557==    at 0x4C2EDEB: free (vg_replace_malloc.c:530)
==15557==    by 0x4D07FA: ??? (in /usr/bin/python2.7)
==15557==    by 0x4FC2C9: _PyModule_Clear (in /usr/bin/python2.7)
==15557==    by 0x4FBADC: PyImport_Cleanup (in /usr/bin/python2.7)
==15557==    by 0x4F8D83: Py_Finalize (in /usr/bin/python2.7)
==15557==    by 0x4936F1: Py_Main (in /usr/bin/python2.7)
==15557==    by 0x507782F: (below main) (libc-start.c:291)
==15557==  Block was alloc'd at
==15557==    at 0x4C2DB8F: malloc (vg_replace_malloc.c:299)
==15557==    by 0x4A0021: PyString_FromStringAndSize (in /usr/bin/python2.7)
==15557==    by 0x4B3F50: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B407D: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B4272: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B414F: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B4272: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B3E65: PyMarshal_ReadObjectFromString (in /usr/bin/python2.7)
==15557==    by 0x4B3DE5: PyMarshal_ReadLastObjectFromFile (in /usr/bin/python2.7)
==15557==    by 0x4B3D2D: ??? (in /usr/bin/python2.7)
==15557==    by 0x4B390B: ??? (in /usr/bin/python2.7)
==15557==    by 0x4A4C20: ??? (in /usr/bin/python2.7)
==15557==
==15557==
==15557== HEAP SUMMARY:
==15557==     in use at exit: 3,393,686 bytes in 5,832 blocks
==15557==   total heap usage: 278,397 allocs, 272,565 frees, 371,732,938 bytes allocated
==15557==
==15557== LEAK SUMMARY:
==15557==    definitely lost: 0 bytes in 0 blocks
==15557==    indirectly lost: 0 bytes in 0 blocks
==15557==      possibly lost: 55,704 bytes in 96 blocks
==15557==    still reachable: 3,337,982 bytes in 5,736 blocks
==15557==         suppressed: 0 bytes in 0 blocks
==15557== Rerun with --leak-check=full to see details of leaked memory
==15557==
==15557== For counts of detected and suppressed errors, rerun with: -v
==15557== Use --track-origins=yes to see where uninitialised values come from
==15557== ERROR SUMMARY: 9917 errors from 128 contexts (suppressed: 0 from 0)

So this was the whole output I got , sorry for uploading this in parts(character limitation).

I hope this gives something useful to track down the issue.

Thread Thread
rishabh900 profile image
all_yours

I apologise for making such a long comment chain.
I have now made a gist of running the launch file through valgrind in

gist.github.com/rishabh900/41fd6df...

And the above comment is the output after i terminated the process manually.
So what do you think of now?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

Did you write the launcher script, or is that third-party? It's clearly written in Python, and the issue is definitely there. I just can't narrow in on the specific issue, because the memory issues are being thrown by the interpreter (e.g. at 0x41964F: PyObject_Free (in /usr/bin/python2.7)). That indicates that something odd has been done within the Python code, but I won't be able to diagnose this further without really fully understanding the launcher's source code, and I'm afraid I don't have time to learn it.

If this is third-party code, open an issue against the launcher project, and include the above output of Valgrind.

Collapse
codevault profile image
Sergiu Mureşan • Edited

Great to see a fellow low-level programmer on here!

I worked on a game engine written in C and was having many issues related to wrongly using the realloc function for dynamically allocated memory. What I did was forget to assign the reallocated memory's pointer to the return value of the function. It took me weeks before I found the underlying problem since only in some cases it would blow up. How would you go about debugging a situation like:

int* p = calloc(5, sizeof(int));
// some code
realloc(p, 6 * sizeof(int)); // notice no assignment

Do you use some sort of special tools? Or just some coding standards to not let this happen?

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything

Whenever I'm working with memory, I pair two different tools: Valgrind and Goldilocks (PawLIB).

Valgrind is a pretty ubiquitous tool on UNIX platforms which will show me all of the memory issues encountered while running, even if the undefined behavior doesn't cause any overt problems. My code isn't done until it's Valgrind-pure. However, Valgrind only monitors the execution, so...

Goldilocks is a testing framework I developed at MousePaw Media, as a part of PawLIB. You could technically use any testing framework, but the benefit to Goldilocks is that it bakes the tests into the final executable, instead of requiring an additional framework to run the tests. That way, you can start the normal executable, run each of the tests you wrote, and see which ones Valgrind complains about.

Mind you, this does require you to write a lot of comprehensive behavioral tests...but you really should be doing that anyway in production code. ;)

Collapse
liulk profile image
Likai Liu

My approach for this specific problem is to use a compiler that warns about unused return value, such as gcc or clang. I know that stdlib.h on Linux and Mac OS X already decorates realloc() with warn_unused_result attribute.

stackoverflow.com/a/2889601

But just naively setting p = realloc(p, ...) is also wrong, since if the allocation fails, p would be set to NULL but the original object is still allocated. The original pointer is lost and now a memory leak. Use reallocf() which frees the original memory if it could not be resized.

Thread Thread
codevault profile image
Sergiu Mureşan

That's a really nice feature, didn't know about it.

But wouldn't that mean data loss in case the memory can't be resized? Wouldn't that become an unrecoverable error?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

@liulk Ha, I completely forgot to mention Clang! It does indeed have the best warnings of any compiler I've used. I almost always compile with -Wall -Wextra -Wpedantic -Werror; that last one (as you know, although the reader might not) causes the build to fail on any warnings.

I also use cppcheck as part of my autoreview workflow, and resolve all linter warnings before committing to the production branch.

Thread Thread
liulk profile image
Likai Liu

@codevault You're right, reallocf() would just free the memory and cause data loss, so it would serve a different use case than realloc(). The more general solution would be to always use this pattern, which is more verbose:

void *q = realloc(p, new_size);
if (q == NULL) {
  // do error handling.
  return;
}
p = q;

I just find that in most of my use cases, I would end up freeing p in the error handling, so I would just use reallocf() which results in less verbose code.

Thread Thread
codevault profile image
Sergiu Mureşan

I see, that makes sense. I can see myself freeing the memory most of the time when reallocation fails.

Good to note. Thanks!

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything

I should add, I use another tool from PawLIB called IOChannel - basically, a std::cout wrapper - that allows me to cleanly print the address and raw memory from literally any pointer, without having to use a debugger. This can make debugging some problems infinitely easier, especially when you're contending with a Heisenbug that goes away if compiled with -g, but appears when compiled with -O2.

Thread Thread
codevault profile image
Sergiu Mureşan

Thanks for the response!

Unfortunately, I didn't find a version of Valgrind for Windows. I tried DrMemory but, after lots of struggle, it didn't give me any helpful information and dropped the ball. Do you have experience with low-level on Windows or just work exclusively on Linux since it is more convenient?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

I rarely use Windows for development, as its development toolchain is almost invariably miles behind its UNIX-based counterparts.

If you're on Windows 10, I strongly recommend setting up the Windows Subsystem for Linux [WSL]. That will give you access to the Linux development environment for compiling and testing. Then, use the LLVM Clang compiler on both the WSL and the Visual Studio environments. That way, once you know it compiles and runs Valgrind-pure on WSL, you can trust that it will work on VS Clang.

Collapse
lindenouwen profile image
Lindenouwen

Hi Jason,

I had a problem when mixing C and C++ code. Everything compiles just fine but when I run it I get a segfault. This happens when the code goes from C++ to C
I implemented it as follows:

include "Signature.hpp"

include

include

extern "C"{
#include "sign.h"
#include "sign.c"
#include "params.h"
#include "aes256ctr.h"
#include "aes256ctr.c"
#include "ntt.h"
#include "ntt.c"
#include "packing.h"
#include "packing.c"
#include "poly.h"
#include "poly.c"
#include "polyvec.h"
#include "polyvec.c"
#include "reduce.h"
#include "reduce.c"
#include "randombytes.h"
#include "randombytes.c"
#include "fips202.h"
#include "fips202.c"
#include "rounding.h"
#include "rounding.c"
#include "symmetric.h"
#include "symmetric-aes.c"

int PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_keypair(uint8_t *,uint8_t *);
Enter fullscreen mode Exit fullscreen mode

}
using namespace std;
// function to generate a keypair, mainly uses the c function from the Dilithium PQ scheme
void Signature::generateKeyPair(){
uint8_t* pk = getPublicKeyAddress();
uint8_t* sk = getSecretKeyAddress();
PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_keypair(pk, sk);
cout << "I succeeded" << endl;
}
I really thought I implemented this right and I do not know what I am doing wrong. Could you help me?

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything

For a start, you might want to wrap your code in your post above with three backticks on the line above, and three on the line below. Otherwise, it's hard to read the code. ;)

Collapse
lindenouwen profile image
Lindenouwen

Dear Jason,

I am so sorry, this is my first time on the platform. I have used valgrind and this gives me that the segfault is caused by an invalid write of size 8. Here is my code (main function):

#include "Signature.hpp"
#include "Signature.cpp"
#include <cstdint>
#include <iostream>
#include <cstddef>
#include <cstring>
using namespace std;
extern "C"{
     #include "api.h"
    }
int main(){
    char publicKey[PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_PUBLICKEYBYTES];
    char secretKey[PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_SECRETKEYBYTES];
    uint8_t* pk;
    pk = (uint8_t *) &publicKey;
    uint8_t* sk;
    sk = (uint8_t *) &secretKey;
    // string passwd = "admin";
    Signature sig(pk, sk);
    sig.generateKeyPair();
    cout << "I succeeded in generating a key pair." << endl;
    string mes = "I am checking if this works";
    size_t mlen = mes.length();
    char message[mlen+1];
    strcpy(message, mes.c_str());
    uint8_t* m;
    m = (uint8_t*) &message;
    mlen = sizeof(*m);
    char signedMessage[PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES+mlen];
    uint8_t* sm;
    sm = (uint8_t*) &signedMessage;
    size_t smLength = sizeof(*sm);
    size_t* smlen;
    smlen = (size_t*) smLength;
    sig.signMessage(sm, smlen, m, mlen);
    cout << "I succeeded in signing a message." << endl;
    cout << *sm << endl;
    return 0;
}
Enter fullscreen mode Exit fullscreen mode

and this is the signature class from which the c code is called:

#include "Signature.hpp"
#include <cstdint>
#include <iostream>
#include <stddef.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <cstddef>
#include <cryptopp/sha3.h>
#include <cryptopp/cryptlib.h>
#include <cryptopp/hex.h>
#include <cryptopp/filters.h>
#include <cryptopp/sha.h>
#include <cryptopp/hex.h>
#include <cryptopp/files.h>

using namespace CryptoPP;

extern "C"{
     #include "api.h"
    }
using namespace std;
void Signature::signMessage(uint8_t* signedMessage, std::size_t* smLength, const uint8_t* message, std::size_t mLength){
    // if (checkPasswd(passwd)==true){
        const uint8_t *sk = getSecretKeyAddress();
        cout << "I get here" << endl;
        PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign(signedMessage, smLength, message, mLength, sk);
        cout << "not here" << endl;
    // }
}
Enter fullscreen mode Exit fullscreen mode

The PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign is a c function that was built for the NIST competition for post quantum signature schemes.
Do you know what I am doing wrong here?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

I have used valgrind and this gives me that the segfault is caused by an invalid write of size 8.

More importantly, what file name and line number does it say that invalid write occurs on? (Consider posted the full output of Valgrind's error message, with traceback.)

Thread Thread
lindenouwen profile image
Lindenouwen
==6225== Memcheck, a memory error detector
==6225== Copyright (C) 2002-2017, and GNU GPL'd, by Julian Seward et al.
==6225== Using Valgrind-3.17.0 and LibVEX; rerun with -h for copyright info
==6225== Command: ./signatures
==6225==
I succeeded in generating a key pair.
I get here
==6225== Invalid write of size 8
==6225==    at 0x109D39: PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_signature (sign.c:179)
==6225==    by 0x109DED: PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign (sign.c:210)
==6225==    by 0x1096D2: Signature::signMessage(unsigned char*, unsigned long*, unsigned char const*, unsigned long) (Signature.cpp:73)
==6225==    by 0x10946C: main (main.cpp:35)
==6225==  Address 0x1 is not stack'd, malloc'd or (recently) free'd
==6225==
==6225==
==6225== Process terminating with default action of signal 11 (SIGSEGV)
==6225==  Access not within mapped region at address 0x1
==6225==    at 0x109D39: PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_signature (sign.c:179)
==6225==    by 0x109DED: PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign (sign.c:210)
==6225==    by 0x1096D2: Signature::signMessage(unsigned char*, unsigned long*, unsigned char const*, unsigned long) (Signature.cpp:73)
==6225==    by 0x10946C: main (main.cpp:35)
==6225==  If you believe this happened as a result of a stack
==6225==  overflow in your program's main thread (unlikely but
==6225==  possible), you can try to increase the size of the
==6225==  main thread stack using the --main-stacksize= flag.
==6225==  The main thread stack size used in this run was 8388608.
I got infor loop works==6225==
==6225== HEAP SUMMARY:
==6225==     in use at exit: 28 bytes in 1 blocks
==6225==   total heap usage: 11 allocs, 10 frees, 75,396 bytes allocated
==6225==
==6225== LEAK SUMMARY:
==6225==    definitely lost: 0 bytes in 0 blocks
==6225==    indirectly lost: 0 bytes in 0 blocks
==6225==      possibly lost: 0 bytes in 0 blocks
==6225==    still reachable: 28 bytes in 1 blocks
==6225==         suppressed: 0 bytes in 0 blocks
==6225== Rerun with --leak-check=full to see details of leaked memory
==6225==
==6225== For lists of detected and suppressed errors, rerun with: -s
==6225== ERROR SUMMARY: 1 errors from 1 contexts (suppressed: 0 from 0)
Segmentation fault (core dumped)
Enter fullscreen mode Exit fullscreen mode

Here is the valgrind error message. The problem happens inside another file than the two above this one although the problem can't be there because, as said above, this is code from an almost NIST standard in post quantum and has been reviewed in correctness. For completeness, here is the code:

#include "packing.h"
#include "params.h"
#include "poly.h"
#include "polyvec.h"
#include "sign.h"
#include "randombytes.h"
#include "symmetric.h"
#include "fips202.h"
#include <stdio.h>

#include <stdint.h>

/*************************************************
* Name:        PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_keypair
*
* Description: Generates public and private key.
*
* Arguments:   - uint8_t *pk: pointer to output public key (allocated
*                             array of PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_PUBLICKEYBYTES bytes)
*              - uint8_t *sk: pointer to output private key (allocated
*                             array of PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_SECRETKEYBYTES bytes)
*
* Returns 0 (success)
**************************************************/
int PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_keypair(uint8_t *pk, uint8_t *sk) {
    uint8_t seedbuf[2 * SEEDBYTES + CRHBYTES];
    uint8_t tr[SEEDBYTES];
    const uint8_t *rho, *rhoprime, *key;
    polyvecl mat[K];
    polyvecl s1, s1hat;
    polyveck s2, t1, t0;
    /* Get randomness for rho, rhoprime and key */
    randombytes(seedbuf, SEEDBYTES);
    shake256(seedbuf, 2 * SEEDBYTES + CRHBYTES, seedbuf, SEEDBYTES);
    rho = seedbuf;
    rhoprime = rho + SEEDBYTES;
    key = rhoprime + CRHBYTES;

    /* Expand matrix */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvec_matrix_expand(mat, rho);

    /* Sample short vectors s1 and s2 */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_uniform_eta(&s1, rhoprime, 0);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_uniform_eta(&s2, rhoprime, L);

    /* Matrix-vector multiplication */
    s1hat = s1;
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_ntt(&s1hat);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvec_matrix_pointwise_montgomery(&t1, mat, &s1hat);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_reduce(&t1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_invntt_tomont(&t1);

    /* Add error vector s2 */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_add(&t1, &t1, &s2);

    /* Extract t1 and write public key */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_caddq(&t1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_power2round(&t1, &t0, &t1);
    PQCLEAN_DILITHIUM5AES_CLEAN_pack_pk(pk, rho, &t1);

    /* Compute H(rho, t1) and write secret key */
    shake256(tr, SEEDBYTES, pk, PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_PUBLICKEYBYTES);
    PQCLEAN_DILITHIUM5AES_CLEAN_pack_sk(sk, rho, tr, key, &t0, &s1, &s2);

    return 0;
}

/*************************************************
* Name:        PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_signature
*
* Description: Computes signature.
*
* Arguments:   - uint8_t *sig:   pointer to output signature (of length PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES)
*              - size_t *siglen: pointer to output length of signature
*              - uint8_t *m:     pointer to message to be signed
*              - size_t mlen:    length of message
*              - uint8_t *sk:    pointer to bit-packed secret key
*
* Returns 0 (success)
**************************************************/
int PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_signature(uint8_t *sig,
        size_t *siglen,
        const uint8_t *m,
        size_t mlen,
        const uint8_t *sk) {
    unsigned int n;
    uint8_t seedbuf[3 * SEEDBYTES + 2 * CRHBYTES];
    uint8_t *rho, *tr, *key, *mu, *rhoprime;
    uint16_t nonce = 0;
    polyvecl mat[K], s1, y, z;
    polyveck t0, s2, w1, w0, h;
    poly cp;
    shake256incctx state;

    rho = seedbuf;
    tr = rho + SEEDBYTES;
    key = tr + SEEDBYTES;
    mu = key + SEEDBYTES;
    rhoprime = mu + CRHBYTES;
    PQCLEAN_DILITHIUM5AES_CLEAN_unpack_sk(rho, tr, key, &t0, &s1, &s2, sk);

     /* Compute CRH(tr, msg) */
    shake256_inc_init(&state);
    shake256_inc_absorb(&state, tr, SEEDBYTES);
    shake256_inc_absorb(&state, m, mlen);
    shake256_inc_finalize(&state);
    shake256_inc_squeeze(mu, CRHBYTES, &state);
    shake256_inc_ctx_release(&state);

    shake256(rhoprime, CRHBYTES, key, SEEDBYTES + CRHBYTES);

    /* Expand matrix and transform vectors */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvec_matrix_expand(mat, rho);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_ntt(&s1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_ntt(&s2);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_ntt(&t0);

rej:
    /* Sample intermediate vector y */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_uniform_gamma1(&y, rhoprime, nonce++);

    /* Matrix-vector multiplication */
    z = y;
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_ntt(&z);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvec_matrix_pointwise_montgomery(&w1, mat, &z);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_reduce(&w1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_invntt_tomont(&w1);

    /* Decompose w and call the random oracle */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_caddq(&w1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_decompose(&w1, &w0, &w1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_pack_w1(sig, &w1);

    shake256_inc_init(&state);
    shake256_inc_absorb(&state, mu, CRHBYTES);
    shake256_inc_absorb(&state, sig, K * POLYW1_PACKEDBYTES);
    shake256_inc_finalize(&state);
    shake256_inc_squeeze(sig, SEEDBYTES, &state);
    shake256_inc_ctx_release(&state);
    PQCLEAN_DILITHIUM5AES_CLEAN_poly_challenge(&cp, sig);
    PQCLEAN_DILITHIUM5AES_CLEAN_poly_ntt(&cp);

    /* Compute z, reject if it reveals secret */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_pointwise_poly_montgomery(&z, &cp, &s1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_invntt_tomont(&z);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_add(&z, &z, &y);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_reduce(&z);
    if (PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_chknorm(&z, GAMMA1 - BETA)) {
        goto rej;
    }

    /* Check that subtracting cs2 does not change high bits of w and low bits
     * do not reveal secret information */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_pointwise_poly_montgomery(&h, &cp, &s2);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_invntt_tomont(&h);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_sub(&w0, &w0, &h);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_reduce(&w0);
    if (PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_chknorm(&w0, GAMMA2 - BETA)) {
        goto rej;
    }

    /* Compute hints for w1 */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_pointwise_poly_montgomery(&h, &cp, &t0);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_invntt_tomont(&h);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_reduce(&h);
    if (PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_chknorm(&h, GAMMA2)) {
        goto rej;
    }

    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_add(&w0, &w0, &h);
    n = PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_make_hint(&h, &w0, &w1);
    if (n > OMEGA) {
        goto rej;
    }

    /* Write signature */
    PQCLEAN_DILITHIUM5AES_CLEAN_pack_sig(sig, sig, &z, &h);
    //this line is the one that gives the segmentation fault. fault is something with an invalid write somehow.
   *siglen = PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES;
    return 0;
}

/*************************************************
* Name:        PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign
*
* Description: Compute signed message.
*
* Arguments:   - uint8_t *sm: pointer to output signed message (allocated
*                             array with PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES + mlen bytes),
*                             can be equal to m
*              - size_t *smlen: pointer to output length of signed
*                               message
*              - const uint8_t *m: pointer to message to be signed
*              - size_t mlen: length of message
*              - const uint8_t *sk: pointer to bit-packed secret key
*
* Returns 0 (success)
**************************************************/
int PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign(uint8_t *sm,
        size_t *smlen,
        const uint8_t *m,
        size_t mlen,
        const uint8_t *sk) {
    size_t i;
    printf("I got in");
    for (i = 0; i < mlen; ++i) {
        sm[PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES + mlen - 1 - i] = m[mlen - 1 - i];
    }
    printf("for loop works");
    PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_signature(sm, smlen, sm + PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES, mlen, sk);

    *smlen += mlen;
    return 0;
}

/*************************************************
* Name:        PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_verify
*
* Description: Verifies signature.
*
* Arguments:   - uint8_t *m: pointer to input signature
*              - size_t siglen: length of signature
*              - const uint8_t *m: pointer to message
*              - size_t mlen: length of message
*              - const uint8_t *pk: pointer to bit-packed public key
*
* Returns 0 if signature could be verified correctly and -1 otherwise
**************************************************/
int PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_verify(const uint8_t *sig,
        size_t siglen,
        const uint8_t *m,
        size_t mlen,
        const uint8_t *pk) {
    unsigned int i;
    uint8_t buf[K * POLYW1_PACKEDBYTES];
    uint8_t rho[SEEDBYTES];
    uint8_t mu[CRHBYTES];
    uint8_t c[SEEDBYTES];
    uint8_t c2[SEEDBYTES];
    poly cp;
    polyvecl mat[K], z;
    polyveck t1, w1, h;
    shake256incctx state;

    if (siglen != PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES) {
        return -1;
    }

    PQCLEAN_DILITHIUM5AES_CLEAN_unpack_pk(rho, &t1, pk);
    if (PQCLEAN_DILITHIUM5AES_CLEAN_unpack_sig(c, &z, &h, sig)) {
        return -1;
    }
    if (PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_chknorm(&z, GAMMA1 - BETA)) {
        return -1;
    }

    /* Compute CRH(H(rho, t1), msg) */
    shake256(mu, SEEDBYTES, pk, PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_PUBLICKEYBYTES);
    shake256_inc_init(&state);
    shake256_inc_absorb(&state, mu, SEEDBYTES);
    shake256_inc_absorb(&state, m, mlen);
    shake256_inc_finalize(&state);
    shake256_inc_squeeze(mu, CRHBYTES, &state);
    shake256_inc_ctx_release(&state);

    /* Matrix-vector multiplication; compute Az - c2^dt1 */
    PQCLEAN_DILITHIUM5AES_CLEAN_poly_challenge(&cp, c);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvec_matrix_expand(mat, rho);

    PQCLEAN_DILITHIUM5AES_CLEAN_polyvecl_ntt(&z);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyvec_matrix_pointwise_montgomery(&w1, mat, &z);

    PQCLEAN_DILITHIUM5AES_CLEAN_poly_ntt(&cp);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_shiftl(&t1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_ntt(&t1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_pointwise_poly_montgomery(&t1, &cp, &t1);

    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_sub(&w1, &w1, &t1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_reduce(&w1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_invntt_tomont(&w1);

    /* Reconstruct w1 */
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_caddq(&w1);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_use_hint(&w1, &w1, &h);
    PQCLEAN_DILITHIUM5AES_CLEAN_polyveck_pack_w1(buf, &w1);

    /* Call random oracle and verify PQCLEAN_DILITHIUM5AES_CLEAN_challenge */
    shake256_inc_init(&state);
    shake256_inc_absorb(&state, mu, CRHBYTES);
    shake256_inc_absorb(&state, buf, K * POLYW1_PACKEDBYTES);
    shake256_inc_finalize(&state);
    shake256_inc_squeeze(c2, SEEDBYTES, &state);
    shake256_inc_ctx_release(&state);
    for (i = 0; i < SEEDBYTES; ++i) {
        if (c[i] != c2[i]) {
            return -1;
        }
    }

    return 0;
}

/*************************************************
* Name:        PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_open
*
* Description: Verify signed message.
*
* Arguments:   - uint8_t *m: pointer to output message (allocated
*                            array with smlen bytes), can be equal to sm
*              - size_t *mlen: pointer to output length of message
*              - const uint8_t *sm: pointer to signed message
*              - size_t smlen: length of signed message
*              - const uint8_t *pk: pointer to bit-packed public key
*
* Returns 0 if signed message could be verified correctly and -1 otherwise
**************************************************/
int PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_open(uint8_t *m,
        size_t *mlen,
        const uint8_t *sm,
        size_t smlen,
        const uint8_t *pk) {
    size_t i;

    if (smlen < PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES) {
        goto badsig;
    }

    *mlen = smlen - PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES;
    if (PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign_verify(sm, PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES, sm + PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES, *mlen, pk)) {
        goto badsig;
    } else {
        /* All good, copy msg, return 0 */
        for (i = 0; i < *mlen; ++i) {
            m[i] = sm[PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES + i];
        }
        return 0;
    }

badsig:
    /* Signature verification failed */
    *mlen = (size_t) -1;
    for (i = 0; i < smlen; ++i) {
        m[i] = 0;
    }

    return -1;
}
Enter fullscreen mode Exit fullscreen mode

Thank you btw for helping me!

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

The problem isn't always at the end of the stack trace, especially where memory management is involved. I don't think the library is at fault.

Actually, I think the problem is somewhere in Signature.cpp. Can you post the function in that file that includes line 73?

==6225==    by 0x1096D2: Signature::signMessage(unsigned char*, unsigned long*, unsigned char const*, unsigned long) (Signature.cpp:73)
Enter fullscreen mode Exit fullscreen mode
Thread Thread
lindenouwen profile image
Lindenouwen

Okay, The Signature.cpp function in which this happens is a rather short one:

#include "Signature.hpp"
#include <cstdint>
#include <iostream>
#include <stddef.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <cstddef>
#include <cryptopp/sha3.h>
#include <cryptopp/cryptlib.h>
#include <cryptopp/hex.h>
#include <cryptopp/filters.h>
#include <cryptopp/sha.h>
#include <cryptopp/hex.h>
#include <cryptopp/files.h>

using namespace CryptoPP;

extern "C"{
     #include "api.h"
    }
using namespace std;
/*************************************************
* Name:        signMessage
*
* Description: Computes the signed message
*
* Arguments:   - uint8_t *sm: pointer to output signed
*                             message, can be equal to m
*              - size_t *smlen: pointer to output length
*                               of signed message
*              - const uint8_t *m: pointer to message to be signed
*              - size_t mlen: length of message
*
* Extra information: -*sk: pointer to secret key
*
* No Return value
**************************************************/
void Signature::signMessage(uint8_t* signedMessage, std::size_t* smLength, const uint8_t* message, std::size_t mLength){
    // if (checkPasswd(passwd)==true){
        const uint8_t *sk = getSecretKeyAddress();
        cout << "I get here" << endl;
        PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign(signedMessage, smLength, message, mLength, sk);
        cout << "not here" << endl;
    // }
}
Enter fullscreen mode Exit fullscreen mode

PQCLEAN_DILITHIUM5AES_CLEAN_crypto_sign is the c function from the library
So I think the problem might be even further back, in main.cpp, but I cannot figure out what I am doing wrong.
The main.cpp is written as follows:

#include "Signature.hpp"
#include "Signature.cpp"
#include <cstdint>
#include <iostream>
#include <cstddef>
#include <cstring>
using namespace std;
extern "C"{
     #include "api.h"
    }
int main(){
    char publicKey[PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_PUBLICKEYBYTES];
    char secretKey[PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_SECRETKEYBYTES];
    uint8_t* pk;
    pk = (uint8_t *) &publicKey;
    uint8_t* sk;
    sk = (uint8_t *) &secretKey;
    // string passwd = "admin";
    Signature sig(pk, sk);
    sig.generateKeyPair();
    cout << "I succeeded in generating a key pair." << endl;
    string mes = "I am checking if this works";
    size_t mlen = mes.length();
    char message[mlen+1];
    strcpy(message, mes.c_str());
    uint8_t* m;
    m = (uint8_t*) &message;
    mlen = sizeof(*m);
    char signedMessage[PQCLEAN_DILITHIUM5AES_CLEAN_CRYPTO_BYTES+mlen];
    uint8_t* sm;
    sm = (uint8_t*) &signedMessage;
    size_t smLength = sizeof(*sm);
    size_t* smlen;
    smlen = (size_t*) smLength;
    sig.signMessage(sm, smlen, m, mlen);
    cout << "I succeeded in signing a message." << endl;
    cout << *sm << endl;
    return 0;
}
Enter fullscreen mode Exit fullscreen mode
Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

I think I found it. The problem is in main.cpp:

    size_t smLength = sizeof(*sm);
    size_t* smlen;
    smlen = (size_t*) smLength;
    sig.signMessage(sm, smlen, m, mlen);
Enter fullscreen mode Exit fullscreen mode

There are two problems here.

  1. sizeof(*sm) gives you the length of the value pointed to by sm. This will not give you the length of the string, but rather the size of the first item in the string/array, being a character. In other words, the value here is 1, regardless of how long the string starting at pointer sm actually is. I'll come back to this.

  2. Even if smLength were correct, (size_t*) smLength; is not going to give you the address to smLength for storing in the pointer. Instead, this is casting, or reinterpreting, the value, the integer 1 in this case, as a pointer. But what's at pointer 0x00000001? Who knows. This is known as a wild pointer.

If you look throughout your code, you'll see these same mistakes occur other times, such as with mlen.

Don't take this as a criticism, but I'm dubious about where you learned to use pointers. This is pretty much a royal hash. If you learned this from an online tutorial, example, or article, I'd strongly recommend avoiding it in the future. (Check to make sure you didn't just misunderstand first.)

The reason for the segfault is that wild pointer in #2. It's looking in the wrong place for a value, and it isn't finding it. You're lucky it failed with a segfault; it could have read in literally anything that was stored at that address in memory, whether it was coincidentally correct, subtly wrong, or absolutely bonkers. These sorts of bugs are really unpredictable like that.

Here's the operations you're misunderstanding in this code:

Getting a Pointer

To get the address of a value, for storing in a pointer, use the & operator:

size_t myValue = 42;
size_t* ptrToMyValue = &myValue;
Enter fullscreen mode Exit fullscreen mode

Getting the length of a c-string (char array)

#include <string.h>

// All three of these are valid ways to declare a c-string
char* stringA = "Hi";
char stringB[] = "there";
char stringC[20] = "Lindenouwen";

size_t lengthA = strlen(stringA);  // 2
size_t lengthB = strlen(stringB);  // 5
size_t lengthC = strlen(stringC); // 11 (NOT 20!)
Enter fullscreen mode Exit fullscreen mode

By the way...

One more pro-tip: stop using the using namespace std; trick. It's an antipattern; in production code, it's all too easy to lose track of what-comes-from-where. Namespaces exist to reduce that confusion, but using namespace negates that namespace. Most examples use it for brevity; good production code never does.

Instead, explicitly spell out namespace each time:

#include <iostream>
#include <string>

std::string greeting = "Hello, world!";
std::cout << greeting << std::endl;
Enter fullscreen mode Exit fullscreen mode

Save yourself weeks of headaches and refactoring now. Never use using namespace again.

Thread Thread
lindenouwen profile image
Lindenouwen

Thanks for your help!
I think it works now :p

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

Excellent!

You will want to get into the habit of always testing your code thoroughly in Valgrind and addressing everything it complains about; even memory leaks. Undefined behavior has a habit of hiding until the most inconvient and unexpected moment. Write tests for your code (you should be doing that anyway!), and then execute those tests both outside of and within Valgrind.

Collapse
bluhmalexander profile image
bluhm-alexander

Have you ever worked with the Motorola 68000. I really like that CPU. In your opinion do you think assembly language is still best for super low level hardware or do you think C is on par with assembly code?

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything

Ironically, I just added 68K Assembly to my list of languages to learn soon! I have a TI-89 calculator (Motorola 68000), and dearly want to play with it.

Up to this point, my assembly work has been largely limited to the X86 and X64 languages, in the context of Intel and AMD processors.

C is actually further up the stack than people think, and it isn't always the best choice for a given architecture. If you need total control, Assembly will always give that to you far and beyond any other language.

However, Assembly is also a pain in the butt (if an endearing one to certain classifications of nerds such as myself). If you have access to a higher level language that is reasonably optimized for that platform, and you don't need ultimate control, use it instead of Assembly.

In other words, "just because we can doesn't mean we should." If you can't make a reasoned argument for the language you're using, you're probably using the wrong language. :)

Collapse
bluhmalexander profile image
bluhm-alexander

Thank you for the reply, I always value getting a second opinion. The reason I'm asking this question is because I am building a game on the Sega Genesis and I've been using A C compiler to do it.

So far it hasn't been an issue because the C compiler was built for the Sega Genesis and it has a lot of nifty features to take advantage of the hardware features such as DMA. More importantly it has sound drivers which are incredibly useful because I do not want to go around writing my own Sound Driver because I am not experienced with writing such a program.

I have recently run into a few short comings with the compiler. First and foremost being that the routines I've written in C don't seem to load as fast onto the screen as compared to Assembly.

I think I will compromise by writing my screen drawing routines in Assembly and then including them in my C code. I think that would be best for me because then I would have access to features in the C compiler as well as having access to the speed of Assembly. The problem is that I am not experienced with Assembly code. Fortunately for me, 68k assembly seems to be the easiest Assembly to learn.

By the way the C compiler I'm using is called SGDK (Sega Genesis Development Kit)

What do you think about mixing languages, is it something to be avoided?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

It really depends on the languages!

There's no trouble combining C and Assembly; ultimately, C is compiled down to Assembly, at which point any Assembly code you wrote outright is just inserted in. Then, the whole thing is assembled down to binary on that particular platform.

However, you can run into varying degrees of performance issues when mixing other languages. It has to be taken on a case-by-case basis.

Bravo on making a game for Sega Genesis! Keep us posted on dev.to how that goes.

I highly recommend picking up "Game Engine Architecture" by Jason Gregory. It addresses many of the issues you're facing, and hundreds more besides, from a C and C++ perspective. He even talks about console development.

Collapse
jesuszilla_tm profile image
Jesuszilla イエスジラ

Ooh, this is an interesting question and reply! I've been increasingly curious about the 68k since I learned of its inclusion in the CPS1, CPS2, and 90's Macintosh systems!

I'm really curious as to how they developed games for the two former and how development was done in the latter, which I believe was mostly Pascal.

Collapse
natepolizogo profile image
NatePolizogo

Hey i write a program about TSP ant colony optimization and i get a segmentation fault when i compile and run the code, but when i debug it through gdb the program just runs flawlessly. What am i missing ?

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

You are dealing with what is called a Heisenbug, which is a bug, usually undefined behavior, whose behavior disappears when using debugging tools.

The first thing you should do is run the program through Valgrind (valgrind ./myprogram). Ideally, you should do this on the Debug version of your program (compiler flag -g). This may provide you information on what memory errors exist in your code, and where they are in the source. Fix everything Valgrind complains about.

However, if after doing that, you're still segfaulting, and even Valgrind can't pick up on any more errors, you're in for a bigger fight.

Start by reading my popular Stack Overflow Q&A Definitive List of Common Reasons for Segmentation Faults. This will attune your programming sense to what to look out for.

(I didn't include my personal favorite in that list: lambdas returning references can cause some particularly nasty undefined behavior.)

  1. If you have an idea of when the segmentation fault occurs functionally, that can help you figure out what function(s) may be involved. If you can, try to create a Minimum Reproducable Example that has the segfault.

  2. Print off the problem area of the code on paper. Desk check it with a red pen and a pad of paper. This means you act as the compiler, running the code mentally, and noting the value of each variable. I've caught a number of bugs this way.

  3. If you're desperate, you can run the Release target of the program through Valgrind, although this will give you raw memory addresses instead of line numbers and file names. If you're very clever with a disassembler like Nemiver, and know how to read assembly code, you may be able to work backwards to isolate the problem. However, this is extremely hard; it will help a lot if you can do this with your Minimum Reproducible Example instead of the full program.

Good luck!

Collapse
natepolizogo profile image
NatePolizogo

I think I kinda located the problem but i cant understand why is this happening. As you can see at the image above i for some reason decides to be whatever value it want's despite the fact that it is in a for loop.

Thread Thread
natepolizogo profile image
NatePolizogo
Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

for some reason decides to be whatever value it want's despite the fact that it is in a for loop.

This means it is reading from uninitialized memory. Common reasons for this:

  • You declared a variable, or dynamically allocated memory, but never initialized the memory with a value.

  • You are using a pointer (or reference) to either a position in memory which has already been freed (dangling pointer/reference), or which has never been allocated (wild pointer/reference). This can happen with either the heap or the stack; it's not limited to dynamic allocation.

  • You are exceeding the boundaries of an array or string (buffer overrun).

Collapse
presto412 profile image
Priyansh Jain • Edited

Are rust and golang going to take over C and C++? In terms of desktop software/web development. Also how would you, as a C++ expert, rate these languages? Do they have potential?

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

I strongly believe that (virtually) all languages have their place. FORTRAN and COBOL have firmly established places in the world, and are almost certain never to lose them on account of their reliability and precedence.

C and C++ likewise have this precedence, making up a sizable chunk of our source code. It's the old "if it ain't broke, don't fix it" concept; I doubt the entire collection of software that makes up a standard Linux-based operating system will ever be rewritten from C to Rust, because most of what already exists works quite well.

That said, I think Rust and golang have a lot of potential as languages, especially Rust.

(In my personal opinion, golang is a rather hipster language, but that's based in my feelings towards it, not in anything practical; so take that with a grain of salt.)

Rust looks especially interesting in the area of error handling. I'll admit, I haven't had the time to learn it very well yet, but it's DEFINITELY high on my list!

In other words, Rust and golang will probably find established places in the programming world, but they won't be displacing C, C++, or any other established language. Every tool has its place, and a quarter inch drill bit doesn't replace a 5mm drill bit.

Collapse
jesuszilla_tm profile image
Jesuszilla イエスジラ

"In my personal opinion, golang is a rather hipster language"

Thank. YOU!

Collapse
qm3ster profile image
Mihail Malo

Rust would take over everything, but the leftist collectivist community threw a baton roue of so-called "golang" at it, and now we will all perish and return to a dark age of literal witch hunts. (Because we are all out of Moore's law)
RIP information technology and human civilization in general

Collapse
presto412 profile image
Priyansh Jain

LOL

Thread Thread
qm3ster profile image
Mihail Malo

Nihilist

Collapse
shantanubanerjee75 profile image
Shantanu Banerjee • Edited

Hello Jason!! I am having some problem of memory corruption sometimes. Could you please help me out with some possible cause. Image is attached.

This issue is not always happening but sometimes. I have some memory crunch in my arm board. Is this the cause of this undefined behavior?

dev-to-uploads.s3.amazonaws.com/up...

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything

Yes, this is undefined behavior. The line marked #3 indicates a double-free is occuring somewhere in your code, wherein an already-freed pointer is being freed again. The behavior of a double-free is undefined.

Unfortunately, I don't have enough context here (especially in an image) to debug this for you. It looks like you're already using valgrind. Try compiling your own code with debug flags (-g), and then running it through Valgrind and repeating whatever action triggers this error. The resulting stack trace should point you to the line in your code where the double-free is originating.

Collapse
shantanubanerjee75 profile image
Shantanu Banerjee

Thank you very much for your reply.
I am unable to use valgrind on target due to very limited system memory on my embedded device. Could you please suggest any alternate approach which use low resource?
I have compiled my application with -ggdb3.
I have encounter this problem only with wide character text (std::wstring) and during the object destruction (out of scope) this corruption is happening.

Images
dev-to-uploads.s3.amazonaws.com/up...
dev-to-uploads.s3.amazonaws.com/up...
dev-to-uploads.s3.amazonaws.com/up...
dev-to-uploads.s3.amazonaws.com/up...
dev-to-uploads.s3.amazonaws.com/up...
dev-to-uploads.s3.amazonaws.com/up...
dev-to-uploads.s3.amazonaws.com/up...

Thread Thread
shantanubanerjee75 profile image
Shantanu Banerjee

Memory dump of variable from frame #6 of stack trace
dev-to-uploads.s3.amazonaws.com/up...

Could you please provide any hint?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

If you have memory bugs in your code, it should also work if you compile and test it on your regular machine, even though the architecture is different. Have you tried that?

Thread Thread
shantanubanerjee75 profile image
Shantanu Banerjee

Thanks for your advice. I haven't tried to run this on regular pc. This is pretty big task but let me try this. Could you please provide any opinion to use ASAN compiled binary on target?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything

That might work. I haven't worked with ARM boards or microcircuits before, so I don't have much insight there.

Collapse
mortoray profile image
edA‑qa mort‑ora‑y

Given that you're writing a fairly low-level, perhaps wait-free concurrent algorithm, it's possible that you have a bug that trips up about every millionth execution of the code. It's a race condition that corrupts a vital structure. Any attempt to trace upsets the condition leading to the error, thus making it go away. Your only choice is a tedious hand execution and logical reasoning.

My question is, how do you avoid throwing the computer out the window?

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

Avoid? I love tedious hand execution and logical reasoning! (No, seriously.) One of my absolute favorite things to do in programming is to print off the source, sit down with a pen, a hot beverage, a blank notebook, and a jazz soundtrack...and then spend the next hour or three just desk-checking the entire thing.

Mmmmmmmmmmmmmmmmmmmmmm, bliss. ,^

Why do you think I specialized in memory management and undefined behavior? I ADORE it!

Now, if you don't have my particular mental condition, and actually don't enjoy desk-checking for Heisenbugs, my advice is this: get off the computer. Print off the source, cozy up in your favorite chair in a relaxing environment, and desk-check it.

Collapse
liulk profile image
Likai Liu

I also recommend writing unit tests that makes the race condition more likely to happen. For example, if the code normally runs with < 10 threads, test it with 1000 threads. Sometimes code is well-behaved when the data entered are far apart, so try testing with consecutive values. If it's the opposite, test with random values.

What I learned over the years is that race-freedom is not composeable: code using several mutexes incorrectly could still suffer race condition, even though a single mutex is race-free on its own. When testing wait-free algorithms, start with very small primitives and gradually add onto it. And write plenty of assert() on the non-volatile local variables of the shared volatile variables the code might be using. When assert triggers under the debugger, you'll be able to see which invariants are violated in that snapshot.

Collapse
Sloan, the sloth mascot
Comment deleted
Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

I'm not as well acquainted with assembly as I would like yet, but here's my first thought: are you absolutely certain of the size (in byes) of memory addresses on your machine? This looks like you're blowing past the end of program memory.

Collapse
klapauciusisgreat profile image
klapauciusisgreat

Yes, I'm sure. However, I made some progress:

in the original 32 bit code, I had an instruction like:

        mov $cold_start,%esi    // Initialise interpreter.

that would work on macos (32 bit)

I found a 64 bit port somewhere that was instead using

    mov $cold_start,%rsi    // Initialise interpreter.

which is what I expected, but the apple clang assembler does not like this syntax because in 64 bit mode I have to use position independent addressing modes.

So I tried

mov cold_start(%rip),%rsi       // Initialise interpreter.

but it seems that derefences cold_start instead of just putting the address in. Using $cold_start(%rip) gives errors.

I guess I just don't understand the apple assembler syntax esp for 64 bit code. Looking ...

Collapse
shrivp1 profile image
shrivp1

Hi Jason,

If we encounter a segfault with error code 4 or any other such error code -

localhost kernel: [139154.090095] xxxxx_process[11909]: segfault at 21 ip 00007ff5704b5254 sp 00007ff556bbbb98 error 4 in libmpi_global-release.so[7ff56c832000+6eee000]

However we see no assertions/errors and no core dumps been generated, how do we go along to debug such issues ?

Core dump configuration been verified and is correct -
Limit Soft Limit Hard Limit Units
Max core file size unlimited unlimited bytes

also the flag to generate full cores is been enabled !!!!

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything

In almost all cases, it's very hard to debug a segfault without compiling the code in question with debug symbols (-g) and running it through Valgrind.

Core dumps are just snapshots of the raw memory when the program crashed, and will seldom provide any clues unless you are very familiar with the entire raw memory layout of your program.

Collapse
shrivp1 profile image
shrivp1

Thank you for your response !!!
The problem here is we are facing this issue specifically in our client environment, we cannot reproduce this issue in house to try compile our code using -g or use valgrind by attaching it to a process

Using valgrind would add performance overhead in customer environment, so it's not a viable option, any other means to track this live on a client environment for a particular process ?

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

Off the top of my head, I don't know of any practical ways to debug a segfault in production like you describe. You could use logs and observations to determine what behavior(s) precede the segfault, and use that to focus in on part of your code base.

Meanwhile, your best bet would be to try and isolate what's different about their environment versus your test environment, and try and replicate it.

In any case, this won't be easy. This roadblock you're running into is exactly why it is so often said "if we can't reproduce it, we can't fix it".

Thread Thread
shrivp1 profile image
shrivp1

Thank you Jason for the advise..
Will see if we can try to identify a diff in production env and in general..
Logs weren't much helpful to logically conclude in this case

Collapse
iggy12345 profile image
Aaron Jencks

Hi Jason, I'm encountering a strange seg fault when trying to write default values to an mmap'd region on my disk, but when I try to write to the file manually in gdb, it comes back normal. Here is what I'm talking about

Found 18,542,192 final board states. Explored 17,714,416,428 boards @ 3,628,469 b/s. Runtime: 0:01:20:43 CPU Time: 0:19:49:07
Thread 32 "main" received signal SIGSEGV, Segmentation fault.
[Switching to Thread 0x7ffe4a7fc700 (LWP 554025)]
0x0000555555561c20 in heirarchy_insert (h=0x55555556b070, key=3148149460081748650666) at mem_man/heir.c:107
107             for(size_t b = 2; b < num_jumps; b++) ((uint64_t*)(phase[bits]))[b] = 0;
(gdb) p phase
$1 = (void **) 0x7ffa1389f6a0
(gdb) p bits
$2 = 341
(gdb) p phase[bits]
$3 = (void *) 0x7ffff77a7f80
(gdb) p num_jumps
$4 = 48
(gdb) p b
$5 = 16
(gdb) p ((uint64_t*)(phase[bits]))
$6 = (uint64_t *) 0x7ffff77a7f80
(gdb) p ((uint64_t*)(phase[bits]))[b]
$7 = 282584257676671
(gdb) p ((uint64_t*)(phase[bits]))[b] = 0
$8 = 0
(gdb) p ((uint64_t*)(phase[bits]))[b]
$9 = 0
(gdb) p ((uint64_t*)(phase[bits]))[b + 1]
$10 = 0
(gdb) p ((uint64_t*)(phase[bits]))[b + 2]
$11 = 4299030531
(gdb) p ((uint64_t*)(phase[bits]))[47]
$12 = 52640
Enter fullscreen mode Exit fullscreen mode

So when I do it myself, there's no segfault. I've tried to run valgrind, but it's so slow, can you take a look at it? The code is uploaded to github at github.com/iggy12345/reversi_walke...

I've been working at this one for days now and I'll take any help I can get.

Collapse
codemouse92 profile image
Jason C. McDonald Ask Me Anything

I would run it through valgrind. That should take you right to the line of code that the segfault is being thrown at. (You're welcome to share that output here.)gdb rarely provides much useful information for undefined behavior.

Collapse
iggy12345 profile image
Aaron Jencks

I'll try and see if I can get it to finish, the segfault seems to happen at 18mil final board states, and at 3mil/sec it takes about an hour and a half to get there, but with valgrind... I'm an hour past 1 day and I'm still only at 3mil boards

Thread Thread
codemouse92 profile image
Jason C. McDonald Ask Me Anything • Edited

Although it's an early (and wild) guess, if the segfault occurs with a large set of data, but not a small set, I would suspect a buffer overrun may be the cause of your problems. Are you...

(1) Putting too much on the stack (versus dynamically allocating the space you need), or
(2) Exceeding the space you allocated?

Collapse
rhymes profile image
rhymes

I know this question is going to come so I'm going to ask it myself: what do you think of languages like Rust?

Do you think that, in some cases, isn't a machine going to be better than a human at dealing with memory management anyway?

Collapse
